Small green circuit board mSATA SSD with gold edge connector and black label

Dogfish Technology

Dogfish Technology 64GB mSATA internal SSD

SKU CH-ESRP-8AAYZ

64 GB mSATA internal solid-state drive with up to 400 MB/s read and 100 MB/s write speeds for notebooks and ultrabooks

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactormSATA
  • Capacity64GB
  • Memory Components2D NAND
  • InterfaceMini-SATA (mSATA)
  • mSATA form factor fits 30mm x 50.88mm slots
  • 64GB capacity stores operating system and core applications
  • Sequential read up to 400MBps speeds up boot and load times
  • MTBF of 1000000 hours indicates long service life
  • Operates from 0°C to 75°C for notebook and ultrabook use

Dogfish 64GB mSATA internal SSD

This Dogfish Technology drive is a 64GB internal solid state drive built in the mSATA form factor. It connects through a SATA III 6Gb/s interface and uses 2D NAND flash memory. The unit measures 50.88mm by 30mm with a 1mm profile.

Suits older notebooks tablets

The drive fits legacy systems that only accept the Mini-SATA form factor. It is not intended for modern M.2 slots or 2.5-inch bays. Buyers needing larger capacities or higher sustained throughput should consider other form factors.

SATA III interface with up to 400MB/s sequential

The SATA III connection delivers a maximum sequential read of 400MB/s and a maximum sequential write of 100MB/s. This single interface specification determines whether the drive matches the host system and the performance envelope required.

Highlights

  • mSATA form factor fits 30mm x 50.88mm slots
  • 64GB capacity stores operating system and core applications
  • Sequential read up to 400MBps speeds up boot and load times
  • MTBF of 1000000 hours indicates long service life
  • Operates from 0°C to 75°C for notebook and ultrabook use

Specifications

BrandDogfish
SeriesSSDNOW dogfish 64g
ModelDOGFISH SSD 64GB
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactormSATA
Capacity64GB
Memory Components2D NAND
InterfaceMini-SATA (mSATA)
Max Sequential ReadUP TO 400MBps
Max Sequential WriteUP TO 100MBps
MTBF1,000,000 hours
Operating Temperature0°C ~ +75°C
Storage Temperature-45°C ~ +85°C
Operating Humidity0% ~ 95%
Height1MM
Width30MM
Depth50.88MM

Questions about this item

How long is the MTBF rating for this 64GB mSATA drive?

The drive carries an MTBF of 1,000,000 hours, so under normal use it should not require replacement for many years.

What is the maximum sustained write speed before the drive becomes the bottleneck?

Sequential write tops out at 100MBps, so heavy write workloads will hit that ceiling first.

How much heat and noise does the SSD add when running continuously?

With no moving parts it produces negligible noise and minimal heat, operating within a 0°C to 75°C range.
