Green micro ATX motherboard with black sockets and silver heatsinks

GIGABYTE

GIGABYTE GA-B85M-D3H Intel B85 Micro ATX Motherboard LGA 1150

SKU CH-4F5G-BKMQ4

Micro-ATX board for LGA 1150 CPUs with four DDR3 slots up to 32 GB, one PCIe 3.0 x16 slot, four SATA 6Gb/s ports, 7.1-channel audio and gigabit LAN

  • CPU Socket TypeLGA 1150
  • CPU TypeIntel Core 5th Gen (LGA 1150)
  • Supported CPU TechnologiesTurbo Boost Technology 2.0
  • ChipsetIntel B85
  • Onboard Video ChipsetIntegrated Graphics Processor - Intel HD Graphics support: 1
  • Number of Memory Slots4x240pin
  • Supports 4th- and 5th-Gen Intel Core CPUs on LGA 1150 socket
  • Four DDR3 slots accept up to 32 GB at 1600 or 1333 MHz
  • PCI Express 3.0 x16 slot delivers full graphics bandwidth
  • Four SATA 6 Gb/s ports for fast storage arrays
  • Realtek ALC892 codec provides 7.1-channel audio output

LGA 1150 Micro ATX board for 4th

The GIGABYTE GA-B85M-D3H uses the Intel B85 chipset on a Micro ATX form factor. It accepts LGA 1150 processors including 4th Gen Core i7, i5 and i3 as well as 5th Gen Core models. Turbo Boost Technology 2.0 is supported for automatic frequency scaling.

DDR3 memory up to 32 GB in dual-channel

Four 240-pin slots support DDR3 1600 and 1333 speeds with a maximum capacity of 32 GB. Dual-channel architecture is available when modules are installed in matched pairs for improved memory throughput.

One PCIe 3.0 x16 slot plus legacy PCI

A single PCI Express 3.0 x16 slot runs at full x16 speed for discrete graphics. A second x16-size slot operates at x4 and two traditional PCI slots remain for older expansion cards. Four SATA 6Gb/s ports handle storage while Realtek ALC892 provides 7.1 channel audio and a Realtek GbE controller delivers 1 Gbps LAN.

Highlights

  • Supports 4th- and 5th-Gen Intel Core CPUs on LGA 1150 socket
  • Four DDR3 slots accept up to 32 GB at 1600 or 1333 MHz
  • PCI Express 3.0 x16 slot delivers full graphics bandwidth
  • Four SATA 6 Gb/s ports for fast storage arrays
  • Realtek ALC892 codec provides 7.1-channel audio output

Specifications

BrandGIGABYTE
ModelGA-B85M-D3H
CPU Socket TypeLGA 1150
CPU TypeIntel Core 5th Gen (LGA 1150)
Supported CPU TechnologiesTurbo Boost Technology 2.0
ChipsetIntel B85
Onboard Video ChipsetIntegrated Graphics Processor - Intel HD Graphics support:
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
* The DVI-D port does not support D-Sub connection by adapter.
1 x HDMI port, supporting a maximum resolution of 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
* Support for HDMI 1.4a version.
Maximum shared memory of 1GB
Number of Memory Slots4x240pin
Memory StandardDDR3 1600/ 1333
Maximum Memory Supported32GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
PCI Express x161 x PCI Express x16 slot, running at x4 (PCIEX4)
PCI Slots2 x PCI Slots
Serial ATA (SATA)4 x SATA 6Gb/s connectors (SATA3 0/1/2/3) supporting up to 4 SATA 6Gb/s devices
Audio ChipsetRealtek ALC892
Audio Channels7.1 Channels
LAN ChipsetRealtek GbE LAN chip
Max LAN Speed1Gbps
PS/21 x PS/2 keyboard/mouse port
Video Ports1 x D-Sub port
1 x DVI-D port
HDMI1 x HDMI
RJ451 x RJ45
USB 3.02 x USB 3.0
USB 1.1/2.04 x USB 2.0
Audio Ports6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
Onboard USB1 x USB 3.0/2.0 header
2 x USB 2.0/1.1 headers
Other Connectors1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
3 x system fan headers
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x serial port header
1 x parallel port header
1 x Trusted Platform Module (TPM) header
1 x Clear CMOS jumper
Form FactorMicro ATX
Dimensions (W x L)9.60" x 8.86"
Power Pin24 Pin
FeaturesMulti-Graphics Technology
- Support for AMD CrossFire technology
I/O Controller
- iTE I/O Controller Chip
H/W Monitoring
- System voltage detection
- CPU/System temperature detection
- CPU/System fan speed detection
- CPU overheating warning
- CPU/System fan fail warning
- CPU/System fan speed control
- * Whether the fan speed control function is supported will depend on the cooler you install.
BIOS
- 2 x 64 Mbit flash
- Use of licensed AMI EFI BIOS
- Support for DualBIOS
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
- Support for Q-Flash
- Support for Xpress In

Questions about this item

What does the 32 GB maximum memory mean for a real build?

You can populate all four DDR3 slots with up to 8 GB modules each, giving 32 GB total in dual-channel mode at 1600 or 1333 MT/s.

How does the PCI Express 3.0 x16 slot running at x4 affect expansion cards?

The second x16-sized slot is electrically x4, so high-bandwidth cards like GPUs will be limited to four lanes while x1 or x4 cards run at full speed.

What clearance does the Micro ATX board need inside a case?

The board follows the Micro ATX form factor, so it fits any case with Micro ATX or larger mounting holes and standard I/O shield cut-out.
