Rectangular ATX motherboard, matte black PCB with blue DDR3 slots and silver heatsinks, rear I/O shield attached

GIGABYTE

GIGABYTE GA-880G-USB3 AMD 880G DDR3 32GB ATX motherboard

SKU CH-ANV0-W7ZA8

Socket AM3 ATX board with AMD 880G chipset, four DDR3 slots for up to 32 GB, one PCIe x16 and one PCIe x4 slot, six SATA II ports, Realtek ALC889 7.1 audio, Gigabit LAN.

  • ChipsetAMD 880G
  • Maximum Memory Supported32GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operation specificati
  • SATA RAID6XSATA II interface
  • Audio Chipset1. Built-in Realtek ALC889 chip 2. Support High Definition A
  • LAN ChipsetBuilt-in 1 Realtek RTL8111E chip (10/100/1000 Mbit)
  • Socket AM3 CPU support for AMD processors
  • AMD 880G chipset with integrated graphics capability
  • Up to 32GB DDR3 memory across four DIMM slots
  • 10 USB ports including 2 USB 3.0 and 8 USB 2.0
  • Realtek ALC889 audio with 7.1-channel Dolby Home Theater

Socket AM3 AMD 880G board

The GIGABYTE GA-880G-USB3 is an ATX motherboard built on the AMD 880G chipset for Socket AM3 processors. It provides four DDR3 DIMM slots with a maximum memory capacity of 32 GB and includes a single PCI Express x16 slot running at x16 plus a second x16 slot wired for x4 operation.

Upgraders with AM3 CPUs, not new builds

This board suits owners of existing Socket AM3 processors who need a replacement or a budget platform using DDR3 memory. Builders starting a fresh PC should look elsewhere because the chipset and socket are discontinued and do not support current processors.

32 GB DDR3 ceiling

The four DIMM slots accept up to 32 GB of DDR3, which is the hard limit for memory on this platform. If your workload needs more RAM you must choose a different motherboard.

Highlights

  • Socket AM3 CPU support for AMD processors
  • AMD 880G chipset with integrated graphics capability
  • Up to 32GB DDR3 memory across four DIMM slots
  • 10 USB ports including 2 USB 3.0 and 8 USB 2.0
  • Realtek ALC889 audio with 7.1-channel Dolby Home Theater

Specifications

BrandGIGABYTE
SeriesGIGABYTE GA-880G-USB3
ChipsetAMD 880G
Maximum Memory Supported32GB
PCI Slots1 PCI Express x16 slot, supporting x16 operation specification (PCIEX16) (Note 5)
1 PCI Express x16 slot, supporting x4 operating specifications (PCIEX4)
2 PCI Express x1 slots (Note 6)
All PCI Express slots support PCI Express 2.0.
4. 2 PCI slots
SATA RAID6XSATA II interface
Audio Chipset1. Built-in Realtek ALC889 chip
2. Support High Definition Audio
3. Support 2/4 /5.1/7.1 channels
4. Support Dolby Home Theater Dolby surround sound technology ®
5. Support S/PDIF input/output
LAN ChipsetBuilt-in 1 Realtek RTL8111E chip (10/100/1000 Mbit)
Onboard USBBuilt-in Nanqiao chip:
1. Up to 10 USB 2.0/1 ports (4 on the rear panel, 6 need to be connected from the USB socket in the main board via the cable)
Built-in Etron EJ168 chip:
Supports up to 2 USB 3.0/2 ports on the rear panel

Questions about this item

What processor socket must I already have to use this GA-880G-USB3 board?

The board uses Socket AM3, so you need an AM3-series CPU to install and run it.

Will my older SATA drives work with the six SATA II ports on this motherboard?

Yes, the six SATA II interfaces accept standard SATA drives and will operate them at SATA II speeds.

How can I confirm the onboard Realtek ALC889 audio is functioning after I build the system?

Connect speakers to the rear audio jacks, play sound in the OS, and verify multi-channel output up to 7.1 through the Realtek control panel.
