Green rectangular Micro ATX motherboard with silver CPU socket and black memory slots

GIGABYTE

GIGABYTE B365M D2V LGA 1151 Intel B365 DDR4 32GB Micro ATX motherboard

SKU CH-WK18-S90C0

Micro ATX Intel B365 board with LGA 1151 socket supports up to 32 GB DDR4 and offers six SATA ports plus one PCI Express x16 slot

  • CPU Socket TypeLGA 1151
  • CPU Type1. Support LGA1151 slot - 9th and 8th generation processors:
  • ChipsetIntel B365
  • Maximum Memory Supported32GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID1XM.2 interface, 6xSATA III interface
  • Supports 9th and 8th generation Intel Core processors with LGA 1151 socket
  • Intel B365 chipset provides stable platform for DDR4 memory up to 32GB
  • Micro ATX form factor measuring 22.6 by 18.5 cm fits compact builds
  • Realtek ALC887 audio codec delivers 7.1 channel high definition sound
  • Realtek Gigabit LAN controller offers 10, 100, 1000 Mbit network connectivity

GIGABYTE B365M D2V Micro ATX Motherboard

The GIGABYTE B365M D2V is a Micro ATX motherboard built around the Intel B365 chipset for LGA 1151 processors. It supports 8th and 9th generation Intel Core i9, i7, i5, i3, Pentium and Celeron CPUs. The board provides two DDR4 DIMM slots with a maximum capacity of 32GB. Its compact 22.6 x 18.5 cm form factor fits smaller chassis while retaining essential connectivity.

Best for budget LGA 1151 builds

This board suits builders assembling a cost-effective system using an 8th or 9th generation Intel processor and no more than two memory modules. It offers one PCI Express 3.0 x16 slot, two PCI Express 3.0 x1 slots, six SATA III ports and one M.2 interface for storage. Users needing four DDR4 slots, integrated Wi-Fi, or support for newer CPU generations should consider a different platform.

Two DDR4 slots limit total memory to 32GB

The board is equipped with only two DDR4 DIMM slots, capping the maximum installed memory at 32GB. This constraint determines whether the platform can meet a given workload’s memory requirements. Verify that 32GB across two modules satisfies the intended application before purchase.

Highlights

  • Supports 9th and 8th generation Intel Core processors with LGA 1151 socket
  • Intel B365 chipset provides stable platform for DDR4 memory up to 32GB
  • Micro ATX form factor measuring 22.6 by 18.5 cm fits compact builds
  • Realtek ALC887 audio codec delivers 7.1 channel high definition sound
  • Realtek Gigabit LAN controller offers 10, 100, 1000 Mbit network connectivity

Specifications

BrandGIGABYTE
SeriesGIGABYTE B365M D2V
ModelGIGABYTE B365M D2V
CPU Socket TypeLGA 1151
CPU Type1. Support LGA1151 slot - 9th and 8th generation processors: Intel ® Core ™ i9 processor/Intel ® Core ™ i7 processor/Intel ® Core ™ i5 processor/Intel ® Core ™ i3 processor/Intel ® Pentium ® processor/Intel ® Celeron ® processor
2. L3 cache depends on CPU
ChipsetIntel B365
Maximum Memory Supported32GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications
2 PCI Express x1 slots
All PCI Express slots support PCI Express 3.0.
SATA RAID1XM.2 interface, 6xSATA III interface
Audio Chipset1. Built-in Realtek ALC887 chip ®
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
LAN ChipsetBuilt-in Realtek GbE network chip (10/100/1000 Mbit)
Onboard USBBuilt-in chipset:
1.6 USB 3.1 Gen 1 interfaces (4 on the rear panel, 2 need to be connected from the USB interface in the main board via cable)
2.6 USB 2.0 interfaces (2 on the rear panel, 4 need to be connected from the USB interface in the main board via cable)

Questions about this item

Does the GIGABYTE B365M D2V come with the I/O shield and SATA cable, and what must I buy separately?

The box contains the motherboard, one SATA cable and the chassis I/O back panel. You must supply the CPU, DDR4 memory, storage drives, power supply and case yourself.

Should I choose a 16 GB or 32 GB DDR4 kit for the two DIMM slots on this B365 board?

The board has two DDR4 DIMM slots and supports up to 32 GB total. A 32 GB kit (2 × 16 GB) fills both slots and reaches the limit; a 16 GB kit (2 × 8 GB) leaves room for a later upgrade.

What does the single PCI Express x16 slot running at 3.0 mean for a graphics card installed in this Micro ATX board?

The slot operates at PCI Express 3.0 x16, so a modern GPU will run at its full 3.0 bandwidth. The board also provides two x1 slots for add-in cards such as sound or networking.
