ATX motherboard with black PCB, silver heatsinks, LGA 1155 socket, four DDR3 slots, PCIe x16 slot, rear I/O panel

GIGABYTE

GIGABYTE GA-PH67A-D3-B3 Intel H67 LGA 1155 DDR3 32GB ATX motherboard

SKU CH-3KGN-TQQP3

ATX board with LGA 1155 socket, Intel H67 chipset, four DDR3 slots up to 32 GB, one PCIe x16, four SATA II plus two SATA III, Realtek ALC889 7.1 audio and RTL8111E gigabit LAN

  • CPU Socket TypeLGA 1155
  • CPU Type1. Support LGA1155 Slot Processor: Intel Core ™ i7 Processor
  • ChipsetIntel H67
  • Maximum Memory Supported32GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID4XSATA II interface; 2xSATA III interface
  • Supports up to 32GB DDR3 memory for responsive multitasking
  • Intel H67 chipset on LGA 1155 socket fits Core i7, i5, i3, Pentium and Celeron CPUs
  • PCI Express x16 slot at full x16 speed for graphics card performance
  • Realtek ALC889 audio with 7.1 channel output for surround sound
  • Realtek RTL8111E gigabit LAN plus two USB 3.0 and ten USB 2.0 ports

Intel H67 ATX motherboard for LGA 1155 builds

The GIGABYTE GA-PH67A-D3-B3 fits standard ATX cases and accepts Intel Core i7, i5, i3, Pentium and Celeron processors in the LGA 1155 socket. Four DDR3 DIMM slots support up to 32GB of system memory. A single PCI Express x16 slot handles the graphics card. Six SATA ports, four at 3 Gb/s and two at 6 Gb/s, provide storage connectivity.

Thermals noise and power draw in normal use

The board uses passive heatsinks on the Intel H67 chipset and voltage regulators, so it adds no fan noise of its own. Power consumption is determined by the chosen processor and graphics card rather than the motherboard itself. Realtek ALC889 audio and RTL8111E Gigabit LAN draw minimal power during typical desktop workloads.

32GB maximum DDR3 capacity

Memory tops out at 32GB across the four slots, a fixed limit of the H67 chipset. If your workload needs more RAM, this board cannot accommodate it. For builds staying at or below that ceiling, the platform delivers standard desktop connectivity with USB 2.0, USB 3.0, 7.1-channel audio and wired networking.

Highlights

  • Supports up to 32GB DDR3 memory for responsive multitasking
  • Intel H67 chipset on LGA 1155 socket fits Core i7, i5, i3, Pentium and Celeron CPUs
  • PCI Express x16 slot at full x16 speed for graphics card performance
  • Realtek ALC889 audio with 7.1 channel output for surround sound
  • Realtek RTL8111E gigabit LAN plus two USB 3.0 and ten USB 2.0 ports

Specifications

BrandGIGABYTE
SeriesGIGABYTE GA-PH67A-D3-B3
ModelGIGABYTE GA-PH67A-D3-B3
CPU Socket TypeLGA 1155
CPU Type1. Support LGA1155 Slot Processor: Intel Core ™ i7 Processor/Intel Core ™ i5 Processor/Intel Core ™ i3 Processor/Intel Pentium Processor/Intel Celeron Processor
2. L3 cache depends on CPU
ChipsetIntel H67
Maximum Memory Supported32GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications (PCIEX16)
To maximize the performance of the graphics card, it is necessary to install it in the PCIEX16 slot when installing a graphics card.
1 PCI Express x16 slot, supporting x4 operating specifications (PCIEX4)
* When installing adapters PCIEX1_2 or PCIEX1_3 slots, PCIEX4 slots can only operate at x1 bandwidth.
3 PCI Express x1 slots
All PCI Express slots support PCI Express 2.0.
4. 2 PCI slots
SATA RAID4XSATA II interface; 2xSATA III interface
Audio Chipset1. Built-in Realtek ALC889 chip
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
* To start the 7.1 channel audio output, you must use the front panel audio output of the HD (High Definition, High Fax) audio module and select the multi-channel audio function through the audio software. Support S/PDIF output
LAN ChipsetBuilt-in 1 Realtek RTL8111E chip (10/100/1000 Mbit)
Onboard USBBuilt-in chipset:
1. Up to 10 USB 2.0/1 ports (4 on the rear panel, 6 need to be connected from the USB socket in the main board via the cable)
Built-in Etron EJ168 chip:
Supports up to 2 USB 3.0/2 ports on the rear panel

Questions about this item

How is the motherboard secured in the case and which step is often missed?

Mount the board using the ATX 30.5x21.5cm hole pattern, then attach the supplied I/O back panel before securing the screws.

What component will need replacement during the board's life?

The onboard metal battery maintains CMOS settings and will eventually require replacement when the system loses time or BIOS settings.

What limit appears first when the PCI Express x16 slot runs at full load for extended periods?

The slot operates at PCI Express x16 specification; sustained maximum throughput is constrained by the x16 lane width and the connected graphics card's own thermal envelope.
