Green micro ATX motherboard with silver LGA 1200 socket, two black DDR4 slots, and grey rear I/O shield

GIGABYTE

GIGABYTE B460M D2VX SI LGA 1200 Intel B460 DDR4 64GB Micro ATX motherboard

SKU CH-DANG-AQFYD

Micro ATX board for LGA 1200 CPUs with Intel B460 chipset, two DDR4 slots up to 64 GB, one PCIe x16 slot, two PCIe x1 slots, one M.2 and four SATA ports, Realtek ALC887 audio and GbE LAN

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports LGA1200 slot - 10th generation processor. Intel ® C
  • ChipsetIntel B460
  • Maximum Memory Supported64GB
  • PCI Slots1 PCI-Ex16 slot, supporting x16 operating specifications 2 P
  • SATA RAID1XM.2 interface, 4xSATA III interface
  • Supports 10th Gen Intel Core processors with LGA 1200 socket
  • Up to 64 GB DDR4 memory across two DIMM slots
  • Intel B460 chipset with PCIe 3.0 x16 and two x1 slots
  • Realtek ALC887 audio delivers 7.1 channel high-definition sound
  • Realtek GbE LAN provides 100/1000 Mbit wired networking

Socket LGA 1200 Micro ATX Board

The GIGABYTE B460M D2VX SI fits Intel 10th generation Core i9, i7, i5, i3, Pentium and Celeron processors in a compact 22.6 x 18.5 cm Micro ATX layout. Two DDR4 DIMM slots accept up to 64 GB of system memory. Builders who need more than two memory slots or a full-size ATX form factor should consider a larger board.

Sustained Load Behaviour

The Intel B460 chipset links the single PCIe 3.0 x16 slot, two PCIe 3.0 x1 slots, one M.2 interface and four SATA III ports without a secondary controller. Realtek ALC887 audio and Realtek GbE LAN (100/1000 Mbit) share the same chipset bandwidth during heavy I/O. Six USB 3.2 Gen 1 ports (four rear, two internal) and six USB 2.0 ports (two rear, four internal) provide steady peripheral throughput.

Installation Notes

The board arrives without original packaging; only the motherboard, one SATA cable and the rear I/O shield are included. Refurbished units show visible wear at 80–90 % cosmetic condition but pass full functional testing. Align the LGA 1200 socket carefully and verify cooler clearance against the compact 22.6 x 18.5 cm PCB before mounting.

Highlights

  • Supports 10th Gen Intel Core processors with LGA 1200 socket
  • Up to 64 GB DDR4 memory across two DIMM slots
  • Intel B460 chipset with PCIe 3.0 x16 and two x1 slots
  • Realtek ALC887 audio delivers 7.1 channel high-definition sound
  • Realtek GbE LAN provides 100/1000 Mbit wired networking

Specifications

BrandGIGABYTE
SeriesGIGABYTE B460M D2VX SI
ModelGIGABYTE B460M D2VX SI
CPU Socket TypeLGA 1200
CPU TypeSupports LGA1200 slot - 10th generation processor.
Intel ® Core ™ i9/Intel ® Core ™ i7/Intel ® Core ™ i5/Intel ® Core ™ i3/Intel ® Pentium ®/Intel ® Celeron ®
2. L3 cache memory depends on CPU
ChipsetIntel B460
Maximum Memory Supported64GB
PCI Slots1 PCI-Ex16 slot, supporting x16 operating specifications
2 PCI-Ex1 slots
(* All PCI-E slots support PCI-E3.0)
SATA RAID1XM.2 interface, 4xSATA III interface
Audio Chipset1. Integrated Realtek ® ALC887 chip
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 - Channel
To start the 7.1 channel audio output, you must enter the audio software and change the default value of "Advanced Device Settings > Playback Device". Please check the detailed setup instructions on the Gigabyte website.
LAN ChipsetIntegrated Realtek ® GbE network chips (100/1000 Mbit)
Onboard USBBased on chipset:
1.6 USB 3.2 Gen 1 ports (4 on the rear panel, 2 to be connected from the USB socket in the main board via cable)
2.6 USB 2.0/1 interfaces (2 on the rear panel, 4 need to be connected from the USB socket in the main board via the cable)

Questions about this item

How much power does the GIGABYTE B460M D2VX SI draw and how hot does it run under all-day load?

The board itself has no published TDP or thermal figures; power draw and temperature depend on the installed LGA 1200 CPU, the 64 GB DDR4 memory and the expansion cards you choose.

Which components must I already own for this Micro ATX board to function?

You need a 10th-generation Intel Core i9, i7, i5, i3, Pentium or Celeron processor for the LGA 1200 socket, up to 64 GB of DDR4 DIMMs across the two slots, a Micro ATX-compatible case, an ATX power supply and storage drives for the four SATA III ports or the single M.2 interface.

Will my existing SATA SSDs and hard drives work with the four SATA III ports on this B460 board?

Yes, the four SATA III interfaces accept standard 2.5-inch or 3.5-inch SATA drives, and the board also provides one M.2 slot for additional storage.
