Green Micro ATX motherboard with silver heatsinks, black slots, rear I/O panel visible

GIGABYTE

GIGABYTE B360M D3H LGA 1151 (300 Series) Intel motherboard

SKU CH-PV5S-8WXAC

Micro-ATX board for 8th-generation Intel Core CPUs with four DDR4 slots, dual-channel memory up to 64 GB, two PCI Express 3.0 x16 slots, six SATA ports, one M.2 slot.

  • CPU Socket TypeLGA 1151 (300 Series)
  • CPU TypeCore i7 / i5 / i3 (8th Gen, LGA1151)
  • ChipsetIntel B360
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardDDR4 2666
  • Supports 8th Gen Intel Core i7, i5 and i3 CPUs with LGA 1151 (300 Series) socket
  • Four DDR4 slots accept up to 64 GB at 2666 MHz for fast multitasking
  • Two PCI Express 3.0 x16 slots plus one PCI Express x1 and one PCI slot for expansion
  • Six SATA 6 Gb/s ports and one M.2 connector provide ample storage connectivity
  • Realtek ALC892 7.1-channel audio and Intel GbE LAN deliver clear sound and wired networking

Micro-ATX Intel B360 board for 8th Gen CPUs

This motherboard uses the Intel B360 chipset and an LGA 1151 socket limited to 300 Series processors. It supports Core i7, i5, i3, Pentium and Celeron CPUs from the 8th Generation. The board fits a Micro-ATX chassis and provides four 288-pin DDR4 slots with a maximum capacity of 64 GB.

Suits builds staying on 8th Gen.

The platform suits users keeping an existing 8th Generation Intel CPU and needing a replacement board. It is not compatible with 6th or 7th Generation LGA 1151 processors, nor with newer Intel sockets. Buyers planning a current-generation system should choose a different motherboard.

Memory speed tied to CPU tier

DDR4 2666 operation requires an 8th Generation Core i7 or i5 processor; with other supported CPUs the memory runs at 2400 or 2133 MHz. This single rule decides whether the board can deliver the higher memory frequency.

Highlights

  • Supports 8th Gen Intel Core i7, i5 and i3 CPUs with LGA 1151 (300 Series) socket
  • Four DDR4 slots accept up to 64 GB at 2666 MHz for fast multitasking
  • Two PCI Express 3.0 x16 slots plus one PCI Express x1 and one PCI slot for expansion
  • Six SATA 6 Gb/s ports and one M.2 connector provide ample storage connectivity
  • Realtek ALC892 7.1-channel audio and Intel GbE LAN deliver clear sound and wired networking

Specifications

BrandGIGABYTE
ModelB360M D3H
CPU Socket TypeLGA 1151 (300 Series)
CPU TypeCore i7 / i5 / i3 (8th Gen, LGA1151)
ChipsetIntel B360
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 2666
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 3.0 x162 x PCI Express 3.0 x16
PCI Express x11 x PCI Express x1
PCI Slots1 x PCI Slot
Serial ATA (SATA)6 x SATA 6Gb/s
M.21 x M.2
Audio ChipsetRealtek ALC892
Audio Channels7.1 Channels
LAN ChipsetIntel GbE LAN
Max LAN Speed1Gbps
PS/21 x PS/2 keyboard/mouse port
Video PortsD-Sub + DVI
HDMI1 x HDMI
RJ451 x RJ45
DisplayPort1 x DisplayPort
USB 3.13 x USB 3.1
USB 1.1/2.02 x USB 2.0
USB Type-C1 x USB 3.1
Audio Ports6 Ports
Onboard USB2 x USB 3.1 + 4 x USB 2.0
Other Connectors1 x CPU fan header3 x system fan headers1 x RGB LED strip header1 x front panel header1 x front panel audio header1 x S/PDIF Out header1 x Trusted Platform Module (TPM) header (2x6-pin, for the GC-TPM2.0_S module only)1 x serial port header1 x parallel port header1 x Clear CMOS jumper
Form FactorMicro ATX
LED LightingRGB
Dimensions (W x L)9.6" x 9.1"
Power Pin24 Pin
FeaturesMulti-Graphics Technology:Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologiesI/O Controller:iTE I/O Controller ChipH/W Monitoring:Voltage detectionTemperature detectionFan speed detectionOverheating warningFan fail warningFan speed control* Whether the fan speed control function is supported will depend on the cooler you install.BIOS:2 x 128 Mbit flashUse of licensed AMI UEFI BIOSSupport for DualBIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0Unique Features:Support for APP Center* Available applications in APP Center may vary by motherboard model. Supported

Questions about this item

Will an 8th-generation Core i5 run 2666 MHz DDR4 on this board?

Yes, 2666 MHz is supported when an 8th-generation Core i7 or i5 processor is installed.

How many SATA 6 Gb/s drives can be connected?

Six SATA 6 Gb/s ports are available for hard drives or SSDs.

Does the board provide wired networking?

An Intel GbE LAN controller provides a 1 Gbps Ethernet connection.
