Green rectangular ATX motherboard with silver CPU socket, four black DDR3 slots, blue SATA ports, black PCIe x16 slot

GIGABYTE

GIGABYTE GA-H67A-USB3-B3 LGA 1155 Intel H67 DDR3 32GB ATX Intel motherboard

SKU CH-AV6F-FW171

ATX motherboard with Intel H67 chipset, LGA 1155 socket, four DDR3 slots for 32GB, two USB 3.0 ports and twelve USB 2.0 ports

  • CPU Socket TypeLGA 1155
  • CPU Type1. Support LGA1155 slot processor: Intel Core ™ i7 processor
  • ChipsetIntel H67
  • Maximum Memory Supported32GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID4XSATA II interface; 2xSATA III interface
  • Supports 32GB DDR3 memory for multitasking
  • USB 3.0 via Renesas D720200 chip adds speed
  • Gigabit LAN with Realtek RTL8111E for networking
  • SATA II and SATA III ports for storage
  • 1-channel audio using Realtek ALC892/889 chip

Socket LGA 1155 ATX motherboard

The GIGABYTE GA-H67A-USB3-B3 is an ATX form-factor board built on the Intel H67 chipset for LGA 1155 processors. It supports Intel Core i7, i5, i3, Pentium and Celeron CPUs and provides four DDR3 DIMM slots with a maximum memory capacity of 32 GB. The board measures 30.5 cm by 24.4 cm and includes a single PCI Express x16 slot for graphics cards.

Sustained operation with H67 chipset

The Intel H67 chipset delivers stable throughput for everyday workloads and extended sessions without the thermal spikes seen in short bursts. Four SATA II ports and two SATA III ports keep storage bandwidth consistent during long file transfers or backups. The Realtek RTL8111E LAN controller maintains 10/100/1000 Mbit connectivity under continuous network load while the onboard audio and USB controllers remain responsive.

Compatibility checks before ordering

Verify that your processor uses the LGA 1155 socket and matches the supported CPU list. Confirm the power supply provides the required ATX connectors for this board. Ensure the chassis can accommodate a 30.5 cm by 24.4 cm ATX motherboard and that the rear I/O shield aligns with the supplied panel. Check that your DDR3 modules do not exceed the 32 GB total limit across four slots.

Highlights

  • Supports 32GB DDR3 memory for multitasking
  • USB 3.0 via Renesas D720200 chip adds speed
  • Gigabit LAN with Realtek RTL8111E for networking
  • SATA II and SATA III ports for storage
  • 1-channel audio using Realtek ALC892/889 chip

Specifications

BrandGIGABYTE
SeriesGIGABYTE GA-H67A-USB3-B3
ModelGIGABYTE GA-H67A-USB3-B3
CPU Socket TypeLGA 1155
CPU Type1. Support LGA1155 slot processor: Intel Core ™ i7 processor/Intel Core ™ i5 processor/Intel Core ™ i3 processor/Intel Pentium ® processor/Intel Celeron processor ®®®®®®
2. L3 cache depends on CPU
ChipsetIntel H67
Maximum Memory Supported32GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications (PCIEX16)
To maximize the performance of the graphics card, it is necessary to install it in the PCIEX16 slot when installing a graphics card.
1 PCI Express x16 slot, supporting x4 operating specifications (PCIEX4)
* When the adapter is installed PCIEX1_1 or PCIEX1_2, the PCIEX4 slot can only operate at x1 bandwidth.
3. 2 PCI Express x1 slots
All PCI Express slots support PCI Express 2.0.
4. 3 PCI slots
SATA RAID4XSATA II interface; 2xSATA III interface
Audio Chipset1. Built-in Realtek ALC892/889 chip
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
4. Support Dolby Home Theater Dolby Surround MegaBass ®
5. Support S/PDIF output
LAN ChipsetBuilt-in 1 Realtek RTL8111E chip (10/100/1000 Mbit)
Onboard USBBuilt-in chipset:
1. Up to 12 USB 2.0/1 ports (4 on the rear panel, 8 to be connected from the USB socket in the main board via cable)
Built-in Renesas D720200 chip:
Supports up to 2 USB 3.0/2 ports located on the rear panel.

Questions about this item

How quiet and cool does the GA-H67A-USB3-B3 run when left on all day?

The board uses passive cooling on the Intel H67 chipset and a 4-pin CPU fan header for PWM control, so noise stays low at idle; power draw is dictated by the installed LGA 1155 processor rather than the board itself.

What components must I already have to make this motherboard work?

You need an LGA 1155 processor (Core i7, i5, i3, Pentium or Celeron), DDR3 DIMMs up to 32 GB total across four slots, an ATX power supply with 24-pin and 4-pin CPU connectors, and a chassis that fits a 30.5 × 24.4 cm board.

Will my existing SATA drives and PCI Express cards work with this board?

Yes — four SATA II and two SATA III ports support older hard drives and SSDs, while the single PCI Express x16 slot accepts legacy graphics or add-in cards at x16 electrical.
