Black 1U rack server chassis with four 3.5 inch drive bays visible on the front panel

DELL

DELL QUO-26175969-R1B5N6 PowerEdge R660xs rack server 3.5" 4-bay Xeon Silver 4510 12C 2.4GHz 150W DDR5-5600

SKU CH-W4G9-4P3Q9 MPN QUO-26175969-R1B5N6

A 3.5" 4-bay rack server with a 12-core Xeon Silver 4510 at 2.4GHz and DDR5-5600 memory

  • Trusted Platform Module 2.0 V6 strengthens platform security
  • Intel Xeon Silver 4510 delivers 12 cores and 24 threads at 2.4 GHz
  • 150 W thermal design supported by dedicated single-CPU heatsink
  • 5 inch chassis accommodates up to 4 SATA hard drives
  • DDR5 memory runs at 5600 MT/s for high bandwidth

12-core Xeon rack server for single-socket workloads

The Dell PowerEdge R660xs is a 1U rack server built around a single Intel Xeon Silver 4510 processor with 12 cores and 24 threads running at 2.4 GHz. It supports DDR5-5600 memory and includes a Trusted Platform Module 2.0 V6 for hardware-based security. The 3.5-inch chassis holds up to four SATA hard drives, making it suited for storage-focused tasks in a compact form factor.

Verify power, cooling and rack space before ordering

Confirm your rack can supply enough power for a 150 W CPU and that your cooling strategy matches the single-CPU heatsink design. The system ships with one processor installed and no second CPU option, so expansion beyond one socket is not possible. Ensure your infrastructure supports DDR5-5600 RDIMMs and that the 3.5-inch drive bays align with your storage plan.

Single-CPU heatsink and four-bay SATA chassis

The heatsink is rated for CPUs up to 150 W, matching the installed Xeon Silver 4510, and the chassis provides four front-accessible 3.5-inch SATA drive bays. This layout simplifies drive swaps and keeps cabling contained within the 1U height. The TPM 2.0 V6 module is integrated on the board, and the memory slots are populated with 5600 MT/s RDIMMs for consistent performance.

Highlights

  • Trusted Platform Module 2.0 V6 strengthens platform security
  • Intel Xeon Silver 4510 delivers 12 cores and 24 threads at 2.4 GHz
  • 150 W thermal design supported by dedicated single-CPU heatsink
  • 5 inch chassis accommodates up to 4 SATA hard drives
  • DDR5 memory runs at 5600 MT/s for high bandwidth

Specifications

BrandDELL
ModelQUO-26175969-R1B5N6
Part NumberQUO-26175969-R1B5N6
Shipping weight13.61 kg
Package size762 × 508 × 508 mm

Questions about this item

What comes in the box and what must I buy separately?

The chassis supports up to four 3.5" SATA drives and includes one Xeon Silver 4510 processor with heatsink. Memory modules, drives, operating system and rail kit are not included.

Should I choose the 4400 MT/s or 5600 MT/s DDR5 RDIMMs?

The installed Xeon Silver 4510 officially supports DDR5-4400; the platform can run 5600 MT/s RDIMMs but they will operate at 4400 MT/s with this CPU.

What does the 12-core 2.4 GHz figure mean in practice?

The Xeon Silver 4510 provides 12 cores and 24 threads at a 2.4 GHz base frequency with a 150 W TDP, giving a 30 MB cache for multi-threaded server workloads.
