Green rectangular micro-ATX board with black DDR5 slots, silver PCIe x16 slot, two M.2 covers, and rear I/O shield showing HDMI, VGA

GIGABYTE

GIGABYTE B760M D2H Intel motherboard

SKU CH-WKHX-S483F

LGA 1700 micro-ATX board with dual-channel DDR5 up to 96 GB, two M.2 slots, PCIe 4.0 x16, 2.5 GbE LAN and HDMI plus VGA outputs

  • CPU Socket TypeLGA 1700
  • ChipsetIntel B760
  • Number of Memory Slots2x288pin (DDR5)
  • Memory StandardSupport DDR5 7800(O.C.)/7600(O.C.) /7400(O.C.) /7200(O.C.) /
  • Maximum Memory Supported96GB
  • Channel SupportedDual Channel

Option DDR5

  • Supports 12th and 13th generation Intel processors with LGA 1700 socket
  • DDR5 memory up to 7800 MT/s overclocked across two slots for 96 GB capacity
  • Two M.2 slots with PCIe 4.0 x4 for fast storage expansion
  • 5 GbE LAN plus HDMI and VGA video outputs for flexible connectivity
  • Smart Fan 6 with multi-point temperature sensing and FAN STOP for quiet cooling

Intel LGA 1700 DDR5 motherboard

The GIGABYTE B760M D2H is a micro-ATX board built around the Intel B760 chipset for 12th and 13th generation Core, Pentium Gold and Celeron processors. Two DDR5 DIMM slots accept up to 96 GB of memory in dual-channel mode. It suits compact workstations or gaming builds that need modern storage and networking without a full-size chassis.

DDR5 memory speed ceiling

Memory compatibility tops out at 7800 MT/s when overclocked via XMP, with official JEDEC support down to 4000 MT/s. Only two slots are provided, so maximum capacity is reached with a pair of 48 GB modules. Builders who need four sticks or higher densities must choose a different board.

Sustained-load thermal behaviour

A 6+2+1 phase power design feeds the CPU socket while Smart Fan 6 monitors multiple onboard sensors and can stop fans entirely at low temperatures. The single PCIe 4.0 x16 slot and both M.2 connectors run at full bandwidth without sharing lanes, so storage and graphics throughput remain stable during extended workloads.

Highlights

  • Supports 12th and 13th generation Intel processors with LGA 1700 socket
  • DDR5 memory up to 7800 MT/s overclocked across two slots for 96 GB capacity
  • Two M.2 slots with PCIe 4.0 x4 for fast storage expansion
  • 5 GbE LAN plus HDMI and VGA video outputs for flexible connectivity
  • Smart Fan 6 with multi-point temperature sensing and FAN STOP for quiet cooling

Specifications

BrandGIGABYTE
ModelB760M D2H
CPU Socket TypeLGA 1700
ChipsetIntel B760
Number of Memory Slots2x288pin (DDR5)
Memory StandardSupport DDR5 7800(O.C.)/7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C. ) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s
Maximum Memory Supported96GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express 4.0 x16
PCI Express x12 PCI-E x1 slots, supporting PCIe 3.0 and x1 operating specifications
Serial ATA (SATA)4 x SATA 6Gb/s
M.22 x M.2
Audio ChipsetIntegrated Realtek® audio chip
Audio ChannelsSupport High Definition Audio
Support 2/4/5.1/7.1 channel
Support S/PDIF output
* The audio socket function can be redefined through the audio software. To enable 7.1-channel audio output, please enter the audio software settings
LAN Chipset??Realtek® 2.5GbE????(2.5 Gbps/1 Gbps/100 Mbps)
Max LAN Speed100Mbps
Back I/O Ports1 PS/2 keyboard/mouse port
1 VGA interface
1 HDMI interface
4 USB 3.2 Gen 1 ports
2 USB 2.0/1.1 ports
1 RJ-45 network cable interface
3 audio interfaces
Windows 11Support Windows 11 64-bit
Support Windows 10 64-bit
Dimensions (W x L)24.4cmx 22.5cm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What does the DDR5 7800 MT/s figure mean once the board is built into a system?

The 7800 MT/s rating is an overclocked memory speed that requires XMP-capable DDR5 modules and a compatible 12th or 13th generation Intel processor; actual operating speed depends on the specific CPU and memory kit installed.

How does the PCI Express 4.0 x16 slot limit graphics card performance in practice?

The single PCIe 4.0 x16 slot delivers full 4.0 bandwidth to a discrete GPU, while the two x1 slots operate at PCIe 3.0 x1 speeds for add-in cards such as sound or network adapters.

What physical space and mounting points does the 24.4cm by 22.5cm board need to fit in a case?

The micro-ATX form factor measures 24.4 cm wide by 22.5 cm deep and uses standard micro-ATX screw holes, so it fits any case that supports micro-ATX or larger motherboards.
