Green ATX motherboard with silver I/O shield in anti-static bag

GIGABYTE

GIGABYTE GA-H110-D3A Intel H110 LGA 1151 ATX motherboard

SKU CH-X2XS-VT9VB MPN GA-H110-D3A.

ATX motherboard with Intel H110 chipset, LGA 1151 socket, DDR4 memory up to 32 GB, one PCI Express 3.0 x16 slot, one M.2 slot, USB 3.1 Gen 2 Type-A and RJ45, sold with I/O shield only

  • CPU Socket TypeLGA 1151
  • ChipsetIntel H110
  • Memory StandardDDR4
  • Maximum Memory Supported32GB
  • PCI Express 3.0 x161x PCI Express 3.0 x16
  • PCI Express x161
  • Supports 6th/7th Gen Intel Core processors via LGA 1151 socket
  • DDR4 memory up to 32 GB for responsive multitasking
  • PCIe 3.0 x16 slot delivers full graphics bandwidth
  • M.2 slot enables fast SATA storage expansion
  • ATX form factor fits standard desktop cases

Socket and chipset

The GA-H110-D3A is an ATX motherboard built on the Intel H110 chipset for LGA 1151 processors. It supports DDR4 memory up to 32 GB and provides one PCI Express 3.0 x16 slot plus a single PCI slot. A USB 3.1 Gen 2 Type-A port and one RJ45 connector sit on the rear I/O. The package contains only the board and I/O shield.

Who should consider this board

Builders replacing a failed H110 board or assembling a basic desktop with a compatible 1151 CPU will find the essentials covered. The single x16 slot handles one graphics card and the M.2 slot accepts one M.2 drive. Users who need multiple expansion cards, extra rear USB ports or a newer chipset feature set should look at a different platform.

The deciding specification

The LGA 1151 socket paired with the H110 chipset determines which processors fit and what feature set is available. If your CPU requires a different socket or a chipset with more lanes, this board will not work. DDR4 is the only supported memory type.

Highlights

  • Supports 6th/7th Gen Intel Core processors via LGA 1151 socket
  • DDR4 memory up to 32 GB for responsive multitasking
  • PCIe 3.0 x16 slot delivers full graphics bandwidth
  • M.2 slot enables fast SATA storage expansion
  • ATX form factor fits standard desktop cases

Specifications

BrandGIGABYTE
ModelGA-H110-D3A
CPU Socket TypeLGA 1151
ChipsetIntel H110
Memory StandardDDR4
Maximum Memory Supported32GB
PCI Express 3.0 x161x PCI Express 3.0 x16
PCI Express x161
PCI Slots1 x PCI Slot
Back I/O Ports1 x USB 3.1 Gen 2 Type-A
RJ451 x RJ45
USB 3.11 x USB 3.1
Form FactorATX

Questions about this item

Should I choose the 32GB DDR4 maximum memory capacity or a lower amount for this GA-H110-D3A motherboard?

The board supports up to 32GB of DDR4. Pick the amount that matches your workload; 16GB suits many general tasks while 32GB gives headroom for heavier multitasking.

What does the single PCI Express 3.0 x16 slot mean for graphics card performance on this H110 board?

The slot delivers PCIe 3.0 x16 bandwidth, so a modern GPU will run at its full interface speed without bottleneck from the motherboard.

How does the USB 3.1 Gen 2 Type-A port on the rear I/O limit real-world transfer speeds?

The port caps at the USB 3.1 Gen 2 10 Gbps rate, so connected drives or devices cannot exceed that throughput regardless of their own rated speed.
