Green micro-ATX motherboard with silver heatsinks and four black DDR5 slots

GIGABYTE

GIGABYTE A620M GAMING X AMD motherboard

SKU CH-EMZD-FZK01

Supports Ryzen 7000 processors on AM5 with four DDR5 slots up to 128 GB, one PCIe 4.0 M.2, four SATA ports and Realtek 1 GbE LAN

  • CPU Socket TypeAM5
  • CPU TypeRyzen 7000 Series
  • ChipsetAMD A620
  • Number of Memory Slots4x288pin (DDR5)
  • Memory StandardSupport for DDR5 6400(OC)/6200(OC)/6000(OC)/5600(OC)/5200/48
  • Maximum Memory Supported128GB
  • Supports AMD Ryzen 7000 Series processors on AM5 socket
  • Four DDR5 DIMM slots accept up to 128 GB memory with AMD EXPO and Intel XMP support
  • Twin 8+2+1 phase digital VRM with eight-layer 2X copper PCB delivers stable power
  • PCIe 4.0 x16 and M.2 slots feature EZ-Latch Plus screwless quick-release design
  • Realtek 1 GbE LAN plus RGB Fusion lighting control and Q-Flash Plus BIOS update without CPU

Socket AM5 and Ryzen 7000 support

This motherboard uses the AMD A620 chipset and the AM5 LGA 1718 socket to support AMD Ryzen 7000 Series processors. It is built in a micro-ATX form factor for compact system builds. The board targets users who want a current-generation AMD platform with DDR5 memory and PCIe 4.0 connectivity in a smaller chassis.

DDR5 memory up to 128 GB and 6400 MT/s

Four 288-pin DDR5 slots accept up to 128 GB of system memory with a maximum single DIMM capacity of 32 GB. Supported speeds include 6400, 6200, 6000, 5600, 5200, 4800 and 4400 MT/s when using overclocked modules. Dual-channel architecture and AMD EXPO profiles provide the single specification that determines whether this board matches your memory kit.

8+2+1 digital VRM phases on an 8-layer 2X copper PCB

The Twin 8+2+1 phase digital VRM solution is paired with an 8-layer PCB using double copper thickness to handle sustained current delivery. An M.2 Thermal Guard covers the PCIe 4.0 x4 M.2 slot to maintain SSD performance during prolonged workloads. Smart Fan 6 headers allow fan curves tuned for continuous thermal load rather than brief bursts.

Highlights

  • Supports AMD Ryzen 7000 Series processors on AM5 socket
  • Four DDR5 DIMM slots accept up to 128 GB memory with AMD EXPO and Intel XMP support
  • Twin 8+2+1 phase digital VRM with eight-layer 2X copper PCB delivers stable power
  • PCIe 4.0 x16 and M.2 slots feature EZ-Latch Plus screwless quick-release design
  • Realtek 1 GbE LAN plus RGB Fusion lighting control and Q-Flash Plus BIOS update without CPU

Specifications

BrandGIGABYTE
ModelA620M GAMING X
CPU Socket TypeAM5
CPU TypeRyzen 7000 Series
ChipsetAMD A620
Number of Memory Slots4x288pin (DDR5)
Memory StandardSupport for DDR5 6400(OC)/6200(OC)/6000(OC)/5600(OC)/5200/4800/4400 MT/s memory modules
Maximum Memory Supported128GB
Channel SupportedDual Channel
ECC SupportedNon-ECC
Buffer SupportedUn-buffered
Memory Feature4 x DDR5 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
Dual channel memory architecture
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules
PCI Express 4.0 x161 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
PCI Express x11 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Serial ATA (SATA)4 x SATA 6Gb/s
M.21 x M.2 connector (Socket 3, M key, type 2580 PCIe 4.0 x4/x2 SSD support)
SATA RAIDRAID 0, RAID 1, and RAID 10 support for SATA storage devices
Audio ChipsetRealtek Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
Audio Channels7.1 Channels
LAN ChipsetRealtek GbE LAN chip (1 Gbps/100 Mbps)
Max LAN Speed1Gbps
Back I/O Ports1 x PS/2 keyboard/mouse port
1 x USB Type-C port, with USB 3.2 Gen 1 support
1 x USB 3.2 Gen 2 Type-A port (red)
2 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x HDMI port
1 x DisplayPort
1 x Q-Flash Plus button
1 x RJ-45 port
3 x audio jacks
Onboard USB1 x USB Type-C header, with USB 3.2 Gen 1 support
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
Other Connectors1 x CPU fan header
2 x system fan headers
1 x addressable LED strip header
1 x RGB LED strip header
1 x M.2 Socket 3 connector
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x Clear CMOS jumper
Form FactorMicro ATX
Dimensions (W x L)9.6" x 9.6"
Power Pin1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
Windows 11Supported
FeaturesSupport for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
Support for Q-Flash
Support for Q-Flash Plus

Questions about this item

Will my Ryzen 7000 series processor fit this AM5 socket?

Yes, the AM5 socket is designed for Ryzen 7000 series processors with 1718 contact pins.

Can I install four DDR5 modules and reach 128 GB total capacity?

The board has four 288-pin DDR5 slots supporting up to 32 GB per module for a maximum of 128 GB in dual-channel mode.

Does the M.2 slot support PCIe 4.0 x4 speeds for a fast SSD?

The single M.2 connector is keyed for type 2580 drives and runs at PCIe 4.0 x4 or x2.
