Green Micro ATX motherboard with silver CPU socket and four black DDR4 slots

GIGABYTE

GIGABYTE B560M DS3H LGA 1200 Intel motherboard

SKU CH-0CD6-A3C5V

Micro ATX board for 10th and 11th Gen Intel Core, Pentium and Celeron CPUs with four DDR4 slots up to 128 GB, one PCIe 4.0 x16 slot, two PCIe 3.0 x1 slots and six SATA ports

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 11th / 10th Gen Intel Core processors Supports Inte
  • ChipsetIntel B560
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardDDR4 3200 / 3000 / 2933 / 2666 / 2400 / 2133 MHz memory modu
  • Maximum Memory Supported128GB
  • Supports 11th and 10th Gen Intel Core CPUs via LGA 1200 socket
  • DDR4 memory up to 3200 MHz on four slots with 128 GB max capacity
  • PCI Express 4.0 x16 slot for modern graphics cards
  • Six SATA 6Gb/s ports for high-speed storage arrays
  • Micro ATX form factor fits compact builds

Socket LGA 1200 Micro ATX board

The GIGABYTE B560M DS3H fits 10th and 11th Gen Intel Core processors into a compact Micro ATX layout. It also accepts select Intel Pentium and Celeron chips that carry 4 MB Smart Cache. The Intel B560 chipset handles platform duties.

Dual-channel DDR4 with four slots

Four 288-pin slots support dual-channel DDR4 at speeds up to 3200 MHz with 11th Gen Core i5, i7 and i9 CPUs, or up to 2933 MHz with 10th Gen Core i7 and i9. Total memory capacity reaches 128 GB. One PCI Express 4.0 x16 slot and two PCI Express 3.0 x1 slots handle graphics and add-in cards. Six SATA 6Gb/s ports provide ample drive connectivity.

Passive chipset cooling and standard power phases

The B560 chipset runs without a fan, keeping noise low in typical workloads. Power delivery uses a conventional phase design suited to the supported processor range. The board draws only the power required by the installed CPU, memory and peripherals.

Highlights

  • Supports 11th and 10th Gen Intel Core CPUs via LGA 1200 socket
  • DDR4 memory up to 3200 MHz on four slots with 128 GB max capacity
  • PCI Express 4.0 x16 slot for modern graphics cards
  • Six SATA 6Gb/s ports for high-speed storage arrays
  • Micro ATX form factor fits compact builds

Specifications

BrandGIGABYTE
ModelB560M DS3H
CPU Socket TypeLGA 1200
CPU TypeSupports 11th / 10th Gen Intel Core processors
Supports Intel Pentium / Celeron processors*
* Limited to with 4MB Intel Smart Cache, Intel Celeron G5xx5 family.
ChipsetIntel B560
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 3200 / 3000 / 2933 / 2666 / 2400 / 2133 MHz memory modules (11th Gen Intel Core i9 / i7 / i5 processors)
DDR4 2933 / 2666 / 2400 / 2133 MHz memory modules (10th Gen Intel Core i9 / i7 processors)
DDR4 2666 / 2400 / 2133 MHz memory modules (10th Gen Intel Core i5 / i3 / Pentium / Celeron processors)
Maximum Memory Supported128GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express x16 slot, running at x16
(The PCIEX16 slot conforms to PCI Express 4.0 standard.) (Note)
PCI Express x12 x PCI Express x1 slots
(The PCIEX1 slot conforms to PCI Express 3.0 standard.)
Serial ATA (SATA)6 x SATA 6Gb/s
Windows 11Supported
Form FactorMicro ATX

Questions about this item

How much DDR4 memory can the B560M DS3H address across its four 288-pin slots?

The board supports up to 128 GB of DDR4 memory in a dual-channel configuration using all four slots.

What is the typical thermal and acoustic behaviour of the B560M DS3H under continuous load?

With a passive chipset heatsink and standard VRM cooling, the board runs silently; case airflow handles the heat generated by the CPU and memory.

Which CPU and memory must already be on hand for the B560M DS3H to function?

An LGA 1200 processor from Intel 10th or 11th Gen Core, Pentium or Celeron lines, plus DDR4 modules rated up to 3200 MHz for 11th Gen or 2933 MHz for 10th Gen.
