Evoc V5604A (V560GNN) gaming laptop Ryzen AI 7 450 RTX 5060 32 GB 4 TB 16 QHD+ 300Hz
16-inch QHD+ 300Hz gaming laptop with Ryzen AI 7 450, RTX 5060 8GB GDDR7, 32GB DDR5, 4TB PCIe 4.0 NVMe storage and metal chassis
- ColorSilver
- Operating SystemWindows 11 Pro
- CPUAMD Ryzen™ Al 7 450
- Screen16" QHD+
- Memory32GB
- Storage4 TB M.2 PCIe 4.0 x4 NVMe SSD
- Ryzen AI 7 450 reaches 5.1 GHz turbo for responsive multitasking
- RTX 5060 with 8 GB GDDR7 drives smooth 1600p gaming
- 16 inch QHD+ 300 Hz panel delivers fluid motion clarity
- 32 GB DDR5 5600 MHz dual channel handles heavy workloads
- 4 TB PCIe 4.0 NVMe storage ensures rapid load times
16″ QHD+ 300 Hz gaming laptop
The Evoc V5604A pairs a 16-inch QHD+ panel running at 300 Hz with an AMD Ryzen AI 7 450 processor and an NVIDIA GeForce RTX 5060 GPU. It ships with Windows 11 Pro and a silver metal chassis built to MIL-STD 810H durability standards.
32 GB DDR5 memory and 4 TB PCIe 4.0 NVMe storage
Dual-channel DDR5 5600 MHz memory provides 32 GB of capacity for multitasking and memory-intensive workloads. Two 2 TB M.2 PCIe 4.0 x4 NVMe SSDs combine for 4 TB of fast storage, eliminating bottlenecks during boot and large-file loads.
RTX 5060 with 8 GB GDDR7 video memory
The discrete RTX 5060 graphics card carries 8 GB of GDDR7 VRAM, setting the ceiling for texture resolution and frame-buffer capacity in modern titles. This VRAM amount determines whether the laptop can hold high-resolution assets without swapping to system memory.
Highlights
- Ryzen AI 7 450 reaches 5.1 GHz turbo for responsive multitasking
- RTX 5060 with 8 GB GDDR7 drives smooth 1600p gaming
- 16 inch QHD+ 300 Hz panel delivers fluid motion clarity
- 32 GB DDR5 5600 MHz dual channel handles heavy workloads
- 4 TB PCIe 4.0 NVMe storage ensures rapid load times
Specifications
| Brand | EVOC |
|---|---|
| Series | V560GNN |
| Model | EVOC V5604A (V560GNN) |
| Part Number | EV-V5604A-HID8 |
| Color | Silver |
| Operating System | Windows 11 Pro |
| CPU | AMD Ryzen™ Al 7 450 |
| Screen | 16" QHD+ |
| Memory | 32GB |
| Storage | 4 TB M.2 PCIe 4.0 x4 NVMe SSD |
| Graphics Card | NVIDIA® GeForce® RTX™ 5060 |
| Video Memory | 8GB |
| Dimensions (W x D x H) | 14.10” (w) x 10.18” (d) x 0.78” (h) |
| Weight | 4.63 lbs. |
| Other Features | Metal top and bottom case, FlexiCharger, MIL-STD 810H |
| CPU Type | AMD Ryzen AI 400 Series |
| Processor Name | AMD Ryzen AI 7 450 |
| Number of Cores | 8-core Processor |
| Turbo Frequency | Max Turbo Frequency 5.1 GHz |
| CPU L3 Cache | 24 MB |
| Screen Size | 16.0" |
| Touchscreen | No |
| Display Type | QHD+ |
| Resolution | 2560 x 1600 |
| Panel | QHD+ |
| Refresh Rate | 300Hz |
| Display Features | Wide View Angle, 72% NTSC Display, Matte Finished |
| GPU/VPU | GeForce RTX 5060 Laptop GPU |
| Graphic Type | Dedicated Card |
| SSD | 4 TB |
| HDD | No |
| Storage Spec | 4 TB (2 x 2 TB) M.2 PCIe 4.0 x4 NVMe SSD |
| Memory Speed | DDR5 5600MHz |
| Memory Spec | 16 GB x 2 |
| Memory Type | 2 x SO-DIMM |
| Memory Slot (Total) | 2 |
| Memory Slot (Available) | 0 |
| Max Memory Supported | 128GB |
| LAN | Built-in Gigabit Ethernet LAN |
| WLAN | Intel Dual Band Wireless Wi-Fi 6E AX210 |
| WiFi Generation | Wi-Fi 6E |
| Bluetooth | Yes |
| USB | 1x USB 4 Gen3 Port with DisplayPort 2.1 and Power Delivery DC in (Type C), 1x USB 4 Gen3 Port with DisplayPort 2.1 (Type C), 1x USB 3.2 Gen2 Port (Type A) with Power USB Port, AC/DC, 1x USB 3.2 Gen1 Port (Type A) |
| HDMI | 1x HDMI output Port (with HDCP) |
| Audio Ports | 1x 2-in-1 Audio Jack (Headphone / Microphone) |
| Audio | High-Definition audio interface, Sound Blaster Studio+ |
| Speaker | Built-in two speakers |
| Touchpad | Built in Click pad with Microsoft PTP multi-gesture and scrolling function |
| Keyboard | Multi languages, Single Zone Multi-Color illuminated full size keyboard with numeric pad |
| Webcam | Built-in 2.0M FHD Video Camera with TNR |
| Style | Standard |
| Type | Gaming & Entertainment |
| Usage | Consumer |
| AC Adapter/Charger | Full Range 180W AC Adapter, AC-in 100~240V, 50~60Hz, DC output 20V, 9A |
| Battery | Embedded 4 cells Polymer battery pack 80WH |
Questions about this item
Will the 16" QHD+ 300Hz panel run at its native 2560x1600 resolution when connected to an older external monitor over HDMI?
The built-in display operates at 2560x1600 and 300Hz regardless of the external monitor; the HDMI output will negotiate the best common resolution and refresh rate supported by that older screen.
How can I verify the RTX 5060 is using its 8 GB GDDR7 memory and the CPU is hitting 5.1 GHz under load?
Open Task Manager or GPU-Z to confirm 8 GB GDDR7 is reported for the RTX 5060, and watch the CPU frequency climb to 5.1 GHz during a sustained benchmark or heavy workload.
Does the box include a second 2 TB M.2 PCIe 4.0 x4 NVMe SSD so the total reaches 4 TB, or must I buy one separately?
The laptop ships with 4 TB already configured as 2 x 2 TB M.2 PCIe 4.0 x4 NVMe SSDs, so no additional drive is required for that capacity.
