Rectangular green circuit board with silver sockets and black heat sinks

GIGABYTE

GIGABYTE A520M DS3H AC AMD motherboard

SKU CH-EX64-XSZJT

Socket AM4 board for Ryzen 5000, 4000 and 3000 series CPUs with four DDR4 slots up to 128 GB, one M.2 slot, 7.1 audio, Wi-Fi 802.11 ac, Bluetooth 4.2 and GbE LAN

  • CPU Socket TypeAM4
  • CPU TypeSupports AMD Ryzen 5000 Series / 5000 G-Series / 4000 G-Seri
  • ChipsetAMD A520
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardDDR4 4733(OC) / 4600(OC) / 4400(OC) / 4000(OC) / 3600(OC) /
  • Maximum Memory Supported128GB
  • Supports AMD Ryzen 5000, 4000 and 3000 series processors on AM4 socket
  • Dual-channel DDR4 memory up to 128 GB across four 288-pin DIMM slots
  • 5+3 phase pure digital VRM with low RDS(on) MOSFETs for stable power delivery
  • Single M.2 socket 3 M-key connector for SATA and PCIe 3.0 x4/x2 SSDs
  • Intel Wi-Fi 802.11ac, Bluetooth 4.2 and Gigabit LAN with bandwidth management

AM4 Socket for Ryzen 5000 and 3000 Series

This motherboard uses the AMD A520 chipset and AM4 socket to support Ryzen 5000 Series, 5000 G-Series, 4000 G-Series and 3000 Series processors. It targets builders who want a straightforward platform for mainstream desktop CPUs without overclocking headroom. The 5+3 phase digital VRM uses low RDS(on) MOSFETs to deliver stable power for daily workloads.

128GB DDR4 Dual Channel and Single M.2

Four 288-pin slots accept unbuffered DDR4 up to 128GB in dual-channel mode with speeds ranging from 2133 to 4733(OC). A single M.2 socket 3 M-key slot handles 2242, 2260 and 2280 drives with both SATA and PCIe 3.0 x4 or x2 modes. Four SATA 6Gb/s ports add bulk storage and support RAID 0, 1 and 10.

Intel Wi-Fi 802.11ac, Bluetooth 4.2 and 8118 LAN

The rear I/O includes HDMI, DVI-D and DisplayPort for multi-monitor setups driven by APUs, plus four USB 3.2 Gen 1 ports, two USB 2.0 ports, PS/2, three audio jacks for 7.1-channel output, two SMA antenna connectors and a Realtek 8118 Gigabit LAN port. Onboard Intel wireless provides 802.11ac and Bluetooth 4.2. RGB Fusion 2.0 headers support addressable and standard LED strips while Smart Fan 5 offers hybrid headers with fan stop.

Highlights

  • Supports AMD Ryzen 5000, 4000 and 3000 series processors on AM4 socket
  • Dual-channel DDR4 memory up to 128 GB across four 288-pin DIMM slots
  • 5+3 phase pure digital VRM with low RDS(on) MOSFETs for stable power delivery
  • Single M.2 socket 3 M-key connector for SATA and PCIe 3.0 x4/x2 SSDs
  • Intel Wi-Fi 802.11ac, Bluetooth 4.2 and Gigabit LAN with bandwidth management

Specifications

BrandGIGABYTE
ModelA520M DS3H AC
CPU Socket TypeAM4
CPU TypeSupports AMD Ryzen 5000 Series / 5000 G-Series / 4000 G-Series / 3000 Series Processors
ChipsetAMD A520
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 4733(OC) / 4600(OC) / 4400(OC) / 4000(OC) / 3600(OC) / 3333(OC) / 3200 / 2933 / 2667 / 2400 / 2133 (3rd Gen AMD Ryzen with Radeon Graphics processors)
DDR4 4400(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3400(OC) / 3333(OC) / 3300(OC) / 3200 / 2933 / 2667 / 2400 / 2133 (AMD Ryzen 5000 G-series / Ryzen 5000 Series/ 3rd Generation AMD Ryzen processors)
Maximum Memory Supported128GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16
* Actual support may vary by CPU.
PCI Express x12 x PCI Express 3.0 x1
Serial ATA (SATA)4 x SATA 6Gb/s
M.21 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)
SATA RAID0/1/10
Onboard Video ChipsetSupported only by CPU with integrated graphic
Audio Channels7.1 Channels
* To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website for details on configuring the audio software.
Max LAN Speed1Gbps
Wireless LANWi-Fi 802.11 ac
BluetoothBluetooth 4.2
Back I/O Ports1 x PS/2 keyboard/mouse port
1 x DVI-D port
1 x DisplayPort
1 x HDMI port
2 x SMA antenna connectors (1T1R)
4 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
Onboard USB1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
Other Connectors1 x CPU fan header
2 x system fan headers
1 x addressable LED strip header
1 x RGB LED strip header
1 x front panel header
1 x front panel audio header
1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
1 x serial port header
1 x Clear CMOS jumper
1 x Q-Flash Plus button
* All fan headers are subject to support AIO_Pump, Pump and high performance fan with the capability of delivering up to 2A/12V @ 24W.
Form FactorMicro ATX
LED LightingRGB
Dimensions (W x L)9.6" x 9.6"
Power Pin1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector

Questions about this item

Will my existing DDR4 memory rated at 3200 MHz run at its rated speed on the A520M DS3H AC?

The board supports DDR4 up to 3200 MHz natively and up to 4733 MHz with overclocking using 3rd Gen Ryzen processors, so 3200 MHz modules will operate at their rated speed without overclocking.

How can I verify that the single M.2 slot is running at PCIe 3.0 x4 after I install an NVMe drive?

Check the BIOS or operating-system device manager; the slot is wired for PCIe 3.0 x4 and will report that link width when a compatible NVMe SSD is installed.

Does the package include the two SMA antennas needed for the 802.11 ac Wi-Fi and Bluetooth 4.2, or must I buy them separately?

The supplier description confirms an antenna is included, so the two SMA antennas required for Wi-Fi and Bluetooth are in the box.
