Green micro-ATX motherboard with black heat-sinks, four DDR4 slots, two M.2 covers and RGB lighting

GIGABYTE

GIGABYTE B660M DS3H AX DDR4 Intel motherboard

SKU CH-06T8-6JHHB

Micro-ATX board for 12th and 13th Gen Intel CPUs with four DDR4 slots, dual M.2 sockets, PCIe 4.0 graphics slot, 2.5 GbE LAN and WiFi 6

  • CPU Socket TypeLGA 1700 * Dedicated LGA1700 mounting bracket is required.
  • CPU TypeSupports 13th / 12th Gen Intel Core, Pentium Gold, Celeron P
  • ChipsetIntel B660
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardDDR4 3200
  • Supports 12th and 13th Gen Intel Core CPUs on LGA 1700 socket
  • 128 GB DDR4 3200 memory across four slots in dual-channel mode
  • PCIe 4.0 x16 slot and dual M.2 for fast storage expansion
  • 5 GbE LAN plus WiFi 6 for high-speed wired and wireless networking
  • 6+2+1 hybrid power phases with premium chokes and 8-pin solid CPU power connector

Socket and CPU support

This Micro ATX motherboard uses the LGA 1700 socket and accepts 12th and 13th Gen Intel Core, Pentium Gold and Celeron processors. A dedicated LGA 1700 mounting bracket is required for cooler installation. The board ships with the Intel B660 chipset and supports Windows 11 out of the box.

Memory and expansion layout

Four 288-pin DDR4 slots run in dual channel up to 3200 and a maximum of 128 GB. One PCI Express 4.0 x16 slot and two PCI Express 3.0 x1 slots handle graphics and add-in cards. Storage options include four SATA 6 Gb/s ports and two M.2 sockets for NVME drives. Connectivity covers USB 3.2 Gen2 Type-C, HDMI 2.0, 2.5 GbE LAN and WiFi 6 802.11 ax.

Build fit and audience

The 6+2+1 phase hybrid power design with an 8-pin solid-pin CPU connector suits mid-range gaming or productivity builds that stay on air cooling. M.2 Thermal Guard and RGB Fusion 2.0 with addressable LED headers help with thermals and lighting. Q-Flash Plus allows BIOS updates without a CPU installed. Builders needing more than two M.2 slots, additional PCIe lanes or higher VRM phase counts should consider a full-size ATX alternative.

Highlights

  • Supports 12th and 13th Gen Intel Core CPUs on LGA 1700 socket
  • 128 GB DDR4 3200 memory across four slots in dual-channel mode
  • PCIe 4.0 x16 slot and dual M.2 for fast storage expansion
  • 5 GbE LAN plus WiFi 6 for high-speed wired and wireless networking
  • 6+2+1 hybrid power phases with premium chokes and 8-pin solid CPU power connector

Specifications

BrandGIGABYTE
ModelB660M DS3H AX DDR4
CPU Socket TypeLGA 1700
* Dedicated LGA1700 mounting bracket is required.
CPU TypeSupports 13th / 12th Gen Intel Core, Pentium Gold, Celeron Processors
ChipsetIntel B660
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 3200
Maximum Memory Supported128GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express x16 slot, running at x16
(The PCIEX16 slot conforms to PCI Express 4.0 standard.)
PCI Express x12 x PCI Express x1 slots
(The PCIEX1 slots conform to PCI Express 3.0 standard.)
Serial ATA (SATA)4 x SATA 6Gb/s
M.22 x M.2
Max LAN Speed2.5Gbps
Wireless LANWi-Fi 802.11 ax
Windows 11Supported
Form FactorMicro ATX
LED LightingRGB

Questions about this item

How much DDR4 memory can the four slots on this B660M DS3H AX DDR4 board accept in total?

The four 288-pin DDR4 slots support up to 128 GB in dual-channel mode at 3200 MT/s.

What VRM phase count and CPU power connector does the board use for sustained loads?

A 6+2+1 phase hybrid design with premium chokes and capacitors is fed by an 8-pin solid-pin CPU power connector.

Which M.2 drives and CPU cooler mounting hardware are required to complete a build?

Two PCIe 4.0 x4 M.2 slots accept NVME drives; a dedicated LGA 1700 mounting bracket is required for the cooler.
