Green micro-ATX board with black slots and silver heatsinks

GIGABYTE

GIGABYTE GA-78LMT-S2P (rev.5.0) AMD motherboard

SKU CH-Q7TS-Z6QK0

Socket AM3+ micro-ATX board with AMD 760G chipset, dual DDR3 slots supporting 16GB, one PCIe 2.0 x16 slot, six SATA ports, Realtek ALC887 audio and Atheros gigabit LAN

  • ChipsetAMD 760G
  • Maximum Memory Supported16GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID6XSATA II interface
  • Audio Chipset1. Built-in Realtek ALC887 HD sound chip 2. Support High Def
  • LAN ChipsetBuilt-in 1 Atheros GbE LAN chip (10/100/1000 Mbit)
  • Socket AM3+ supports AMD processors
  • AMD 760G chipset handles graphics and I/O
  • Two DDR3 DIMM slots take up to 16GB memory
  • PCI Express 2.0 x16 plus x1 and PCI slots for expansion
  • Realtek ALC887 delivers 7.1 channel HD audio

AM3+ socket for AMD CPUs

This micro ATX board uses the AMD 760G chipset and a Socket AM3+ CPU slot. It targets builders who need a compact platform for older AMD processors. Two DDR3 DIMM slots support up to 16GB of system memory. The 24.4 by 20.6 cm layout fits many small chassis.

Check CPU cooler clearance and power phases

Verify that your chosen AM3+ processor matches the board's power delivery before ordering. Confirm the case can accept a 24.4 by 20.6 cm micro ATX board and that the cooler mounting holes align. Ensure the power supply provides the necessary ATX and CPU connectors for this generation.

One SATA cable and I/O shield included

The bundle supplies a single SATA cable and a chassis I/O back panel for the rear ports. No additional brackets, driver media or extra cables are provided. Plan to source any further SATA cables, fan adapters or mounting hardware separately.

Highlights

  • Socket AM3+ supports AMD processors
  • AMD 760G chipset handles graphics and I/O
  • Two DDR3 DIMM slots take up to 16GB memory
  • PCI Express 2.0 x16 plus x1 and PCI slots for expansion
  • Realtek ALC887 delivers 7.1 channel HD audio

Specifications

BrandGIGABYTE
SeriesGIGABYTE GA-78LMT-S2P(rev.5.0)
ChipsetAMD 760G
Maximum Memory Supported16GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications
2. 1 PCI Express x1 slot
All PCI Express slots support PCI Express 2.0.
3. 1 PCI slot
SATA RAID6XSATA II interface
Audio Chipset1. Built-in Realtek ALC887 HD sound chip
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels (Note 3)
LAN ChipsetBuilt-in 1 Atheros GbE LAN chip (10/100/1000 Mbit)
Onboard USB1. Built-in Nanqiao chip:
2. Support up to 8 USB 2.0/1 ports (4 on the rear panel, 4 need to be connected from the USB socket in the main board via the cable)

Questions about this item

Does the GA-78LMT-S2P rev. 5.0 box include a CPU cooler or extra cables?

The package contains the motherboard, one SATA cable and the chassis I/O back panel. No CPU cooler or additional cables are supplied.

Should I choose a 16 GB kit or two 8 GB DDR3 modules for this board?

The board has two DDR3 DIMM slots and supports up to 16 GB total, so a 2 × 8 GB kit fills both slots and reaches the maximum capacity.

What does the single PCI Express x16 slot running at 2.0 mean for a graphics card?

The slot follows the PCI Express 2.0 specification; a card installed here will communicate at that link speed.
