Green Micro ATX motherboard with silver CPU socket and black DIMM slots

GIGABYTE

GIGABYTE B360M D2V LGA 1151 Intel B360 DDR4 32GB Micro ATX motherboard

SKU CH-6F0Q-XPEX7

Micro-ATX board for LGA 1151 CPUs with Intel B360 chipset, two DDR4 slots up to 32 GB, one PCIe x16 slot, six SATA ports, one M.2 socket, Realtek GbE LAN and 7.1-channel audio

  • CPU Socket TypeLGA 1151
  • CPU Type1. Support LGA1151 slot - Intel 9th and 8th generation proce
  • ChipsetIntel B360
  • Maximum Memory Supported32GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID1XM.2 interface, 6xSATA III interface
  • Supports 8th and 9th Gen Intel Core i7, i5, i3, Pentium and Celeron CPUs via LGA 1151 socket
  • Up to 32GB DDR4 memory across two DIMM slots for responsive multitasking
  • Realtek ALC887 audio codec delivers 7.1 channel high-definition sound
  • Realtek Gigabit LAN provides 10/100/1000 Mbit wired network connectivity
  • Micro ATX form factor at 22.6 x 18.5 cm fits compact chassis builds

Socket and generation

This micro-ATX board fits Intel 8th and 9th generation Core i7, i5, i3, Pentium and Celeron processors in the LGA 1151 socket. The Intel B360 chipset handles platform duties without overclocking features. It suits office builds or budget gaming rigs that do not need Z-series flexibility.

Memory capacity and layout

Two DDR4 DIMM slots support up to 32 GB of system memory in dual-channel mode. Populating both slots gives the highest bandwidth for integrated graphics or discrete cards. The 32 GB ceiling matches the chipset specification and cannot be exceeded.

Thermals, noise and power

The board draws modest power for its VRM and chipset, running cool under typical desktop loads. No active cooling is fitted, so system airflow alone keeps temperatures in check. Acoustic output depends entirely on the case and CPU cooler chosen by the builder.

Highlights

  • Supports 8th and 9th Gen Intel Core i7, i5, i3, Pentium and Celeron CPUs via LGA 1151 socket
  • Up to 32GB DDR4 memory across two DIMM slots for responsive multitasking
  • Realtek ALC887 audio codec delivers 7.1 channel high-definition sound
  • Realtek Gigabit LAN provides 10/100/1000 Mbit wired network connectivity
  • Micro ATX form factor at 22.6 x 18.5 cm fits compact chassis builds

Specifications

BrandGIGABYTE
SeriesGIGABYTE B360M D2V
ModelGIGABYTE B360M D2V
CPU Socket TypeLGA 1151
CPU Type1. Support LGA1151 slot - Intel 9th and 8th generation processors: Intel Core ™ i7 processor/Intel Core ™ i5 processor/Intel Core ™ i3 processor/Intel Pentium processor/Intel Celeron processor
2. L3 cache depends on CPU
ChipsetIntel B360
Maximum Memory Supported32GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications
To maximize the performance of the graphics card, it is necessary to install it in the PCIEX16 slot when installing a graphics card.
2 PCI Express x1 slots
All PCI Express slots support PCI Express 3.0.
3. 1 PCI slot
SATA RAID1XM.2 interface, 6xSATA III interface
Audio Chipset1. Built-in Realtek ALC887 chip ®
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
To activate the 7.1 channel audio output, you must use the front panel audio output of the HD (High Definition, High Fax) audio module and select the multi-channel audio function through the audio software.
LAN ChipsetBuilt-in Realtek GbE network chip (10/100/1000 Mbit)
Onboard USBBuilt-in chipset:
1.6 USB 3.1 Gen 1 ports (4 on the rear panel, 2 to be connected from the USB socket in the main board via cable)
2.6 USB 2.0/1 ports (2 on the rear panel, 4 to be connected from the USB socket in the main board via cable)

Questions about this item

What does the 32 GB DDR4 limit mean when I populate both slots?

The board has two DDR4 DIMM slots and supports a total of 32 GB, so you can install two 16 GB modules to reach the maximum capacity.

How does the single PCI Express x16 slot and the M.2 interface affect expansion?

The board provides one PCI Express x16 slot for a graphics card and one M.2 interface for storage; both run at the speeds defined by the Intel B360 chipset.

Will the 22.6 cm by 18.5 cm Micro ATX board fit in my chassis?

The board measures 22.6 cm by 18.5 cm and uses the standard Micro ATX mounting pattern, so it fits any case that supports Micro ATX motherboards.
