Black tower workstation with front panel vents and Dell logo

DELL

DELL Precision T5820 Workstation Xeon W-2133 3.6GHz 32GB DDR4 500GB NVMe

SKU CH-7CNC-2Q3SN

Tower workstation with 6-core Xeon W-2133, 32 GB DDR4 and 500 GB NVMe for professional design and engineering workloads

  • CPU TypeIntel Xeon
  • MAX Processors1
  • Chipset425W
  • GPU TypeNVIDIA GeForce 210
  • Video Memory1GB
  • Installed Memory Size32GB
  • 6-core Xeon W-2133 at 3.6 GHz powers demanding professional workloads
  • 32 GB DDR4 ECC memory enables smooth multitasking on large projects
  • 500 GB NVMe storage delivers fast access to applications and files
  • Windows 11 Pro pre-installed for immediate out-of-box setup
  • Tower chassis with eight DIMM slots and multiple PCIe Gen 3 slots supports future expansion

Professional tower workstation

The Dell Precision T5820 is a new tower workstation built around a single Intel Xeon W-2133 six-core processor running at 3.6GHz with 12 virtual cores. It ships with 32GB of DDR4 ECC memory installed across eight DIMM slots and a 500GB NVMe M.2 SSD on a PCIe adapter card. Windows 11 Pro is preinstalled for immediate setup.

Expansion layout and storage flexibility

Four-channel memory architecture supports up to 512GB total capacity when all eight slots are populated. The chassis provides two PCIe x16 slots, one wired as x8, one as x4 and one as x1, plus a legacy PCI slot for specialised add-in cards. Two FlexBays accept 3.25in or 2.5in drives, a 5.25in bay and an SD slot add further storage options without using expansion slots.

Sustained workload behaviour

The 425W chipset and 600W graphics power budget allow up to two 300W double-width GPUs for extended rendering or compute tasks. The installed GeForce 210 with 1GB video memory drives two monitors via HDMI, DVI and VGA for basic display output. Intel RSTe software RAID 0, 1, 5 and 10 protects data during long project sessions when configured with additional drives.

Highlights

  • 6-core Xeon W-2133 at 3.6 GHz powers demanding professional workloads
  • 32 GB DDR4 ECC memory enables smooth multitasking on large projects
  • 500 GB NVMe storage delivers fast access to applications and files
  • Windows 11 Pro pre-installed for immediate out-of-box setup
  • Tower chassis with eight DIMM slots and multiple PCIe Gen 3 slots supports future expansion

Specifications

CPU TypeIntel Xeon
MAX Processors1
Chipset425W
GPU TypeNVIDIA GeForce 210
Video Memory1GB
Installed Memory Size32GB
Memory TypeDDR4
Max Memory Capacity32GB
Memory FeaturesFour channel memory up to 2666MHz DDR4 ECC memory with 8 DIMM Slots. Memory speed is dependent on specific Intel
Xeon or Core X Processor installed.
Number of Memory Slots8
SSD (Installed)500GB
Raid LevelRAID 0/1/5/10
BrandDELL
SeriesPrecision
ModelPrecision T5820
TypeTower
Redundant Hot-swap PowerNo
LAN Ports1 x Ports
Expansion SlotsAll slots PCIe Gen 3: (2) PCIe x16, (1) PCIe x16 wired as x8, (1) PCie x16 wired as x4, (1) PCIe x16 wired as x1, 1 PCI 32/33
Operating SystemWindows 11 Pro
Weight45.0000LBS

Questions about this item

What thermal ceiling does the 425W chipset and 6-core 3.6GHz Xeon hit during long renders?

The 425W power supply and Xeon W-2133 six-core 3.6GHz processor define the thermal ceiling; sustained heavy workloads will be limited by this 425W envelope.

How loud and hot does the GeForce 210 1GB GPU get when the tower runs all day?

The GeForce 210 1GB card draws modest power inside the 425W budget, so fan noise and case temperatures stay low during continuous operation.

Which DDR4 ECC modules must I already have to reach the 512GB ceiling?

The board accepts up to 512GB across eight DDR4 ECC DIMM slots running four-channel at 2666MHz; populate with registered DDR4 ECC sticks to expand beyond the installed 32GB.
