Mini-ITX motherboard in white box packaging, green PCB with black heatsinks and silver I/O shield

GIGABYTE

GIGABYTE GA-Z170N-WIFI REV.1.0 Intel motherboard

SKU CH-EZH0-5DCNC

Mini-ITX Z170 board for LGA1151 CPUs with dual HDMI, DVI-D, dual Intel Gigabit LAN, dual-channel DDR4 up to 3200 MT/s, two M.2 slots, six SATA 6Gb/s ports and 7.1-channel Realtek ALC1150 audio

  • CPU Socket TypeLGA 1151
  • CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1151)
  • ChipsetIntel Z170
  • Onboard Video ChipsetIntegrated Graphics Processor - Intel HD Graphics support- 1
  • Number of Memory Slots2x288pin (DDR4)
  • Memory StandardDDR4 3200*(*O.C.)/ 3000*/ 2800*/ 2666*/ 2400*/ 2133
  • Supports Intel Core i7, i5, i3, Pentium and Celeron processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB with overclocked speeds to 3200 MHz
  • Full HD display output through DVI-D at 1920x1200 and two HDMI ports
  • Dual Intel Gigabit LAN controllers for reliable wired networking
  • Realtek ALC1150 audio with 7.1-channel surround sound support

Compact Z170 platform for LGA 1151 builds

This motherboard pairs the Intel Z170 chipset with an LGA 1151 socket in a small-form-factor design. It accepts Core i7, i5, i3, Pentium and Celeron processors and includes integrated Intel HD graphics with DVI-D and dual HDMI outputs. Dual Intel gigabit LAN and Realtek ALC1150 audio are built in.

Dual-channel DDR4 up to 32 GB

Two 288-pin slots support DDR4 at 2133, 2400, 2666, 2800, 3000 and 3200 (OC) speeds for a maximum of 32 GB. The single PCI Express 3.0 x16 slot runs at full x16 bandwidth. Storage connects through six SATA 6 Gb/s ports, two SATA Express connectors and a rear-mounted M.2 Socket 3 slot, with RAID 0/1/5/10 available on the SATA array.

Passive chipset cooling keeps noise low in typical

The Z170 PCH is cooled without a fan, so acoustic output depends only on the CPU cooler and case airflow chosen by the builder. Dual gigabit LAN controllers and the audio codec draw modest power, while the board's 6+2 phase digital VRM delivers clean current to the processor at stock or mildly overclocked settings.

Highlights

  • Supports Intel Core i7, i5, i3, Pentium and Celeron processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB with overclocked speeds to 3200 MHz
  • Full HD display output through DVI-D at 1920x1200 and two HDMI ports
  • Dual Intel Gigabit LAN controllers for reliable wired networking
  • Realtek ALC1150 audio with 7.1-channel surround sound support

Specifications

BrandGIGABYTE
ModelGA-Z170N-WIFI (rev. 1.0)
CPU Socket TypeLGA 1151
CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1151)
ChipsetIntel Z170
Onboard Video ChipsetIntegrated Graphics Processor - Intel HD Graphics support- 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz* The DVI-D port does not support D-Sub connection by adapter.- 2 x HDMI ports, supporting a maximum resolution of 4096x2160@24 Hz* Support for HDMI 1.4 version.- Support for up to 3 displays at the same time- Maximum shared memory of 512 MB
Number of Memory Slots2x288pin (DDR4)
Memory StandardDDR4 3200*(*O.C.)/ 3000*/ 2800*/ 2666*/ 2400*/ 2133
Maximum Memory Supported32GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express x16 slot, running at x16(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
Other Slots1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI)
Serial ATA (SATA)6 x SATA 6Gb/s connectors
SATA Express2 x SATA Express connectors
M.21 x M.2 Socket 3 connector on the back of the motherboard
SATA RAID0/1/5/10
Audio ChipsetRealtek ALC1150
Audio Channels2/4/5.1/7.1-channel
LAN ChipsetIntel GbE LAN chip
Second LAN ChipsetIntel GbE LAN chip
Max LAN Speed1Gbps
Wireless LANWi-Fi 802.11 a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
BluetoothBLUETOOTH 4.2, 4.1, BLE, 4.0, 3.0, 2.1+EDR
PS/21 x PS/2 keyboard/mouse port
Video Ports1 x DVI-D
HDMI2 x HDMI
RJ452 x RJ45
USB 3.04 x USB 3.0/2.0 ports
USB Type-C1 x USB Type-C port, with USB 3.0 support
S/PDIF Out1 x Optical
Audio Ports5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In)
Antenna Connectors2 x SMA antenna connectors (2T2R)
Onboard USB1 x USB 3.0/2.0 header1 x USB 2.0/1.1 header
Other Connectors1 x 24-pin ATX main power connector1 x 4-pin ATX 12V power connector1 x CPU fan header1 x system fan header1 x front panel header1 x front panel audio header1 x S/PDIF Out header1 x speaker header1 x Clear CMOS jumper1 x chassis intrusion header
Form FactorMini ITX
Dimensions (W x L)6.7" x 6.7"
Power Pin24 Pin
FeaturesI/O Controller: - iTE I/O Controller ChipH/W Monitoring: - System voltage detection- CPU/System temperature detection- CPU/System fan speed detection- CPU/System overheating warning- CPU/System fan fail warning- CPU/System fan speed control- * Whether the fan speed control function is supported will depend on the cooler you install.BIOS: - 2 x 64 Mbit flash- Use of licensed AMI UEFI BIOS- Support for DualBIOS- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0Unique Features: - Support for APP Center* Available applications in APP Center may vary by motherboard model. Supported functi
Package ContentsGA-Z170N-WIFI motherboardMotherboard driver diskTwo SATA cablesUser's ManualQuick Installation GuideOne antennaI/O ShieldWireless module driver disk

Questions about this item

Will my existing DDR4 2133 MHz modules run on this board?

Yes, the board lists DDR4 2133 as a supported speed alongside 2400, 2666, 2800, 3000 and 3200 OC.

How do I confirm the integrated graphics are active after assembly?

Connect a display to the DVI-D or one of the two HDMI ports; the board supports up to 1920x1200 at 60 Hz on DVI-D and 4K on HDMI.

What accessories are included and what must I source separately?

The white-box package includes the I/O backplate, one SATA cable and a driver CD; Wi-Fi antennas are not supplied.
