Green micro-ATX board, silver AM5 socket, two black DDR5 slots, matte black heatsinks

GIGABYTE

GIGABYTE B650M D2H AMD B650 DDR5 96GB Micro ATX motherboard

SKU CH-4NGJ-E6PKX

Micro-ATX board for AM5 CPUs with two DDR5 slots supporting 96GB, one PCIe 4.0 x16 slot, four SATA ports, 2.5GbE LAN and USB 3.2 Gen 1

  • ChipsetAMD B650
  • Maximum Memory Supported96GB
  • PCI SlotsBased on CPU: -1 PCI-E x16 slot, supporting PCIe 4.0 and x16
  • SATA RAID1XM.2 interface, 4xSATA III interface
  • Audio Chipset1. Integrated Realtek ® audio chip 2. Support High Definitio
  • LAN ChipsetRealtek ® 2.5GbE Network Chip (2.5 Gbps/1 Gbps/100 Mbps)
  • Supports up to 96GB DDR5 memory for high-capacity workloads
  • Micro ATX form factor at 24x22.5cm fits compact builds
  • Realtek 2.5GbE LAN delivers 2.5 Gbps wired throughput
  • AMD B650 chipset enables PCIe 4.0 on the primary x16 slot
  • Four SATA III ports plus one M.2 interface provide flexible storage options

Socket AM5 Micro ATX Platform

The GIGABYTE B650M D2H is a Micro ATX motherboard built on the AMD B650 chipset for Socket AM5 processors. It supports up to 96GB of DDR5 memory across two DIMM slots and fits a 24 by 22.5cm footprint. The board targets builders who need a compact foundation for current AMD desktop CPUs.

Verify CPU Cooler Clearance and Power Phases

Before ordering confirm that your CPU cooler fits the Micro ATX layout around the Socket AM5 zone and that your power supply provides the required 8-pin EPS connector for the board's voltage regulator. Check case front-panel headers match the onboard USB 3.2 Gen 1 and USB 2.0 internal connectors. Ensure any M.2 drive you plan to install uses a SATA interface because the single M.2 slot is wired for SATA only.

Sustained Load Thermal and Power Behaviour

Under prolonged workloads the 2.5GbE Realtek LAN and Realtek audio controllers maintain stable operation without throttling. The two DDR5 slots run at JEDEC standard voltages so memory temperatures stay consistent during extended sessions. The chipset-linked PCIe 3.0 x1 slot and four SATA III ports deliver steady throughput for storage arrays. VRM temperatures will depend on the specific CPU installed and the cooler airflow you provide.

Highlights

  • Supports up to 96GB DDR5 memory for high-capacity workloads
  • Micro ATX form factor at 24x22.5cm fits compact builds
  • Realtek 2.5GbE LAN delivers 2.5 Gbps wired throughput
  • AMD B650 chipset enables PCIe 4.0 on the primary x16 slot
  • Four SATA III ports plus one M.2 interface provide flexible storage options

Specifications

BrandGIGABYTE
SeriesGIGABYTE B650M D2H
ChipsetAMD B650
Maximum Memory Supported96GB
PCI SlotsBased on CPU:
-1 PCI-E x16 slot, supporting PCIe 4.0 and x16 operating specifications
Based on chipset:
2. - 1 PCI-E x1 slot, supporting PCIe 3.0 and x1 operating specifications
SATA RAID1XM.2 interface, 4xSATA III interface
Audio Chipset1. Integrated Realtek ® audio chip
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 - Channel
LAN ChipsetRealtek ® 2.5GbE Network Chip (2.5 Gbps/1 Gbps/100 Mbps)
Onboard USBBased on CPU:
1. - 2 USB 3.2 Gen 1 ports in the rear window IO
2. - 1 USB 2.0/1 interface in the rear window IO
Based on chipset:
3.2 USB 3.2 Gen 1 ports, which need to be connected from the USB socket in the main board via a cable
4. - 5 USB 2.0/1 ports (3 in the rear window IO, 2 need to be connected from the USB socket in the main board via the cable)
Based on chipset + USB 2.0 Hub:
5.-2 USB 2.0/1 ports, which need to be connected from the USB socket in the main board through the cable
