Green Micro ATX motherboard with LGA 775 socket, four DDR3 slots, blue PCIe x16 slot, white PCIe x1 slot, two white PCI slots

GIGABYTE

GIGABYTE GA-EG41MFT-US2H Intel motherboard LGA 775 G41 DDR3 8GB Micro ATX

SKU CH-AT7D-7KVHZ

Micro-ATX board for LGA 775 CPUs with G41 chipset, four DDR3 slots supporting 8 GB, one PCIe x16 slot, one PCIe x1 slot, two PCI slots, Realtek ALC888 audio and Gigabit LAN

  • CPU Socket TypeLGA 775
  • CPU Type1. Support LGA775 slot processor: IntelCore ™ 2 Extreme proc
  • ChipsetIntel G41
  • Maximum Memory Supported8GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAIDNo data yet
  • Supports Core 2 and Pentium CPUs via LGA 775 socket
  • Intel G41 chipset handles everyday desktop workloads
  • Four DDR3 slots allow up to 8GB system memory
  • Realtek ALC888 audio delivers 7.1 channel surround sound
  • Gigabit LAN with Realtek 8111D for wired network speed

Socket and chipset

This board uses the Intel G41 chipset and an LGA 775 socket to support Core 2 Extreme, Core 2 Quad, Core 2 Duo, Pentium dual-core and Celeron processors. It is built for users maintaining or repairing older systems that require this specific platform. The micro-ATX form factor measures 24.4 by 24.4 centimetres and fits compatible chassis.

Memory capacity

Four DDR3 DIMM slots accept up to 8 gigabytes of total system memory. This limit is the key specification that determines whether the board meets a build's requirements. Exceeding this amount is not possible, so the figure must match the intended workload before purchase.

Included accessories

The package supplies the motherboard, a single SATA cable and a chassis I/O back panel. A metal battery is also fitted on the board. No additional cables, brackets or software media are provided, so installers should source any extra SATA leads or mounting hardware separately.

Highlights

  • Supports Core 2 and Pentium CPUs via LGA 775 socket
  • Intel G41 chipset handles everyday desktop workloads
  • Four DDR3 slots allow up to 8GB system memory
  • Realtek ALC888 audio delivers 7.1 channel surround sound
  • Gigabit LAN with Realtek 8111D for wired network speed

Specifications

BrandGIGABYTE
SeriesGIGABYTE GA-EG41MFT-US2H
ModelGIGABYTE GA-EG41MFT-US2H
CPU Socket TypeLGA 775
CPU Type1. Support LGA775 slot processor: IntelCore ™ 2 Extreme processor/IntelCore ™ 2 Quad processor/IntelCore ™ 2 Duo processor/IntelPentium dual-core processor/IntelCeleron processor
2. L2 cache depends on CPU
ChipsetIntel G41
Maximum Memory Supported8GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications (Note 4)
2. 1 PCI Express x1 slot
3. 2 PCI slots
SATA RAIDNo data yet
Audio Chipset1. Built-in Realtek ALC888 chip
2. Support High Definition Audio
3. Support 2/4 /5.1/7.1 channels
4. Support S/PDIF input/output
5. Support CD audio input
LAN ChipsetBuilt-in Realtek8111D chip (10/100/1000 Mbit)
Onboard USBBuilt-in Southbridge Chip
Up to 8 USB 2.0/1 ports (4 on the rear panel, 4 to be connected from the USB socket in the main board via cable)

Questions about this item

What does the 8 GB memory ceiling mean when I populate all four DDR3 slots?

The board accepts up to 8 GB total across its four DDR3 DIMM sockets, so a full 4 × 2 GB kit will hit the limit; larger modules are not supported.

How fast does the single PCI Express x16 slot actually run?

The slot is wired for x16 electrical operation, giving a full 16-lane link to a graphics card or other add-in board.

Will this Micro ATX board fit in a standard ATX case?

Yes, the 24.4 cm square Micro ATX form factor uses the standard mounting pattern, so it secures into any ATX or Micro ATX chassis.
