ATX motherboard in black with grey PCIe slots and metal-reinforced audio section

GIGABYTE

GIGABYTE G1.SNIPER B7 Intel motherboard LGA 1151 B150 DDR4 2133 64GB

SKU CH-5CT6-ZHF3R

ATX board for 6th- and 7th-gen Intel CPUs with four DDR4 2133 slots, dual-channel support to 64 GB, two PCIe x16 slots, six SATA ports, one SATA Express and one M.2 connector.

  • CPU Socket TypeLGA 1151
  • CPU TypeIntel Core 7th Gen (LGA 1151)
  • ChipsetIntel B150
  • Onboard Video ChipsetIntegrated Graphics
  • Number of Memory Slots4 x DIMM
  • Memory StandardDDR4 2133
  • Supports 64GB DDR4 memory for demanding workloads
  • Dual-channel DDR4 2133 boosts data throughput
  • Intel B150 chipset enables 6th and 7th Gen Core CPUs
  • Six SATA 6Gb/s ports plus SATA Express for fast storage
  • Realtek ALC1150 delivers 8-channel high-definition audio

G1.SNIPER B7 Platform

The GIGABYTE G1.SNIPER B7 is an ATX motherboard built on the Intel B150 chipset for LGA 1151 processors. It accepts 6th and 7th Generation Intel Core, Pentium and Celeron CPUs. Four DIMM slots support DDR4 2133 memory in dual-channel mode up to 64GB.

Gamers and builders on B150

This board suits users assembling a mid-range system with a locked Intel CPU who want multi-GPU capability and plenty of storage ports. Builders needing CPU overclocking, newer socket support or integrated Wi-Fi should consider a different platform.

Memory and expansion headroom

Dual-channel DDR4 2133 scales comfortably to 64GB across four slots for heavy multitasking. Two full-length PCI Express x16 slots handle dual graphics cards, while six SATA 6Gb/s ports, one SATA Express connector and an M.2 slot provide extensive drive connectivity.

Highlights

  • Supports 64GB DDR4 memory for demanding workloads
  • Dual-channel DDR4 2133 boosts data throughput
  • Intel B150 chipset enables 6th and 7th Gen Core CPUs
  • Six SATA 6Gb/s ports plus SATA Express for fast storage
  • Realtek ALC1150 delivers 8-channel high-definition audio

Specifications

BrandGIGABYTE
ModelG1.SNIPER B7
CPU Socket TypeLGA 1151
CPU TypeIntel Core 7th Gen (LGA 1151)
ChipsetIntel B150
Onboard Video ChipsetIntegrated Graphics
Number of Memory Slots4 x DIMM
Memory StandardDDR4 2133
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express x162 x PCI Express x16
PCI Express x11 x PCI Express x16 slot, running at x16 (PCIEX16)
1 x PCI Express x16 slot, running at x4 (PCIEX4)
PCI Slots2 x PCI Slots
Serial ATA (SATA)6 x SATA 6Gb/s
SATA Express1 x SATA Express
M.21 x M.2
Audio ChipsetRealtek ALC1150
Audio Channels8 Channels
Max LAN Speed1Gbps
PS/21 x PS/2 keyboard/mouse port
Video Ports1 x DVI-D
HDMI1 x HDMI
RJ451 x RJ45
USB 3.04 x USB 3.0 / 2.0
USB 1.1/2.01 x USB 2.0 / 1.1
S/PDIF Out1 x Optical
Audio Ports5 (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In)
Onboard USB1 x USB 3.0 / 2.0 header + 2 x USB 2.0 / 1.1 headers
Other Connectors1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x M.2 Socket 3 connector
1 x SATA Express connector
6 x SATA 6Gb/s connectors
1 x CPU fan header
3 x system fan headers
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x Trusted Platform Module (TPM) header
1 x Thunderbolt add-in card connector
1 x serial port header
1 x Clear CMOS jumper
1 x audio gain control switch
Form FactorATX
Dimensions (W x L)12.01" x 8.86"
Power Pin24-pin ATX main power connector
8-pin ATX 12V power connector
FeaturesSupports 6th Generation Intel Core Processor
Dual Channel DDR4, 4 DIMMs
2-Way Graphics with Premium PCIe Lane
PCIe Gen3 x4 M.2 Connector with up to 32Gb/s Data Transfer (PCIe NVMe & SATA SSD support)
SATA Express Connector for up to 16Gb/s Data Transfer
115dB SNR HD Audio with Built-in Rear Audio Amplifier
8-channel HD Audio with High Quality Audio Capacitors
Audio Noise Guard with Ambient LED Trace Path Lighting
Intel GbE LAN with cFosSpeed Internet Accelerator Software
Triple USB DAC-UP ports
APP Center Including EasyTune and Cloud Station Utilities
GIGABYTE UEFI DualBIOS Technolog

Questions about this item

Which Intel processor socket does this board use so I can match my CPU?

The board uses the LGA 1151 socket and supports Intel Core 6th and 7th generation processors including Celeron, Pentium, Core i3, i5 and i7 models.

Can I keep my existing DDR4 2133 memory modules when upgrading to this motherboard?

Yes, the four DIMM slots accept DDR4 2133 memory in dual-channel mode up to a total of 64 GB, so your current modules will work.

How can I confirm the onboard audio is functioning after I build the system?

The Realtek ALC1150 codec provides 8-channel output; connect speakers to the rear audio jacks and verify sound in the OS audio control panel.
