Green micro-ATX board with silver heatsinks and black PCB

GIGABYTE

GIGABYTE B760M AORUS PRO Intel motherboard

SKU CH-ZJQD-53KKT

LGA 1700 micro-ATX board with DDR5 memory, two M.2 slots, 2.5 GbE LAN and USB 3.2 Gen 2x2 Type-C

  • CPU Socket TypeLGA 1700
  • ChipsetIntel B760
  • Onboard Video ChipsetIntel® HD Graphics
  • Number of Memory Slots4x288pin (DDR5)
  • Memory StandardDDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.
  • Maximum Memory Supported128GB
  • Supports 13th and 12th generation Intel processors via LGA 1700 socket
  • 14+1+1 phase power design delivers stable CPU power
  • Four DDR5 slots reach up to 128GB with XMP 3.0 support
  • Two PCIe 4.0 M.2 slots with thermal armor for fast storage
  • Rear USB Type-C hits 20Gb/s plus 2.5GbE LAN

Socket LGA 1700 DDR5 motherboard

The GIGABYTE B760M AORUS PRO is an Intel B760 motherboard built for 12th and 13th generation Intel Core, Pentium Gold and Celeron processors. It fits a Micro ATX chassis measuring 24.4cm by 24.4cm. The board targets builders who want DDR5 memory support and modern connectivity in a compact footprint.

14+1+1 phase power with tool-free M.2

A 14+1+1 phase power design feeds the CPU socket for stable operation. Two M.2 slots feature EZ-Latch Plus for tool-free installation and include thermal armor to manage drive temperatures. Rear I/O provides a 20Gb/s USB Type-C port, HDMI, DisplayPort, 2.5GbE LAN and digital optical audio. Four SATA 6Gb/s ports handle additional storage.

PCIe 4.0 limits and memory overclocking ceiling

The single PCI Express 4.0 x16 slot runs at x4 electrical speed when the second M.2 is populated, limiting graphics bandwidth. DDR5 memory tops out at 7600 MT/s overclocked with XMP 3.0 modules, while native support stops at 4800 MT/s. Maximum capacity is 128GB across four 288-pin slots in dual-channel mode.

Highlights

  • Supports 13th and 12th generation Intel processors via LGA 1700 socket
  • 14+1+1 phase power design delivers stable CPU power
  • Four DDR5 slots reach up to 128GB with XMP 3.0 support
  • Two PCIe 4.0 M.2 slots with thermal armor for fast storage
  • Rear USB Type-C hits 20Gb/s plus 2.5GbE LAN

Specifications

BrandGIGABYTE
ModelB760M AORUS PRO
CPU Socket TypeLGA 1700
ChipsetIntel B760
Onboard Video ChipsetIntel® HD Graphics
Number of Memory Slots4x288pin (DDR5)
Memory StandardDDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s
Maximum Memory Supported128GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express 4.0 x16
PCI Express x161 PCI-E x16 slot, supporting PCIe 4.0 and x4 operating specifications (PCIEX4)
Serial ATA (SATA)4 x SATA 6Gb/s
M.22 x M.2
Audio ChipsetIntegrated Realtek® audio chip
Audio ChannelsSupport High Definition Audio
Support 2/4/5.1/7.1 channel
* The audio socket function can be redefined through the audio software. To enable 7.1-channel audio output, please enter the audio software settings.
Support S/PDIF output
LAN ChipsetRealtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Max LAN Speed2.5 Gbps/1 Gbps/100 Mbps
Back I/O Ports1 USB Type-C® port, supports USB 3.2 Gen 2x2
1 USB 3.2 Gen 2 Type-A port (red)
3 USB 3.2 Gen 1 ports
4 USB 2.0/1.1 ports
1 HDMI interface
1 DP interface
1 RJ-45 network cable interface
1 digital optical output interface
2 audio interfaces
Windows 11Support Windows 11 64-bit
Support Windows 10 64-bit
Dimensions (W x L)Micro ATX form factor; 24.4cm x 24.4cm

Questions about this item

What PCIe generation does the B760M AORUS PRO's primary x16 slot use, and what speed does that cap the graphics card at?

The primary slot runs at PCIe 4.0 x16, so a graphics card is limited to 4.0 bandwidth even if the card supports 5.0.

What case clearance and mounting pattern does the 24.4 cm square Micro-ATX board need?

It fits any Micro-ATX or larger case with standard 24.4 cm × 24.4 cm mounting holes and adequate CPU-cooler height clearance.

How do you install an M.2 SSD in the EZ-Latch Plus slot, and which step do builders often skip?

Tilt the drive in, press down, and turn the integrated latch until it clicks; many forget to rotate the latch fully, leaving the drive loose.
