Green Micro ATX motherboard with black sockets and silver heatsinks

GIGABYTE

GIGABYTE GA-78LMT-S2 (rev. 1.0) AMD motherboard

SKU CH-09RJ-MXQP8

Micro-ATX AMD 760G board with two DDR3 slots supporting up to 16GB, one PCIe x16, one PCIe x1 and six SATA ports

  • ChipsetAMD 760G
  • Maximum Memory Supported16GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID6XSATA II interface
  • Audio Chipset1. Built-in Realtek HD sound chip 2. Support High Definition
  • LAN ChipsetBuilt-in Realtek GbE LAN chips (10/100/1000 Mbit)
  • Socket AM3+/AM3 supports AMD processors
  • AMD 760G chipset provides integrated graphics
  • 16GB DDR3 maximum memory capacity
  • PCI Express 2.0 x16 slot for graphics cards
  • Realtek GbE LAN enables 1000 Mbit networking

Socket AM3+/AM3 micro-ATX board

This GIGABYTE GA-78LMT-S2 revision 1.0 motherboard fits Socket AM3+ and AM3 processors in a micro-ATX form factor. It uses the AMD 760G chipset and provides two DDR3 DIMM slots for up to 16 GB of system memory. The board targets builders assembling a compact AMD system with legacy DDR3 components.

Thermals and power in normal use

The AMD 760G chipset and simple voltage regulation run cool under typical desktop loads without active chipset cooling. A single PCI Express x16 slot operating at PCI Express 2.0 and one PCI Express x1 slot keep expansion power draw modest. The micro-ATX layout leaves room for standard case airflow around the CPU socket area.

Bundled accessories and their impact

The retail package includes one SATA cable and a chassis I/O back panel for immediate drive and peripheral connection. No additional mounting hardware, driver media or software utilities are supplied beyond the board itself. Builders must source any extra SATA cables, case standoffs or operating-system drivers separately.

Highlights

  • Socket AM3+/AM3 supports AMD processors
  • AMD 760G chipset provides integrated graphics
  • 16GB DDR3 maximum memory capacity
  • PCI Express 2.0 x16 slot for graphics cards
  • Realtek GbE LAN enables 1000 Mbit networking

Specifications

BrandGIGABYTE
SeriesGIGABYTE GA-78LMT-S2(rev.1.0)
ChipsetAMD 760G
Maximum Memory Supported16GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications
2. 1 PCI Express x1 slot
All PCI Express slots support PCI Express 2.0.
3. 1 PCI slot
SATA RAID6XSATA II interface
Audio Chipset1. Built-in Realtek HD sound chip
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels (Note 2)
LAN ChipsetBuilt-in Realtek GbE LAN chips (10/100/1000 Mbit)
Onboard USBBuilt-in Nanqiao chip:
Up to 8 USB 2.0/1 ports (4 on the rear panel, 4 to be connected from the USB socket in the main board via cable)

Questions about this item

How do I install this Micro ATX board in a case, and what step is often missed?

Mount the board using the Micro ATX screw pattern measuring 24.4 by 18.8 cm, then attach the supplied I/O back panel before securing the board — many builders forget the back panel until after the board is fixed down.

What maintenance will the GA-78LMT-S2 need later?

Replace the metal battery on the board when the system loses time or BIOS settings; the board ships with one battery and no other user-serviceable parts.

What limit appears first when the board runs under sustained load?

Memory capacity stops at 16 GB across the two DDR3 DIMM slots, so heavy multitasking hits that ceiling before the PCI Express 2.0 or SATA interfaces saturate.
