Rectangular green circuit board with silver ports and black slots

GIGABYTE

GIGABYTE B450M DS3H V2 AMD motherboard

SKU CH-6KZF-F2F2H

Micro-ATX AM4 board with four DDR4 slots up to 128 GB, PCIe Gen3 x4 M.2 for NVMe and SATA, HDMI and DVI outputs, and 8118 Gaming LAN

  • CPU Socket TypeAM4
  • CPU TypeA-Series / Ryzen Series
  • ChipsetAMD B450
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardDDR4 3600(OC) / 3466(OC) / 3200(OC) / 2933 / 2667 / 2400 / 2
  • Maximum Memory Supported128GB
  • Supports AMD Ryzen processors across generations with AM4 socket
  • Dual-channel DDR4 memory up to 128 GB capacity
  • PCIe Gen3 x4 M.2 slot for NVMe and SATA drives
  • 8118 Gaming LAN with bandwidth management built in
  • Smart Fan 5 uses five temperature sensors for cooling

Micro ATX AM4 motherboard

The GIGABYTE B450M DS3H V2 is a Micro ATX board built on the AMD B450 chipset for Socket AM4 processors. It accepts Ryzen 3rd Gen, 2nd Gen, 1st Gen and Athlon CPUs with Radeon Vega Graphics. Four 288-pin DDR4 slots support dual-channel memory up to 128 GB at speeds from 2133 to 3600 MHz (OC). The board provides HDMI and DVI-D outputs for integrated graphics.

Builders needing four DDR4 slots

This board suits builders who want four memory slots on a compact Micro ATX form factor and need HDMI or DVI-D for a display driven by the CPU graphics. It also provides an M.2 slot with PCIe Gen3 x4 and SATA modes for fast storage. Users who require more than four DIMM slots, additional video outputs beyond HDMI and DVI-D, or a different chipset feature set should consider other models.

Four DDR4 slots up to 128 GB

The key specification is the four 288-pin DDR4 slots supporting dual-channel memory up to 128 GB with speeds ranging from 2133 to 3600 MHz (OC). This capacity and slot count determine whether the board fits a memory-heavy build or a compact system that still needs maximum RAM headroom.

Highlights

  • Supports AMD Ryzen processors across generations with AM4 socket
  • Dual-channel DDR4 memory up to 128 GB capacity
  • PCIe Gen3 x4 M.2 slot for NVMe and SATA drives
  • 8118 Gaming LAN with bandwidth management built in
  • Smart Fan 5 uses five temperature sensors for cooling

Specifications

BrandGIGABYTE
ModelGIGABYTE B450M DS3H V2
CPU Socket TypeAM4
CPU TypeA-Series / Ryzen Series
ChipsetAMD B450
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 3600(OC) / 3466(OC) / 3200(OC) / 2933 / 2667 / 2400 / 2133
Maximum Memory Supported128GB
Channel SupportedDual Channel
ECC SupportedNon-ECC
Buffer SupportedUn-buffered

Questions about this item

What does the 3600 MHz DDR4 rating mean once the board is built?

3600 MHz is the highest overclocked memory speed the board can reach with compatible modules; standard speeds run at 2133, 2400, 2667, 2933 or 3200 MHz without overclocking

How does the PCIe Gen3 x4 M.2 slot limit drive performance?

The slot caps throughput at PCIe Gen3 x4 bandwidth, so NVMe drives faster than that will run at the slot's maximum instead of their rated peak

What physical space and mounting does the Micro ATX board need?

The board fits any Micro ATX or larger case with standard standoff holes and uses a 24-pin ATX plus 8-pin CPU power connector for installation
