Dell VRTX 5U rack chassis with twelve 3.5 inch drive bays

DELL

DELL VRTX rack server 2× M630 2× E5-2680v4 2.4GHz 14C 128GB 12× 12TB 7.2K SAS

SKU CH-G9FD-ESKCQ

A 5U rack chassis holds two M630 blades, each with dual 2.4GHz 14-core Xeons, 128GB DDR4 and twelve 12TB 7.2K SAS drives behind a PERC S130 controller.

  • TypeRack
  • Rack Height5U
  • CPU TypeIntel
  • Hard Drive (Installed)12x 12TB 7.2K SAS
  • Storage ControllerS130
  • Max HDD Capacity12x 3.5" Drive Bays
  • Dual 14-core Xeons at 2.4 GHz for parallel workloads
  • 128 GB DDR4 memory across eight modules
  • Twelve 12 TB 7.2 K SAS drives on S130 controller
  • Eight flexible PCIe slots with 1 Gb switch module
  • Four 1600 W redundant PSUs with iDRAC8 Express management

Dell VRTX 5U rack server with dual M630 blades

This Dell VRTX system fits a 5U rack space and holds two M630 compute blades. Each blade runs dual Intel E5-2680v4 processors at 2.4 GHz with 14 cores and 35M cache. The chassis ships with 128 GB of DDR4 memory across eight 16 GB modules and twelve 12 TB 7.2K SAS drives installed.

1 Gb switch module and S130 controller set

Internal networking is handled by a VRTX 1GB switch module, so blade-to-blade and blade-to-uplink traffic tops out at one gigabit per second. The single PERC8-class S130 RAID controller manages all twelve drive bays without a dedicated cache module, limiting write performance on heavy random workloads.

Verify 5U rack depth and 1600 W power feed before

The chassis requires a rack deep enough for a 5U tower-form-factor enclosure and four 1600 W redundant power supplies fed from suitable circuits. Only eight PCIe slots are available — three full-height and five low-profile — so expansion cards must fit that mix. No optical drive bay is present.

Highlights

  • Dual 14-core Xeons at 2.4 GHz for parallel workloads
  • 128 GB DDR4 memory across eight modules
  • Twelve 12 TB 7.2 K SAS drives on S130 controller
  • Eight flexible PCIe slots with 1 Gb switch module
  • Four 1600 W redundant PSUs with iDRAC8 Express management

Specifications

BrandDELL
ModelVRTX
TypeRack
Rack Height5U
CPU TypeIntel
Hard Drive (Installed)12x 12TB 7.2K SAS
Storage ControllerS130
Max HDD Capacity12x 3.5" Drive Bays
Remote ManagementiDRAC8 Express

Questions about this item

Should I pick the 128GB DDR4 configuration or add more memory later?

The system ships with 128GB DDR4 across the two M630 blades. Each blade holds eight 16GB modules, so capacity can be expanded within the blade's DIMM limits.

What does the 2.4GHz 14-core E5-2680v4 rating mean for actual workloads?

Each blade runs two 2.4GHz 14-core processors, delivering 28 cores per blade for multi-threaded applications and virtualisation density.

How does the 1GB switch module affect network throughput between blades?

The VRTX 1GB switch module provides internal 1GbE connectivity between the two M630 blades and the shared chassis resources.
