Black copper radiator, 240 mm length, 28 mm thick, 16 FPI fin density

FormulaMod

FormulaMod 240 mm Copper Radiator 28 mm Thick Black 16 FPI

SKU CH-FPE2-44660

A 240 mm copper radiator with 28 mm thickness, 16 FPI fin density and 165 ml capacity for custom liquid-cooling loops

  • TypeRadiator
  • ColorBlack
  • Copper, brass and stainless steel construction resists corrosion
  • 28 mm thick core increases coolant capacity to 165 ml
  • 16 fins per inch maximise heat dissipation surface area
  • 6 mm length fits standard 240 mm dual-fan mounting points
  • Tested to 0.32 bar pressure for leak-free operation

240 mm Copper Radiator 16 FPI

This 240 mm copper radiator uses a brass and stainless-steel construction with a black finish. It measures 275.6 by 121.4 by 28 mm and holds 165 ml of coolant. The core runs at 16 fins per inch and is tested to 0.32 bar. It fits custom loops that need high-density heat rejection.

Best For Dense 240 mm Loops

Builders assembling a custom water-cooling loop with space for a 240 mm radiator and G1/4 inch threads will find this part matches those requirements. The 16 FPI density works well with moderate-to-high static-pressure fans. Loops that need a slimmer profile, a different port standard or a larger core surface should look elsewhere.

16 Fins Per Inch Fin Density

The 16 fins-per-inch spacing is the specification that determines thermal performance and fan pairing. It sets the airflow resistance and the heat-transfer area available in the 165 ml volume. Match your fan curves to this density to get the intended cooling results.

Highlights

  • Copper, brass and stainless steel construction resists corrosion
  • 28 mm thick core increases coolant capacity to 165 ml
  • 16 fins per inch maximise heat dissipation surface area
  • 6 mm length fits standard 240 mm dual-fan mounting points
  • Tested to 0.32 bar pressure for leak-free operation

Specifications

TypeRadiator
ColorBlack

Questions about this item

What fittings and fans are required for the G1/4″ ports on this 240 mm radiator?

The radiator uses standard G1/4″ threads, so you need matching fittings and two fans that fit the 121.4 mm mounting spacing.

Will the 28 mm thickness and 16 FPI fin density restrict airflow if I keep my current low-RPM fans?

At 28 mm thick with 16 fins per inch the core is moderately dense; low-RPM fans will work but expect higher static pressure demand than a thinner radiator.

How can I confirm the loop holds pressure after installing this copper radiator?

Pressurise the system to the tested 0.32 bar and watch for any pressure drop or leaks at the G1/4″ connections.
