Eluktronics MANIX 4TB M.2 2280 internal SSD, double-sided bare board, green PCB with black chips, no heatsink

Eluktronics

Eluktronics MANIX 4TB NVMe internal SSD

SKU CH-TM3Z-5RVZQ

M.2 2280 NVMe drive with 4000 GB capacity and sequential speeds up to 4700 MB/s read and 3400 MB/s write

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity4TB
  • Memory ComponentsQLC
  • InterfacePCI-Express 4.0 x4
  • Massive 4TB capacity stores games and media
  • Up to 4700 MB/s read speeds load apps instantly
  • Up to 3400 MB/s write speeds save large files fast
  • PCIe 4.0 x4 interface unlocks full NVMe performance
  • 5 million hour MTBF backs long-term reliability

Capacity and form factor

The Eluktronics MANIX 4000GB-G4SS is a 4TB internal solid-state drive built in the M.2 2280 form factor. It connects through a PCIe 4.0 x4 interface using the NVMe protocol. The drive uses 3D QLC NAND flash and is assembled double-sided with a height of 2.23mm.

Ideal use and limits

This drive suits users who need a large, single volume for games, media libraries or project files and who have a motherboard with an M.2 slot wired for PCIe 4.0 x4. Systems limited to PCIe 3.0 will see sequential speeds capped at roughly 3400 MB/s. The module ships without a heatsink, so the host board must provide adequate airflow or a dedicated cooler.

Sustained workload behaviour

Under continuous write loads the QLC architecture will settle to lower throughput once its SLC cache fills, and the controller may throttle if the NAND temperature rises without a heatsink. The rated MTBF of 1500000 hours reflects long-term reliability under typical consumer write patterns rather than enterprise-grade endurance. Thermal management becomes the main factor that keeps performance consistent during extended transfers.

Highlights

  • Massive 4TB capacity stores games and media
  • Up to 4700 MB/s read speeds load apps instantly
  • Up to 3400 MB/s write speeds save large files fast
  • PCIe 4.0 x4 interface unlocks full NVMe performance
  • 5 million hour MTBF backs long-term reliability

Specifications

BrandEluktronics
SeriesMANIX
ModelMANIX4000GB-G4SS
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity4TB
Memory ComponentsQLC
InterfacePCI-Express 4.0 x4
Max Sequential ReadUp to 4700 MBps
Max Sequential WriteUp to 3400 MBps
MTBF1,500,000 hours
HeatSinkwithout HeatSink
Height2.23mm
Width22mm
Depth80mm

Questions about this item

Will this drive fit in a standard M.2 2280 slot on a laptop or desktop?

Yes. The drive uses the M.2 2280 form factor measuring 22mm wide, 80mm long and 2.23mm high, which matches the standard slot dimensions used in most modern laptops and desktops.

Does the drive need a heatsink when installed in a PCIe 4.0 motherboard?

The drive ships without a heatsink. The supplier strongly recommends adding one when running at PCIe 4.0 speeds to prevent thermal throttling and keep performance consistent.

What sequential speeds can I expect if my system only supports PCIe 3.0?

On a PCIe 3.0 x4 interface the drive is limited to a maximum of 3400 MB/s read and write due to the bus bandwidth ceiling.
