Silver 2U rack server chassis, front drive bays visible

DELL

DELL PowerEdge XR8620t 2U rack server Xeon DDR5 512GB

SKU CH-MMJ2-AHD3Y MPN PowerEdge_XR8620t

A 2U rack server supporting one Intel Xeon Scalable processor with up to 512GB DDR5 memory, three full-height PCIe accelerator slots and two 2.5-inch drive bays

  • WorkloadCentralized RAN, Distributed RAN, Network Edge, Manufacturin
  • TypeRack
  • Rack Height2U
  • SecurityCryptographically signed firmware Data at Rest Encryption (S
  • CPU TypeIntel Xeon Scalable
  • # of Processors Installed0
  • Designed for Centralized RAN, Distributed RAN, Network Edge, Manufacturing, Military & Defense workloads
  • Supports one Intel Xeon Scalable processor for compute-intensive tasks
  • Up to 512GB DDR5 memory across 8 RDIMM slots for high bandwidth
  • Three full-height half-length PCIe slots enable GPU or accelerator expansion
  • Cryptographically signed firmware, Secure Boot, Silicon Root of Trust, TPM 2.0 FIPS certified security

Purpose-built edge server

The DELL PowerEdge XR8620t is a 2U rack server designed for Centralized RAN, Distributed RAN, Network Edge, Manufacturing and Military & Defense workloads. It accepts one Intel Xeon Scalable processor and up to 512GB of DDR5 memory across eight slots. No CPU, memory or drives are installed, so integrators configure the exact compute and storage mix each site requires.

Bundled security foundation

Cryptographically signed firmware, Secure Boot, Secure Erase and a Silicon Root of Trust are embedded in the platform, while Secured Component Verification checks hardware integrity at every boot. Data-at-rest encryption works with self-encrypting drives using local or external key management, and System Lockdown activates when iDRAC9 Enterprise or Datacenter is licensed. TPM 2.0 meets FIPS, CC-TCG and China NationZ certifications out of the box.

Pre-deployment checklist

Verify that your rack provides 2U height and at least 17.06 inches of depth for the 3.27 x 7.27 x 17.06 inch chassis. Select a single Xeon Scalable processor, DDR5 RDIMMs up to the 512GB limit and 2.5 inch SATA or SAS drives for the two internal bays. Plan power and cooling for up to three full-height half-length PCIe accelerators, and confirm operating-system licensing separately as none is included.

Highlights

  • Designed for Centralized RAN, Distributed RAN, Network Edge, Manufacturing, Military & Defense workloads
  • Supports one Intel Xeon Scalable processor for compute-intensive tasks
  • Up to 512GB DDR5 memory across 8 RDIMM slots for high bandwidth
  • Three full-height half-length PCIe slots enable GPU or accelerator expansion
  • Cryptographically signed firmware, Secure Boot, Silicon Root of Trust, TPM 2.0 FIPS certified security

Specifications

BrandDELL
SeriesPowerEdge XR8620t
WorkloadCentralized RAN, Distributed RAN, Network Edge, Manufacturing, Military & Defense
TypeRack
Rack Height2U
SecurityCryptographically signed firmware
Data at Rest Encryption (SEDs with local or external key mgmt)
Secure Boot
Secure Erase
Secured Component Verification (Hardware integrity check)
Silicon Root of Trust
System Lockdown (requires iDRAC9 Enterprise or Datacenter)
TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
CPU TypeIntel Xeon Scalable
# of Processors Installed0
MAX Processors1
Installed Memory SizeNo
Memory TypeDDR5
Max Memory Capacity512GB
Number of Memory Slots8
Hard Drive (Installed)None
HDD InterfaceSATA/SAS
SSD (Installed)No
GPU Type3 x FHHL PCIe
Expansion Bays2 x 2.5"
Operating SystemNo
Dimensions3.27" x 7.27" x 17.06"
Weight13.27 lbs.
Shipping weight9.07 kg
Package size508 × 254 × 127 mm

Questions about this item

How often should the system firmware be re-verified to maintain the Silicon Root of Trust?

The Silicon Root of Trust and Secured Component Verification run automatically on every boot, so no manual re-verification schedule is required.

Which resource saturates first when all three FHHL PCIe accelerators run sustained workloads?

The single Intel Xeon Scalable processor and its PCIe lane budget become the limiting factor before the 512GB DDR5 memory ceiling is reached.

What is the typical acoustic output when the 2U chassis runs a full load continuously?

The 2U form factor uses high-speed fans to cool the CPU and up to three full-height cards, so sustained operation produces noticeable datacentre-level noise.
