DELL T350 Rack Server 5U E-2374G 4C 64GB 4x 16TB 7.2K SATA H755

Dell T350 5U rack server with E-2374G

The Dell T350 is a 5U rack-mount server built around a single Intel E-2374G processor running at 3.7 GHz with four cores and 8 MB cache. It ships with 64 GB of DDR4 memory in four 16 GB modules at 3200 MT/s. Four 16 TB 7.2K SATA drives are installed behind an H755 RAID controller. The chassis provides eight 3.5-inch drive bays for future expansion. Remote management is handled by iDRAC9 Enterprise with OpenManage Enterprise Advanced+.

Upgrade from single-drive or non-RAID towers

This system replaces a standalone tower or desktop acting as a file server by adding hardware RAID, redundant 600 W power supplies and out-of-band management. The jump is worth it when uptime matters and you need hot-swap drive bays plus a dedicated remote console. The four installed drives give 64 TB raw capacity with RAID redundancy options. The H755 controller supports multiple RAID levels for performance or protection.

Verify rack depth, power cords and PCIe card length

Confirm your rack can accept a 5U unit and that the 600 W redundant supplies match your PDU plug type. The server includes two PCIe Gen 4.0 slots and two Gen 3.0 slots; check the length and height allowance for any add-in cards you plan to install. The dual SD module with a 16 GB card is present for hypervisor boot. Onboard networking is dual 1 GbE Broadcom; add a NIC if faster links are required.
