Square black 92 mm frame fan with clear blades and four corner holes

Fans

Fans AUB0912HHSize 92×92×25mm 12V 3150 RPM case fan

SKU CH-QRV1-5KYF6 MPN AUB0912HHSize

A 92 mm square case fan spins at 3150 RPM with double ball bearings for 35,000-hour life at 38.0 dB(A)

  • 12 V operation with a 7.0–13.6 V input range
  • 3150 RPM speed delivers 98.4 m³/h maximum airflow
  • Double ball bearing rated for 35000 hours L10 life at 25 °C
  • 0 dB(A) noise level at full speed
  • Compact 92 × 92 × 25 mm frame fits standard 92 mm mounts

Compact 92 mm Axial Fan

The Fans AUB0912HHSize is a 92 × 92 × 25 mm DC axial fan built for chassis airflow in industrial, medical and embedded systems. It runs on 12 V DC with a 7.0 V to 13.6 V input range and draws 0.40 A at rated load. The double ball bearing and PBT housing suit continuous-duty environments.

Sustained-Load Thermal Behaviour

At 3 150 rpm the fan delivers 98.4 m³/h against a minimum static pressure of 55 Pa while emitting 38.0 dB(A). The L10 life rating is 35 000 hours at 25 °C across an operating span of –10 °C to 70 °C. Glass-fibre reinforced blades and maintenance-free bearings keep output stable during extended operation.

Voltage-Window Compatibility Check

The decisive parameter is the 7.0 V to 13.6 V supply window; any rail outside this range will prevent start-up or exceed the motor limits. Buyers who need a wider input range or a different form factor cannot use this model.

Highlights

  • 12 V operation with a 7.0–13.6 V input range
  • 3150 RPM speed delivers 98.4 m³/h maximum airflow
  • Double ball bearing rated for 35000 hours L10 life at 25 °C
  • 0 dB(A) noise level at full speed
  • Compact 92 × 92 × 25 mm frame fits standard 92 mm mounts

Specifications

No published specifications for this item yet.

Questions about this item

How loud is the AUB0912HHSize 92 mm fan at 3150 RPM under full load?

The fan produces 38.0 dB(A) at its rated speed of 3150 RPM with a maximum airflow of 98.4 m³/h.

What power connector and voltage range does the AUB0912HHSize require?

It runs on DC 12 V (range 7.0 V–13.6 V) and draws 0.40 A, compatible with standard 3-pin or 4-pin motherboard headers.

Will the 92 × 92 × 25 mm frame and counter-clockwise exhaust fit my existing 92 mm mounting points?

Yes, the 92 mm square frame matches standard 92 mm holes and the airflow discharges from the bracket side.
