Green rectangular Micro ATX motherboard with silver LGA 1200 socket, two black DDR4 slots, single PCIe x16 slot, four SATA ports

GIGABYTE

GIGABYTE B560M H Intel motherboard LGA 1200 Micro ATX

SKU CH-WFV4-XQBSE

Micro ATX board for 10th and 11th Gen Intel Core CPUs with dual-channel DDR4 up to 64 GB, PCIe 4.0 x16 slot, two M.2 sockets, four SATA 6Gb/s ports, and 1 GbE LAN

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 11th / 10th Gen Intel Core processors Supports Inte
  • ChipsetIntel B560
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots2x288pin (DDR4)
  • Memory StandardDDR4 3200 / 3000 / 2933 / 2666 / 2400 / 2133 (11th Gen Intel
  • Supports 11th and 10th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 64 GB with speeds to 3200 MHz
  • PCI Express 4.0 x16 slot and CPU-linked M.2 for PCIe 4.0 storage
  • Four SATA 6 Gb/s ports plus a second M.2 for SATA or PCIe 3.0 drives
  • Realtek 7.1-channel audio and 1 Gbps LAN on a compact Micro ATX board

Socket LGA 1200 Micro ATX board

The GIGABYTE B560M H is a Micro ATX motherboard for Intel LGA 1200 processors. It supports 10th and 11th Gen Core CPUs plus selected Pentium and Celeron models. The Intel B560 chipset provides a compact foundation for office or home builds.

Dual M.2 and four SATA ports

Two M.2 sockets accept 2260 or 2280 drives; the CPU-linked slot runs at PCIe 4.0 x4 while the chipset slot offers PCIe 3.0 x4 and SATA modes. Four SATA 6Gb/s connectors handle additional hard drives or SSDs. Rear I/O includes HDMI, D-Sub, four USB 3.2 Gen 1 ports, two USB 2.0 ports, Gigabit LAN and 7.1 audio jacks.

Two DDR4 slots up to 64 GB

Memory capacity tops out at 64 GB across two 288-pin slots running in dual channel. Supported speeds reach 3200 with 11th Gen Core i5, i7 or i9 processors and scale down through 3000, 2933, 2666, 2400 to 2133 depending on the installed CPU.

Highlights

  • Supports 11th and 10th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 64 GB with speeds to 3200 MHz
  • PCI Express 4.0 x16 slot and CPU-linked M.2 for PCIe 4.0 storage
  • Four SATA 6 Gb/s ports plus a second M.2 for SATA or PCIe 3.0 drives
  • Realtek 7.1-channel audio and 1 Gbps LAN on a compact Micro ATX board

Specifications

BrandGIGABYTE
ModelB560M H
CPU Socket TypeLGA 1200
CPU TypeSupports 11th / 10th Gen Intel Core processors
Supports Intel Pentium / Celeron processors*
* Limited to with 4MB Intel Smart Cache, Intel Celeron G5xx5 family.
ChipsetIntel B560
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots2x288pin (DDR4)
Memory StandardDDR4 3200 / 3000 / 2933 / 2666 / 2400 / 2133 (11th Gen Intel Core i9 / i7 / i5 processors)
DDR4 2933 / 2666 / 2400 / 2133 (10th Gen Intel Core i9 / i7 processors)
DDR4 2666 / 2400 / 2133 (10th Gen Intel Core i5 / i3 / Pentium / Celeron processors)
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express 4.0 x16*
* Actual support may vary by CPU.
PCI Express x11 x PCI Express 3.0 x1
Serial ATA (SATA)4 x SATA 6Gb/s
M.2CPU:
1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2P_CPU)*
Chipset:
1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/x2 SSD support) (M2A_SB)
* System acceleration with Intel Optane Memory can only be enabled on the M2P_CPU connector and with an 11th Generation Intel processor installed.
* Supported by 11th Generation processors only.
Intel Optane ReadyYes
Audio ChipsetRealtek Audio CODEC
Audio Channels7.1 Channels
LAN ChipsetRealtek GbE LAN chip
Max LAN Speed1Gbps
Back I/O Ports1 x PS/2 mouse port
1 x PS/2 Keyboard port
1 x D-Sub port
1 x HDMI port
4 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
Onboard USB1 x USB 3.2 Gen 1 header
3 x USB 2.0/1.1 headers
Other Connectors1 x CPU fan header
1 x system fan header
1 x addressable LED strip header
1 x RGB LED strip header
1 x front panel header
1 x front panel audio header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x serial port header
1 x Clear CMOS jumper
1 x Q-Flash Plus button
Form FactorMicro ATX
LED LightingRGB
Dimensions (W x L)9.6" x 8.9"
Power Pin1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
FeaturesI/O Controller:
iTE I/O Controller Chip
H/W Monitoring:
Voltage detection
Temperature detection
Fan speed detection
Fan fail warning
Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.
BIOS:
1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features:
Support for APP Center
*Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
@BIOS
EasyTune
Fast Boot
Game Boost
O

Questions about this item

What speed does the CPU-linked M.2 slot run at with an 11th Gen processor?

The CPU-linked M.2 slot runs at PCIe 4.0 x4 or x2 with an 11th Gen processor.

What case and cooler clearances does the Micro ATX B560M H need?

The board fits any Micro ATX or larger case and uses the standard LGA 1200 mounting holes for coolers.

How do I enable the PCIe 4.0 x16 slot and CPU M.2 at full speed?

Install an 11th Gen Intel Core processor; 10th Gen CPUs limit both to PCIe 3.0 speeds.
