Compact Mini-ITX motherboard with black PCB and silver heatsinks

GIGABYTE

GIGABYTE GA-B150N PHOENIX-WIFI Intel motherboard

SKU CH-NDRK-3FG9B

Mini ITX board for LGA 1151 CPUs with dual-channel DDR4 2133, one PCIe x16 slot, four SATA ports, one M.2 slot, Intel gigabit LAN, dual-band Wi-Fi and Bluetooth 4.2

  • CPU Socket TypeLGA 1151
  • CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1151)
  • ChipsetIntel B150
  • Number of Memory Slots2 x DIMM
  • Memory StandardDDR4 2133
  • Maximum Memory Supported32GB
  • Supports up to 32GB DDR4 2133 memory for responsive multitasking
  • Single PCI Express x16 slot at full x16 speed for graphics expansion
  • Four SATA 6Gb/s ports provide ample storage connectivity
  • Realtek ALC892 delivers 8-channel high-definition audio
  • Dual-band Wi-Fi 802.11 a/b/g/n/ac plus Bluetooth 4.2 for wireless flexibility

B150 Mini ITX motherboard with Wi-Fi and Bluetooth

The GIGABYTE GA-B150N PHOENIX-WIFI is a Mini ITX board built around the Intel B150 chipset for LGA 1151 processors. It supports Core i7, i5, i3, Pentium and Celeron CPUs with dual-channel DDR4 2133 memory up to 32 GB across two DIMM slots. Integrated 802.11 a/b/g/n/ac dual-band Wi-Fi and Bluetooth 4.2 provide wireless connectivity in a compact layout.

Suits small-form-factor builds needing wireless

This board fits compact cases that require built-in Wi-Fi and Bluetooth alongside a single full-length PCI Express x16 slot for a graphics card. Four SATA 6 Gb/s ports and one M.2 socket handle storage, while Realtek ALC892 8-channel audio covers sound. Builders who need multiple PCIe slots, more than two memory slots, or legacy PS/2 keyboards will find the feature set limited.

Single PCI Express x16 slot at x16 electrical

The sole PCI Express x16 slot runs at full x16 speed, which determines whether a discrete graphics card can operate at its maximum bandwidth. If the build requires additional expansion cards or a second x16 slot, this platform cannot accommodate them.

Highlights

  • Supports up to 32GB DDR4 2133 memory for responsive multitasking
  • Single PCI Express x16 slot at full x16 speed for graphics expansion
  • Four SATA 6Gb/s ports provide ample storage connectivity
  • Realtek ALC892 delivers 8-channel high-definition audio
  • Dual-band Wi-Fi 802.11 a/b/g/n/ac plus Bluetooth 4.2 for wireless flexibility

Specifications

BrandGIGABYTE
ModelGA-B150N PHOENIX-WIFI
CPU Socket TypeLGA 1151
CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1151)
ChipsetIntel B150
Number of Memory Slots2 x DIMM
Memory StandardDDR4 2133
Maximum Memory Supported32GB
Channel SupportedDual Channel
PCI Express x161 x PCI Express x16 slot, running at x16
Serial ATA (SATA)4 x SATA 6Gb/s
M.21 x M.2
Audio ChipsetRealtek ALC892
Audio Channels8 Channels
LAN ChipsetIntel
Max LAN Speed1Gbps
Wireless LANWi-Fi 802.11 a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
BluetoothBluetooth 4.2, 4.1, BLE, 4.0, 3.0, 2.1+EDR
PS/21 x PS/2 keyboard/mouse port
Video Ports1 x DVI-D
HDMI1 x HDMI
RJ451 x RJ45
USB 3.11 x USB Type-C with USB 3.1 support/1 x USB 3.1 Type-A port (red)
USB 3.04 x USB 3.0 / 2.0
S/PDIF Out1 x Optical
Audio Ports5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In)
Antenna Connectors2 x SMA antenna connectors (2T2R)
Onboard USB1 x USB 3.0/2.0 header + 1 x USB 2.0/1.1 header
Other Connectors1 x 24-pin ATX main power connector/1 x 8-pin ATX 12V power connector/4 x SATA 6Gb/s connectors/1 x CPU fan header/2 x system fan headers/1 x front panel header/1 x front panel audio header/1 x S/PDIF Out header/1 x speaker header/1 x Clear CMOS jumper/1 x chassis intrusion header
Form FactorMini ITX
Dimensions (W x L)6.69" x 6.69"
Power Pin24-pin ATX main power connector/8-pin ATX 12V power connector
FeaturesSupports 6th Generation Intel Core Processor//Dual Channel DDR4, 2 DIMMs//Fast USB 3.1 with USB Type-C -The World’s Next Universal Connector//11ac 867 Mbps dual band wireless connection + BLUETOOTH 4.2//PCIe Gen3 x4 M.2 Connector with up to 32Gb/s Data Transfer (PCIe NVMe & SATA SSD support)//8-channel HD Audio with High Quality Audio Capacitors//Intel GbE LAN with cFosSpeed Internet Accelerator Software//Audio Noise Guard with Ambient LED Trace Path Lighting//APP Center Including EasyTune and Cloud Station Utilities//GIGABYTE UEFI DualBIOS Technology

Questions about this item

What case size and mounting pattern does the GA-B150N PHOENIX-WIFI require?

The board uses the Mini-ITX form factor, so it fits any chassis with Mini-ITX or larger motherboard trays and the standard four-hole mounting pattern.

How is the CPU cooler mounted on the LGA 1151 socket, and what step is often missed?

Align the cooler with the four holes around the LGA 1151 socket, press the push-pins through until they click, then connect the fan header; the step often missed is fully seating all four pins before powering on.

Which memory modules will need replacement if I want more than 32 GB later?

The two DDR4 2133 DIMM slots max out at 32 GB total, so exceeding that capacity requires a different motherboard rather than just swapping modules.
