Green micro-ATX motherboard with silver heatsinks and black PCB

GIGABYTE

GIGABYTE B460M DS3H LGA 1200 Intel motherboard

SKU CH-YMTK-YY9FD

Micro-ATX board for 10th Gen Intel Core CPUs with four DDR4 slots, one M.2 socket, six SATA ports, 7.1 audio and Gigabit LAN

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core processors Supports Intel Penti
  • ChipsetIntel B460
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardDDR4 2933 / 2666 / 2400 / 2133 (Intel Core i9 / i7 processor
  • Supports 10th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory across four DIMM slots up to 128 GB
  • Ultra-fast M.2 slot with PCIe 3.0 x4 and SATA support
  • Realtek ALC887 audio with 7.1 channels and noise guard
  • GbE LAN with 8118 bandwidth management and 15 KV surge protection

GIGABYTE B460M DS3H LGA 1200

This Micro-ATX board pairs an Intel B460 chipset with an LGA 1200 socket for 10th Gen Core, Pentium and Celeron CPUs. Four DDR4 slots support up to 128 GB in dual-channel mode, while a single PCIe 3.0 x16 slot handles discrete graphics. Six SATA 6Gb/s ports and one M.2 socket cover storage needs.

Compatibility checklist before ordering

Verify your processor is a supported 10th Gen Intel Core, Pentium or Celeron model for the LGA 1200 socket. Select DDR4 memory at 2933, 2666, 2400 or 2133 MT/s depending on the CPU tier. Ensure the case accepts a Micro-ATX form factor and that the power supply provides the required 24-pin and 8-pin CPU connectors.

Build quality and daily connectivity

Anti-sulfur resistors and 15 KV surge LAN protection guard the Realtek 8118 Gigabit controller. Audio uses a Realtek ALC887 codec with 7.1-channel output, high-quality capacitors and an LED-lit noise guard trace. RGB Fusion headers drive strips in seven colours, while Smart Fan 5 reads multiple sensors and hybrid headers stop fans at low load.

Highlights

  • Supports 10th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory across four DIMM slots up to 128 GB
  • Ultra-fast M.2 slot with PCIe 3.0 x4 and SATA support
  • Realtek ALC887 audio with 7.1 channels and noise guard
  • GbE LAN with 8118 bandwidth management and 15 KV surge protection

Specifications

BrandGIGABYTE
ModelB460M DS3H
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core processors
Supports Intel Pentium / Celeron processors
ChipsetIntel B460
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 2933 / 2666 / 2400 / 2133 (Intel Core i9 / i7 processors)
DDR4 2666 / 2400 / 2133 (Intel Core i5 / i3 / Pentium / Celeron processors)
Maximum Memory Supported128GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16
PCI Express x12 x PCI Express 3.0 x1
Serial ATA (SATA)6 x SATA 6Gb/s
M.21 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support)
Intel Optane ReadyYes
SATA RAID0/1/5/10
Audio ChipsetRealtek ALC887
Audio Channels7.1 Channels
* To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website for details on configuring the audio software.
LAN ChipsetRealtek GbE LAN chip
Max LAN Speed1Gbps
Back I/O Ports1 x PS/2 keyboard/mouse port
1 x D-Sub port
1 x DVI-D port
1 x HDMI port
4 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
Onboard USB1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
Other Connectors1 x CPU fan header
2 x system fan headers
2 x RGB LED strip headers
1 x front panel header
1 x front panel audio header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
2 x serial port headers
1 x Clear CMOS jumper
Windows 11Supported
Form FactorMicro ATX
LED LightingRGB
Dimensions (W x L)9.6" x 8.9"
Power Pin1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
FeaturesI/O Controller:
iTE I/O Controller Chip
H/W Monitoring:
Voltage detection
Temperature detection
Fan speed detection
Overheating warning
Fan fail warning
Fan speed control
* Whether the fan speed control function is supported will depend on the fan you install.
BIOS:
2 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
Support for DualBIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features:
Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications

Questions about this item

Will this board run a 10th Gen Intel Core i5 with integrated graphics?

Yes, the LGA 1200 socket and B460 chipset support 10th Gen Core i5 processors, and onboard video works when the CPU has integrated graphics.

What DDR4 speeds can I use with a Core i5 and four sticks?

With a Core i5 the board runs DDR4 at 2666, 2400 or 2133 MT/s across all four slots in dual-channel mode.

Can I add a PCIe 3.0 x4 M.2 SSD and still use all six SATA ports?

Yes, the single M.2 slot accepts 2242, 2260 or 2280 drives using PCIe x4 or SATA, and all six SATA 6Gb/s ports remain available.
