Square 92 mm metal fan in black iron frame, 38 mm thick, double ball bearing, 230 V AC power leads visible

Fans

Fans UF-92AM23BTH 92mm liquid cooler

SKU CH-XRAM-YH0D5

A 92 mm liquid-cooling fan delivers 1.25–1.45 m³/min airflow at 2700–3200 RPM with 37–42 dB noise and a 50,000-hour L10 life

  • 92 mm footprint fits tight chassis spaces
  • 230 V AC supply plugs straight into mains power
  • Double ball bearing rated for 50000 hours at 25 °C
  • 37 dB low-speed noise keeps work areas quiet
  • CE UL TUV certifications available for compliance needs

Compact 92 mm liquid cooler for industrial cooling

This 92 mm liquid cooler is built for industrial and embedded applications such as medical equipment, rail vehicles, drives and new-energy vehicles. It operates on 230 V AC at 50/60 Hz and fits a 92×92×38 mm footprint, making it suitable for tight enclosures that need reliable liquid cooling.

12 W input with 51 CFM airflow

At 230 V the unit draws 0.06 A for 11 W input, delivering 1.45 m³/min (51 CFM) at 3200 RPM with 42 dB noise. At the lower speed it runs at 0.07 A, 12 W, 1.25 m³/min (44 CFM) at 2700 RPM and 37 dB. The double ball bearing is rated for 50 000 hours L10 life at 25 °C across a -20 °C to 90 °C range.

Replaces noisy sleeve-bearing fans in 92 mm mounts

The iron frame and metal blades with maintenance-free double ball bearings eliminate the wear and rattle of sleeve-bearing axial fans in the same 92 mm cut-out. The jump is worth it when continuous 230 V operation, long bearing life and CE/UL/TUV certifiable safety are required for industrial or transport duty.

Highlights

  • 92 mm footprint fits tight chassis spaces
  • 230 V AC supply plugs straight into mains power
  • Double ball bearing rated for 50000 hours at 25 °C
  • 37 dB low-speed noise keeps work areas quiet
  • CE UL TUV certifications available for compliance needs

Specifications

No published specifications for this item yet.

Questions about this item

Will the 92 mm frame fit the mounting holes on my existing radiator?

The fan measures 92 mm by 92 mm by 38 mm, so it matches standard 92 mm mounting patterns.

How can I verify the fan is running at the rated 2700 or 3200 RPM after installation?

Connect the tachometer lead to a motherboard header or fan controller and confirm the reported speed matches 2700 RPM at 50 Hz or 3200 RPM at 60 Hz.

Does the package include mounting screws or a power cable, or must I buy them separately?

The unit ships as the bare fan with an iron frame and metal blades; mounting hardware and a mains lead are not included.
