Black rectangular circuit board with silver heatsinks and two vertical DDR5 slots

GIGABYTE

GIGABYTE B760M GAMING AC Wi-Fi Intel Motherboard

SKU CH-S05Z-4M3VY

Micro-ATX board with LGA 1700 socket for 12th and 13th generation Intel processors, dual-channel DDR5 up to 96 GB, two M.2 slots, 2.5 GbE LAN, Realtek Wi-Fi and BLUETOOTH 4.2

  • CPU Socket TypeLGA 1700
  • ChipsetIntel B760
  • Onboard Video ChipsetIntel® HD Graphics
  • Number of Memory Slots2x288pin (DDR5)
  • Memory StandardSupport DDR5 7800(O.C.)/7600(O.C.) /7400(O.C.) /7200(O.C.) /
  • Maximum Memory Supported96GB
  • Supports 13th and 12th generation Intel processors via LGA 1700 socket
  • Dual-channel DDR5 up to 7800 MT/s overclocked with two slots
  • Two PCIe 4.0 x4 M.2 slots for next-generation storage
  • 5 GbE LAN plus Wi-Fi 802.11ac and Bluetooth 4.2
  • Tool-free PCIe 4.0 x16 graphics card slot with EZ-Latch design

Socket and chipset

The GIGABYTE B760M GAMING AC is an Intel motherboard built on the B760 chipset with an LGA 1700 socket. It accepts 12th and 13th generation Intel Core, Pentium Gold and Celeron processors. The board uses a 6+2+1 phase power design and supports dual-channel DDR5 memory up to 96 GB across two slots.

Who this suits

Builders who want a compact micro-ATX platform with integrated 2.5 GbE LAN, dual-band Wi-Fi and Bluetooth 4.2 will find the connectivity complete. Users needing four DDR5 slots, additional PCIe x16 lanes or a higher-end chipset feature set should consider other models.

Deciding specification

The board provides only two DDR5 DIMM slots with a 96 GB maximum capacity. If your memory plan requires four slots or more than 96 GB, this motherboard will not meet that requirement.

Highlights

  • Supports 13th and 12th generation Intel processors via LGA 1700 socket
  • Dual-channel DDR5 up to 7800 MT/s overclocked with two slots
  • Two PCIe 4.0 x4 M.2 slots for next-generation storage
  • 5 GbE LAN plus Wi-Fi 802.11ac and Bluetooth 4.2
  • Tool-free PCIe 4.0 x16 graphics card slot with EZ-Latch design

Specifications

BrandGIGABYTE
ModelB760M GAMING AC
CPU Socket TypeLGA 1700
ChipsetIntel B760
Onboard Video ChipsetIntel® HD Graphics
Number of Memory Slots2x288pin (DDR5)
Memory StandardSupport DDR5 7800(O.C.)/7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C. ) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s
Maximum Memory Supported96GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express 4.0 x16
PCI Express x11 PCI-E x1 slot, supports PCIe 3.0 and x1 operating specifications
Serial ATA (SATA)4 x SATA 6Gb/s
M.22 x M.2
Audio ChipsetIntegrated Realtek® audio chip
Audio ChannelsSupport High Definition Audio
Support 2/4/5.1/7.1-channel
* The audio socket function can be redefined through the audio software. To enable 7.1-channel audio output, please enter the audio software settings.
Support S/PDIF output
LAN ChipsetIntegrated Realtek® 2.5GbE network chip (2.5 Gbps/1 Gbps/100 Mbps)
Max LAN Speed100Mbps
Wireless LANRealtek® Wi-Fi RTL8821CE
WIFI 802.11a, b, g, n, ac, support 2.4/5 GHz wireless dual-band
Support 11ac wireless communication standard, can support up to 433 Mbps
BluetoothBLUETOOTH 4.2
Back I/O Ports2 USB 2.0/1.1 ports
1 PS/2 keyboard/mouse port
2 SMA antenna interfaces (1T1R)
1 VGA interface
1 HDMI interface
1 DP interface
3 USB 3.2 Gen 1 ports
1 x USB Type-C® port, supports USB 3.2 Gen 1
1 RJ-45 network cable interface
3 audio interfaces
Windows 11Support Windows 11 64-bit
Support Windows 10 64-bit
Dimensions (W x L)Micro ATX form factor; 24.4cm x 22.5cm

Questions about this item

What is included in the box and what must be bought separately?

The motherboard, an I/O shield, two SMA Wi-Fi antennas and SATA cables are supplied. You will need to purchase a compatible LGA 1700 processor, DDR5 memory modules, storage drives and a graphics card if your CPU lacks integrated graphics.

Which memory speed should I choose for this board?

The board supports DDR5 speeds from 4000 up to 7800 MT/s, all listed as overclocked profiles. Pick a kit that matches your CPU's memory controller and enable the XMP profile in BIOS for the rated speed.

What does the 2.5 GbE LAN figure mean in daily use?

The Realtek 2.5GbE controller can transfer data at up to 2.5 Gbps on a compatible network, giving noticeably faster file moves and lower latency than standard 1 GbE when paired with a 2.5 GbE switch or router.
