Rectangular ATX motherboard, dark PCB with blue DDR3 slots, white PCIe x16, black PCIe x1 and PCI slots, silver I/O shield

GIGABYTE

GIGABYTE GA-770T-D3L DDR3 AMD Motherboard AM3 Socket

SKU CH-MTBC-4ANS2

AM3 motherboard with AMD 770 chipset, dual-channel DDR3 up to 1666 MHz, six SATA 3Gb/s ports with RAID, PCI Express 2.0 x16 graphics slot, four PCIe x1 slots, two PCI slots, twelve USB 2.0 ports.

  • CPU Socket TypeAM3
  • Supports AMD Phenom II X6 processors for multi-core performance
  • Dual-channel DDR3 1666 MHz memory for faster data throughput
  • PCI Express 2.0 x16 slot enables high-bandwidth graphics
  • 6 SATA 3Gb/s ports with RAID 0, 1, 0+1 for flexible storage
  • All 50000-hour Japanese solid capacitors ensure long-term reliability

AM3 DDR3 Motherboard

The GIGABYTE GA-770T-D3L uses the AMD 770 northbridge and SB710 southbridge to support Phenom II and Athlon II processors in an AM3 socket. Dual-channel DDR3 runs at 1666 OC, 1333 and 1066 MHz across two DIMM slots for up to 8 GB. A PCI Express 2.0 x16 slot, four PCIe x1 slots and two PCI slots handle expansion. On-board audio uses the Realtek ALC888/892 codec for 7.1-channel output and Gigabit LAN is provided by a Realtek 8111 chip.

Builders needing AM3 DDR3 platform

This board suits anyone upgrading or repairing a legacy AM3 system that requires DDR3 memory and PCI Express 2.0 graphics. It will not suit builders who need more than two memory slots, more than six SATA 3Gb/s ports, USB 3.0 connectivity, or a newer CPU socket. The single PCIe x16 slot also limits multi-GPU configurations.

Two DDR3 slots cap memory at 8 GB

Only two 1.5 V DDR3 DIMM sockets are fitted, so the maximum supported system memory is 8 GB in dual-channel mode. If your workload demands 16 GB or more, this motherboard cannot meet that requirement.

Highlights

  • Supports AMD Phenom II X6 processors for multi-core performance
  • Dual-channel DDR3 1666 MHz memory for faster data throughput
  • PCI Express 2.0 x16 slot enables high-bandwidth graphics
  • 6 SATA 3Gb/s ports with RAID 0, 1, 0+1 for flexible storage
  • All 50000-hour Japanese solid capacitors ensure long-term reliability

Specifications

CPU Socket TypeAM3

Questions about this item

How much DDR3 memory can the two DIMM slots accept in total?

The board supports up to 8 GB of system memory across its two 1.5 V DDR3 DIMM sockets.

What is the peak heat or noise concern when the system runs continuously?

All 50,000 hour Japanese solid capacitors and the Easy Energy Saver design keep heat and power draw low during all-day operation.

Which AM3 processor must already be owned for this motherboard to function?

An AMD Phenom II or Athlon II CPU with HyperTransport 5200 MT/s is required to boot the GA-770T-D3L.
