Dell PowerEdge T630 tower server, black metal chassis with eight front drive bays

DELL

DELL PowerEdge T630 tower server E5-2680 v3 12-core 2.5GHz 384GB DDR4 3×2TB SAS H330

SKU CH-QJT3-73WC6

Tower server with twelve-core Xeon at 2.5 GHz, 384 GB DDR4, three 2 TB SAS drives and H330 RAID controller

  • TypeTower
  • Rack Height5U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • MAX Processors2
  • ChipsetIntel C610
  • 12-core Xeon handles heavy workloads
  • 384 GB DDR4 fits large datasets
  • Three 2 TB SAS drives give 6 TB storage
  • H330 RAID controller supports multiple levels
  • Dual 750 W supplies keep it running

Dell PowerEdge T630 tower server

This Dell PowerEdge T630 tower server ships new with a single Intel Xeon E5-2680 v3 twelve-core 2.5GHz processor and 384GB of DDR4 memory across 24 DIMM slots. Three 2TB 7.2K SAS drives are installed behind the H330 RAID controller supporting RAID 0, 1, 5, 10, 50 and 60. Dual 750W redundant power supplies and a DVD ROM complete the 5U chassis.

Compatibility checks before ordering

Verify that your rack or floor space can accommodate a 5U tower measuring 26.8 x 17.44 x 3.4 inches and weighing 110 lbs. Confirm the SAS backplane and H330 controller match your drive replacement plans, and note the single CPU configuration leaves one processor socket and twelve memory slots unpopulated. The eight PCIe slots include x16 and x8 lanes split between CPU1, CPU2 and the PCH.

Thermals, noise and power draw

Dual redundant 750W power supplies share the load and maintain operation if one unit fails. The tower form factor uses internal airflow across two processor sockets and up to eight hot-plug drive bays. Acoustic output will reflect the 5U server design with multiple system fans running under typical workloads.

Highlights

  • 12-core Xeon handles heavy workloads
  • 384 GB DDR4 fits large datasets
  • Three 2 TB SAS drives give 6 TB storage
  • H330 RAID controller supports multiple levels
  • Dual 750 W supplies keep it running

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge T630
TypeTower
Rack Height5U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
MAX Processors2
ChipsetIntel C610
Installed Memory Size384GB
Memory TypeDDR4
Max Memory Capacity384GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots24
Storage ControllerDell Perc H330 Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/10/50/60
Max HDD Capacity80TB
Media DrivesDVD ROM
GPU TypeIntegrated Graphics
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports2 x Ports
Expansion Slots8 PCIe slots
Operating SystemNo
Weight59.0000LBS

Questions about this item

Does the tower ship with drive trays for the three 2 TB SAS drives, or must they be purchased separately?

The three 2 TB 7.2K 6Gbps 3.5" SAS drives are supplied with their hot-plug trays; the remaining five 3.5" bays are empty and trays are only included when additional drives are ordered.

Should I choose the single E5-2680 v3 or add a second processor to reach the 384 GB memory ceiling?

The installed 384 GB already uses all 24 DDR4 slots (12 per CPU); adding a second Xeon would not increase capacity unless higher-density modules replace the current ones.

What throughput can the H330 controller deliver to the three 6 Gbps SAS drives in a RAID 5 array?

The H330 12 Gbps controller supports RAID 0/1/5/10/50/60, but each 2 TB drive is limited to 6 Gbps, so the array speed is bound by the drives rather than the controller.
