Evoc
Evoc X580WNT-G gaming laptop 18" QHD+ 240Hz Ultra 9 290HX Plus RTX 5090 16 GB DDR5 1 TB NVMe
An 18-inch QHD+ 240Hz gaming laptop with a 24-core Ultra 9 290HX Plus CPU, RTX 5090 graphics, 16 GB DDR5 memory and a 1 TB NVMe SSD
- ColorBlack
- Operating SystemWindows 11 Pro
- CPUIntel® Core Ultra 9-290HX Plus
- Screen18" QHD+
- Memory16GB
- Storage1 TB M.2 PCIe 4.0 x4 NVMe SSD
- 18" QHD+ 240 Hz display for smooth competitive gaming
- Intel Core Ultra 9 290HX Plus 24-core CPU up to 5.5 GHz for heavy workloads
- NVIDIA GeForce RTX 5090 with 24 GB GDDR7 for high-fidelity graphics
- 16 GB DDR5 5600 MHz dual-channel memory for responsive multitasking
- 1 TB PCIe 4.0 NVMe SSD for fast boot and load times
18" QHD+ 240Hz gaming laptop
The 18 inch display runs at 2560 by 1600 pixels with a 240 Hz refresh rate, driven by an RTX 5090 graphics card with 24 GB GDDR7 memory. An Intel Core Ultra 9 290HX Plus processor provides 24 cores and a maximum turbo frequency of 5.5 GHz. The system ships with Windows 11 Pro and 16 GB of DDR5 5600 MHz memory in dual channel.
PCIe 4.0 x4 NVMe storage limit
The 1 TB M.2 drive uses a PCIe 4.0 x4 NVMe interface, so sequential throughput is bounded by that generation's lane speed. The graphics card connects internally through the same PCIe fabric, sharing total platform bandwidth with the SSD and other peripherals. No faster storage interface is present in this chassis.
Factory-applied Gelid GC Extreme thermal paste
HIDevolution applies Gelid GC Extreme on the CPU and GPU before shipment, replacing the standard compound to lower core temperatures under load. The laptop arrives with the latest stable BIOS and drivers installed after burn-in stress testing. Memory and storage upgrades later require removing the bottom case screws and may void the custom thermal work if the heatsinks are disturbed.
Highlights
- 18" QHD+ 240 Hz display for smooth competitive gaming
- Intel Core Ultra 9 290HX Plus 24-core CPU up to 5.5 GHz for heavy workloads
- NVIDIA GeForce RTX 5090 with 24 GB GDDR7 for high-fidelity graphics
- 16 GB DDR5 5600 MHz dual-channel memory for responsive multitasking
- 1 TB PCIe 4.0 NVMe SSD for fast boot and load times
Specifications
| Brand | EVOC |
|---|---|
| Series | X580WNT-G |
| Model | EVOC X5802C (X580WNT-G) |
| Part Number | EV-X5802C-HID1 |
| Color | Black |
| Operating System | Windows 11 Pro |
| CPU | Intel® Core Ultra 9-290HX Plus |
| Screen | 18" QHD+ |
| Memory | 16GB |
| Storage | 1 TB M.2 PCIe 4.0 x4 NVMe SSD |
| Graphics Card | NVIDIA® GeForce® RTX™ 5090 |
| Video Memory | 24GB |
| Dimensions (W x D x H) | 15.59” (w) x 10.95” (d) x 0.98” (h) |
| Weight | 7.25 lbs. |
| Other Features | Metal top, palm rest and bottom case, Light module, FlexiCharger, Intel Dynamic Tuning Technology |
| CPU Type | Intel Core Ultra 9 (Series 2) |
| Processor Name | Intel Core Ultra 9 290HX Plus |
| Number of Cores | 24-core Processor |
| Core Name | Arrow Lake |
| Turbo Frequency | Max Turbo Frequency 5.5 GHz |
| CPU L3 Cache | 36 MB |
| Chipset | Intel® |
| Screen Size | 18.0" |
| Touchscreen | No |
| Display Type | QHD+ |
| Resolution | 2560 x 1600 |
| Panel | QHD+ |
| Refresh Rate | 240Hz |
| Display Features | Wide View Angle, G-Sync Display, Matte Finished |
| GPU/VPU | GeForce RTX 5090 Laptop GPU |
| Graphic Type | Dedicated Card |
| SSD | 1 TB |
| HDD | No |
| Storage Spec | 1 TB M.2 PCIe 4.0 x4 NVMe SSD |
| Memory Speed | DDR5 5600MHz |
| Memory Spec | 8 GB x 2 |
| Memory Type | 2 x SO-DIMM |
| Memory Slot (Total) | 4 |
| Memory Slot (Available) | 2 |
| Max Memory Supported | 256GB |
| LAN | Built-in Killer 2.5 Gigabit Ethernet LAN |
| WLAN | Intel Wireless Wi-Fi 7 BE200 |
| WiFi Generation | Wi-Fi 7 |
| Bluetooth | Yes |
| USB | 2x USB 3.2 Gen 2 Ports (Type A, with 1 x powered USB, AC/DC) |
| Thunderbolt | 1x Thunderbolt 5 combo Port with Power Delivery DC in (Type C), 1x Thunderbolt 5 Port (Type C) |
| HDMI | 1x HDMI output Port (with HDCP) |
| Audio Ports | 1x 2-in-1 Audio Jack (Headphone / Microphone) |
| Audio | High Definition audio interface |
| Speaker | Built-in two 1W Tweeter speakers, Built-in two 2W Mid-range speakers, Built-in one 4W Subwoofer speaker |
| Touchpad | Built in Click pad with Microsoft PTP multi-gesture and scrolling function |
| Keyboard | Multi languages LED Per Key full color illuminated full size isolated keyboard with numeric pad |
| Webcam | Built-in 5.0M Hello Camer with TNR (Temporal Noise Reduction) |
| Card Reader | Micro SD Push-Push Card reader |
| Style | Standard |
| Type | Gaming & Entertainment |
| Usage | Consumer |
| AC Adapter/Charger | Full Range 330W AC Adapter, AC-in 100~240V, 50~60Hz, DC output 20V, 16.5A |
| Battery | Embedded 8 cells Polymer battery pack 98WH |
Questions about this item
Should I pick the 16 GB DDR5 configuration or add more memory for the 24-core Ultra 9 290HX Plus?
The 16 GB dual-channel kit at 5600 MHz feeds the 24-core processor well for gaming and heavy multitasking; extra modules only help if you run virtual machines or large content-creation projects.
What does the 5.5 GHz max turbo on the Ultra 9 290HX Plus deliver inside this 18-inch chassis?
The 5.5 GHz peak clock lets the 24-core CPU hit high single-thread speeds in bursts, while Gelid GC Extreme paste and the metal case keep thermals in check during sustained loads.
How fast is the 1 TB PCIe 4.0 x4 NVMe drive in real use?
The PCIe 4.0 x4 interface caps sequential throughput near 7 GB/s, so game loads, boot and large file transfers run at the drive’s rated speed without bottleneck.
