Green micro-ATX board with black slots and silver I/O shield

GIGABYTE

GIGABYTE GA-B150M-HD3 Intel motherboard

SKU CH-N6AH-5TXQ8

Micro-ATX board for LGA 1151 CPUs with two DDR4 2133 slots up to 32 GB, one PCIe x16, two PCIe x1, one PCI, six SATA 6 Gb/s, one M.2, Realtek ALC887 8-channel audio, gigabit LAN.

  • CPU Socket TypeLGA 1151
  • CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1151)
  • ChipsetIntel B150
  • Number of Memory Slots2 x DIMM
  • Memory StandardDDR4 2133
  • Maximum Memory Supported32GB
  • Supports 6th and 7th Gen Intel Core i7, i5, i3, Pentium and Celeron processors via LGA 1151 socket
  • Dual-channel DDR4 2133 memory architecture with two DIMM slots for up to 32 GB total capacity
  • Full-length PCI Express x16 slot running at x16 electrical for discrete graphics cards
  • Realtek ALC887 eight-channel high-definition audio for immersive sound
  • Gigabit Ethernet with 10/100/1000 Mbps connectivity for fast wired networking

Socket LGA 1151 B150 board

The GIGABYTE GA-B150M-HD3 is a micro-ATX motherboard built around the Intel B150 chipset. It accepts 6th- and 7th-generation Core i7, i5, i3, Pentium and Celeron processors in the LGA 1151 package. Two DIMM slots support DDR4 2133 memory up to 32 GB in dual-channel mode.

Builders needing legacy and modern ports

Six SATA 6 Gb/s connectors and one M.2 slot provide storage flexibility, while a full-size PCI Express x16 slot, two x1 slots and a conventional PCI slot cover both current and older add-in cards. Rear I/O supplies HDMI video, one PS/2 combo port, two USB 2.0 and three USB 3.0 connections. Buyers requiring more than two memory slots or multiple x16 slots should consider larger form-factor boards.

Two DIMM slots cap memory at 32 GB

The board offers only two DDR4 slots, so the 32 GB maximum is reached with a pair of 16 GB modules. If your workload demands four sticks or higher total capacity, this platform will not meet that requirement.

Highlights

  • Supports 6th and 7th Gen Intel Core i7, i5, i3, Pentium and Celeron processors via LGA 1151 socket
  • Dual-channel DDR4 2133 memory architecture with two DIMM slots for up to 32 GB total capacity
  • Full-length PCI Express x16 slot running at x16 electrical for discrete graphics cards
  • Realtek ALC887 eight-channel high-definition audio for immersive sound
  • Gigabit Ethernet with 10/100/1000 Mbps connectivity for fast wired networking

Specifications

BrandGIGABYTE
ModelGA-B150M-HD3
CPU Socket TypeLGA 1151
CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1151)
ChipsetIntel B150
Number of Memory Slots2 x DIMM
Memory StandardDDR4 2133
Maximum Memory Supported32GB
Channel SupportedDual Channel
PCI Express x161 x PCI Express x16 slot, running at x16
PCI Express x12 x PCI Express x1
PCI Slots1 x PCI Slot
Serial ATA (SATA)6 x SATA 6Gb/s
M.21 x M.2
Audio ChipsetRealtek ALC887
Audio Channels8 Channels
LAN ChipsetRealtek
Max LAN Speed1Gbps
Back I/O Ports1 x HDMI / 1 x PS/2 Keyboard/Mouse Combo / 2 x USB 2.0/1.1 / 3 x USB 3.0
PS/21 x PS/2 keyboard/mouse port
Video Ports1 x DVI-D/1 x D-Sub
HDMI1 x HDMI
RJ451 x RJ45
USB 3.03 x USB 3.0 / 2.0
USB 1.1/2.02 x USB 2.0 / 1.1
Audio Ports3 x audio jacks (Line In, Line Out, Mic In)
Onboard USB1 x USB 3.0 / 2.0 header + 2 x USB 2.0 / 1.1 headers
Other Connectors1 x 24-pin ATX main power connector/1 x 8-pin ATX 12V power connector/1 x M.2 Socket 3 connector/6 x SATA 6Gb/s connectors/1 x CPU fan header/1 x system fan header/1 x front panel header/1 x front panel audio header/1 x S/PDIF Out header/1 x Trusted Platform Module (TPM) header/1 x serial port header/1 x parallel port header/1 x Clear CMOS jumper
Form FactorMicro ATX
Dimensions (W x L)9.61" x 6.85"
Power Pin24-pin ATX main power connector/8-pin ATX 12V power connector
FeaturesSupports 6th Generation Intel Core Processor//Dual Channel DDR4, 2 DIMMs//PCIe Gen3 x4 M.2 Connector with up to 32Gb/s Data Transfer (PCIe NVMe & SATA SSD support)//8-channel HD Audio with High Quality Audio Capacitors//Audio Noise Guard with LED Trace Path Lighting//Realtek Green GbE LAN with cFosSpeed Internet Accelerator Software//APP Center Including EasyTune and Cloud Station Utilities//GIGABYTE UEFI DualBIOS Technology//Support Intel Small Business Basics

Questions about this item

Will the Realtek ALC887 audio codec or the two DDR4 2133 DIMM slots need replacement first?

The Realtek ALC887 codec is soldered to the board and not user-replaceable; the two DDR4 2133 DIMM slots accept standard modules that can be swapped if a stick fails or more capacity is needed.

Does the single PCI Express x16 slot running at x16 or the 32 GB memory ceiling limit sustained workloads first?

The board supports a maximum of 32 GB across its two DDR4 2133 slots, so memory capacity is the first hard limit for sustained workloads.

How hot or loud does the board get when the six SATA 6 Gb/s ports and the M.2 slot are active all day?

The chipset and voltage regulators are passively cooled; typical case airflow keeps temperatures in a safe range and adds no audible noise of their own.
