Green micro ATX motherboard with silver LGA 1151 socket and two black DDR4 slots

GIGABYTE

GIGABYTE B360M D2V Intel Motherboard LGA 1151 DDR4 Micro ATX

SKU CH-8AR7-8N6E5

Micro-ATX board for LGA 1151 Intel CPUs with dual-channel DDR4 up to 32 GB and 2.0-channel audio

  • CPU Socket TypeLGA 1151
  • CPU TypeIntel Core 9th Gen (LGA 1151)
  • ChipsetIntel B360
  • Form FactorMicro ATX
  • Supports 9th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • Micro-ATX form factor fits compact builds
  • Passive B360 chipset cooling runs silently
  • PC health monitoring tracks CPU, fan, temperature and voltage

Micro ATX board for Intel LGA 1151

The Gigabyte B360M D2V is a micro ATX motherboard built around the Intel B360 chipset and the LGA 1151 socket. It supports Intel Core i3, i5, i7 and Pentium processors from the 9th generation. The board uses passive chipset cooling and provides 2.0 channel audio output. It is intended for compact desktop builds that do not require overclocking features.

Suited for basic desktop builds.

This motherboard suits builders assembling office or home PCs with a single processor and up to 32 GB of system memory. It offers two DDR4 DIMM slots running in dual-channel mode at speeds up to 2666 MHz. Buyers who need four memory slots, larger total memory capacity or multi-processor support should look at a different platform.

Two DDR4 slots with 32 GB maximum

The board provides exactly two DDR4 DIMM slots supporting unbuffered non-ECC modules at 2133, 2400 and 2666 MHz. Maximum supported capacity is 32 GB using 16 GB modules. This memory limit is the key specification that determines whether the board fits the planned system.

Highlights

  • Supports 9th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • Micro-ATX form factor fits compact builds
  • Passive B360 chipset cooling runs silently
  • PC health monitoring tracks CPU, fan, temperature and voltage

Specifications

CPU Socket TypeLGA 1151
CPU TypeIntel Core 9th Gen (LGA 1151)
ChipsetIntel B360
Form FactorMicro ATX

Questions about this item

How do I confirm the board is working after I install a CPU and RAM?

Power on the system and watch for the POST screen; the PC health monitoring will report CPU temperature, fan speed and voltage readings if the hardware is initialising correctly.

What comes in the box and what must I source separately?

The motherboard itself is supplied; you will need to provide an LGA 1151 processor, DDR4 DIMMs (up to 32 GB total), a power supply, storage, and a chassis.

Which memory speed should I choose for this board?

The board supports DDR4 at 2666, 2400 and 2133 MHz; pick the highest speed your budget allows, up to the 32 GB maximum across the two DIMM slots.
