Micro-ATX board in matte black with silver heatsinks and blue slots

GIGABYTE

GIGABYTE GA-B85M-D3V Intel motherboard

SKU CH-KAYE-AY0W6

Micro-ATX board for LGA 1150 CPUs with four SATA3 ports, four USB 3.0 ports, dual-channel DDR3 memory up to 16 GB, and Gigabit LAN

  • CPU Socket TypeLGA 1150
  • CPU TypeIntel Core 5th Gen (LGA 1150)
  • Maximum Memory Supported16GB
  • PCI Express x161 x PCI Express x16
  • PCI Express x12 x PCI Express x1
  • Form FactorMicro ATX
  • Supports 4th and 5th Gen Intel Core CPUs via LGA 1150 socket
  • Up to 16 GB dual-channel DDR3 memory at 1600 MHz
  • One PCIe 3.0 x16 slot plus two PCIe 2.0 x1 slots for expansion
  • Realtek ALC887 7.1-channel audio and Gigabit LAN for media and networking
  • Micro-ATX form factor 24.4 x 17.4 cm with four SATA3 and two SATA2 ports

LGA 1150 Micro ATX motherboard

The GIGABYTE GA-B85M-D3V is an Intel B85 motherboard built for LGA 1150 processors. It uses the Micro ATX form factor and includes Ultra Durable 4 Plus technology with a hybrid digital power engine. Dual UEFI BIOS and all solid capacitors round out the core platform.

Suits 4th and 5th Gen Core builds on DDR3

This board fits users assembling or repairing systems with 4th or 5th Generation Intel Core CPUs and existing DDR3 1333 or 1600 memory. It provides one PCIe 3.0 x16 slot, two PCIe 2.0 x1 slots and a legacy PCI slot. Builders needing newer CPU sockets or different memory types must choose another platform.

Dual-channel DDR3 limited to 16 GB

Two DIMM slots support dual-channel DDR3 at 1600 and 1333 speeds with a maximum capacity of 16 GB. This ceiling is the key specification when matching memory kits to the board.

Highlights

  • Supports 4th and 5th Gen Intel Core CPUs via LGA 1150 socket
  • Up to 16 GB dual-channel DDR3 memory at 1600 MHz
  • One PCIe 3.0 x16 slot plus two PCIe 2.0 x1 slots for expansion
  • Realtek ALC887 7.1-channel audio and Gigabit LAN for media and networking
  • Micro-ATX form factor 24.4 x 17.4 cm with four SATA3 and two SATA2 ports

Specifications

BrandGIGABYTE
ModelGA-B85M-D3V
CPU Socket TypeLGA 1150
CPU TypeIntel Core 5th Gen (LGA 1150)
Maximum Memory Supported16GB
PCI Express x161 x PCI Express x16
PCI Express x12 x PCI Express x1
Form FactorMicro ATX
FeaturesSupports 4th Generation Intel Core processors
GIGABYTE Ultra Durable 4 Plus Technology
GIGABYTE Hybrid digital power engine
GIGABYTE UEFI DualBIOS
Industry's Leading All Solid Capacitor Design
GIGABYTE 333 Onboard Acceleration (USB 3.0, SATA 3.0 & 3x USB Power)
GIGABYTE On/Off Charge for USB devices
LAN with high ESD Protection
DVI interface for smoother HD video playback

Questions about this item

How much memory can the GA-B85M-D3V handle before it becomes the bottleneck?

The board supports a maximum of 16 GB across its two DDR3 DIMM slots running at up to 1600 MT/s.

What thermal or acoustic load should I expect from the onboard voltage regulation during all-day operation?

The hybrid digital power engine uses solid capacitors and low-RDS(on) MOSFETs to reduce heat output and keep fan speeds low under continuous load.

Which processor and memory kits must I already own to populate this LGA 1150 board?

You need a 4th or 5th Generation Intel Core CPU for the LGA 1150 socket plus DDR3-1600 or DDR3-1333 non-ECC DIMMs.
