Green Micro ATX motherboard with silver CPU socket, two black DIMM slots, blue PCIe x16, white PCIe x1, four SATA ports

GIGABYTE

GIGABYTE GA-B85M-D2V LGA 1150 B85 Micro ATX Intel motherboard

SKU CH-A9PH-5FKHT

Micro ATX board for LGA 1150 CPUs with dual-channel DDR3 1600/1333 up to 16 GB, four SATA 6Gb/s ports, USB 3.0, and 7.1 audio

  • CPU Socket TypeLGA 1150
  • CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1150)
  • ChipsetIntel B85
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots2x240pin
  • Memory StandardDDR3 1600/1333
  • Supports up to 16 GB DDR3 for smooth multitasking
  • Dual-channel memory architecture boosts bandwidth with DDR3 1600/1333
  • One PCI Express 3.0 x16 slot handles modern graphics cards
  • Four SATA 6Gb/s ports connect multiple high-speed drives
  • Realtek ALC887 delivers 7.1-channel audio for immersive sound

B85 Micro-ATX board for LGA 1150 builds

The GIGABYTE GA-B85M-D2V is an Intel B85 motherboard built for LGA 1150 processors including Core i7, i5, i3, Pentium and Celeron models. It uses the Micro-ATX form factor so it fits a wide range of chassis while still delivering the essential I/O and expansion needed for a mainstream desktop. Onboard video outputs rely on a CPU with integrated graphics.

Dual-channel DDR3 and single x16 slot

Two 240-pin slots accept DDR3 1600/1333 memory in dual-channel mode up to 16 GB total capacity. Expansion is provided by one PCI Express 3.0 x16 slot and two PCI Express 2.0 x1 slots for add-in cards. Four SATA 6Gb/s ports handle storage drives while the rear panel supplies two USB 3.0 ports, four USB 2.0/1.1 ports, PS/2 keyboard and mouse connectors, plus D-Sub and DVI-D video outputs.

Sustained operation with standard cooling

The B85 chipset and Realtek ALC887 7.1-channel audio run within typical desktop thermal limits without specialised cooling. Gigabit LAN from a Realtek controller maintains steady 1 Gbps throughput during long transfers. With only essential onboard controllers the board draws modest power, letting a standard CPU cooler and case airflow keep temperatures stable during extended workloads.

Highlights

  • Supports up to 16 GB DDR3 for smooth multitasking
  • Dual-channel memory architecture boosts bandwidth with DDR3 1600/1333
  • One PCI Express 3.0 x16 slot handles modern graphics cards
  • Four SATA 6Gb/s ports connect multiple high-speed drives
  • Realtek ALC887 delivers 7.1-channel audio for immersive sound

Specifications

BrandGIGABYTE
ModelGA-B85M-D2V
CPU Socket TypeLGA 1150
CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1150)
ChipsetIntel B85
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots2x240pin
Memory StandardDDR3 1600/1333
Maximum Memory Supported16GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16
PCI Express x12 (PCI Express 2.0)
Serial ATA (SATA)4 x SATA 6Gb/s
Audio ChipsetRealtek ALC887
Audio Channels7.1 Channels
LAN ChipsetRealtek
Max LAN Speed1Gbps
Back I/O Ports2 x PS/2 / 2 x USB 3.0 / 4 x USB 2.0/1.1
PS/21 x PS/2 keyboard 1 x PS/2 mouse
Video Ports1 x D-Sub 1 x DVI-D
USB 3.02 x USB 3.0
USB 1.1/2.04 x USB 2.0
Audio Ports3 Ports
Onboard USB2 x USB 3.0 + 4 x USB 2.0
Other Connectors1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header1 x system fan header1 x front panel header1 x front panel audio header1 x serial port header1 x Clear CMOS jumper
Form FactorMicro ATX
Dimensions (W x L)8.9" x 6.85"
Power Pin24 Pin
FeaturesGIGABYTE Ultra Durable 4 Plus TechnologyGIGABYTE UEFI DualBIOSGIGABYTE 333 Onboard Acceleration (USB 3.0, SATA 3.0 & 3x USB Power)GIGABYTE On/Off Charge for USB devicesLAN with high ESD ProtectionSupport for Q-FlashSupport for Xpress InstallSupport for APP Center* Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications.-@BIOS-EasyTune-EZ Setup-USB Blocker-Smart TimeLock-Smart Recovery 2

Questions about this item

How much DDR3 memory can the GA-B85M-D2V handle across its two slots?

The board supports up to 16 GB of DDR3 1600 or 1333 running in dual-channel mode across its two 240-pin DIMM sockets.

What temperatures or fan noise should I expect when the system runs all day?

The motherboard itself has no active cooling; thermal output and noise will come from the installed CPU cooler and case fans you choose.

Which LGA 1150 processor do I need to get video output from the D-Sub and DVI-D ports?

Any Core i7, i5, i3, Pentium or Celeron for LGA 1150 that includes integrated graphics will drive the onboard video connectors.
