Black 200mm axial fan with seven steel blades and die-cast aluminium frame

Ebm-Papst

Ebm-Papst No.W2E200-HK38-01 230V AC 200mm industrial cooling fan

SKU CH-18P4-YFRHE MPN No.W2E200-HK38-01

200 mm AC axial fan delivers 2550–2800 RPM airflow at 230 V with IP44 protection and ball-bearing motor

  • Typeaxial cooling fan
  • Fan RPM2550~2800
  • Voltage230
  • Hz50/60
  • Phase1
  • Amps0.29
  • Reliable airflow at 2550–2800 RPM with 230 V AC supply
  • IP44 rating protects against dust and splashing water in harsh environments
  • Ball-bearing motor runs continuously from –25 °C to 65 °C
  • Low 64–80 W power draw keeps operating costs down
  • Seven steel blades on a 200 mm die-cast aluminium frame deliver 80–95 Pa static pressure

Industrial axial cooling fan

The Ebm-Papst W2E200-HK38-01 is a 230V AC axial fan built for cabinet and enclosure cooling in industrial environments. Its 200mm diameter frame houses a ball-bearing motor rated for continuous operation between -25°C and 65°C. The IP44-rated construction uses a die-cast aluminium wall ring and black-coated sheet-steel blades for durability.

Upgrade from smaller or sleeve-bearing units

This model replaces lower-airflow fans or sleeve-bearing designs that wear faster in dusty or high-temperature cabinets. The step up to 2550-2800 RPM and 64-80W power draw is justified when equipment density raises internal temperatures beyond what a 64W class fan can exhaust. The 80-95Pa maximum back-pressure rating supports restrictive filter meshes or dense component layouts.

Verify voltage, mounting and clearance

Confirm the supply is single-phase 230V AC at 50/60Hz and that the 0.29-0.35A current draw suits the circuit protection. The 200mm square frame and 2.1kg weight require secure mounting points on the enclosure wall. Ensure the operating temperature range matches the installation site and that the IP44 rating meets the local ingress requirements.

Highlights

  • Reliable airflow at 2550–2800 RPM with 230 V AC supply
  • IP44 rating protects against dust and splashing water in harsh environments
  • Ball-bearing motor runs continuously from –25 °C to 65 °C
  • Low 64–80 W power draw keeps operating costs down
  • Seven steel blades on a 200 mm die-cast aluminium frame deliver 80–95 Pa static pressure

Specifications

Typeaxial cooling fan
BrandEbmpapst
Fan RPM2550~2800
Voltage230
Hz50/60
Phase1
Amps0.29
MaterialSheet steel, coated in black
Fan TypeAC

Questions about this item

What cut-out diameter and bolt pattern does the 200mm wall ring require?

The die-cast aluminum wall ring fits a 200mm cut-out and uses the standard four-hole mounting pattern for axial fans of this frame size.

How is the 450VDB capacitor wired during installation, and what mistake should be avoided?

Connect the capacitor across the motor's auxiliary winding terminals; the common error is fitting a lower-voltage capacitor that fails under 230VAC operation.

When should the ball bearing be inspected or the fan replaced?

Inspect the ball bearing at each scheduled maintenance interval; replace the unit if vibration increases or speed drops below 2550 RPM at 50Hz.
