Green ATX motherboard with silver heatsinks and black expansion slots

GIGABYTE

GIGABYTE GA-Z77-DS3H rev.1.0 Intel motherboard

SKU CH-XD5D-5PJC2

An Intel Z77 ATX motherboard with an LGA 1155 socket, four DDR3 slots for up to 32 GB, a PCIe 3.0 x16 slot, two SATA III and three SATA II ports, Realtek ALC887 7.1 audio and a Gigabit LAN chip

  • CPU Socket TypeLGA 1155
  • CPU Type1. Support LGA1155 Slot Processor: Intel Core ™ i7 Processor
  • ChipsetIntel Z77
  • Maximum Memory Supported32GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID3XSATA II interface; 2xSATA III interface
  • Supports Intel Core i7, i5, i3, Pentium and Celeron CPUs on LGA 1155 socket
  • Up to 32 GB DDR3 memory across four DIMM slots for multitasking headroom
  • PCI Express 3.0 x16 slot delivers full graphics-card bandwidth
  • Realtek ALC887 codec enables 7.1-channel high-definition audio
  • Gigabit LAN plus four USB 3.0 ports for fast wired networking and peripherals

LGA 1155 Z77 ATX board

This GIGABYTE GA-Z77-DS3H rev.1.0 is an ATX motherboard built around the Intel Z77 chipset for LGA 1155 processors. It accepts Core i7, i5, i3, Pentium and Celeron CPUs and provides four DDR3 DIMM slots for up to 32 GB of memory.

Builders keeping an LGA 1155 system alive

The board suits anyone extending the life of an existing Sandy Bridge or Ivy Bridge platform, especially if they need SATA III ports and a PCI Express 3.0 x16 slot. It will not suit builders starting a new platform or anyone who needs more than four memory slots.

Four DDR3 slots, 32 GB ceiling

The decisive specification is the four DDR3 DIMM sockets with a 32 GB maximum. If the intended CPU and workload require more memory than that, this motherboard cannot meet the requirement.

Highlights

  • Supports Intel Core i7, i5, i3, Pentium and Celeron CPUs on LGA 1155 socket
  • Up to 32 GB DDR3 memory across four DIMM slots for multitasking headroom
  • PCI Express 3.0 x16 slot delivers full graphics-card bandwidth
  • Realtek ALC887 codec enables 7.1-channel high-definition audio
  • Gigabit LAN plus four USB 3.0 ports for fast wired networking and peripherals

Specifications

BrandGIGABYTE
SeriesGIGABYTE GA-Z77-DS3H(rev.1.0)
ModelGIGABYTE GA-Z77-DS3H(rev.1.0)
CPU Socket TypeLGA 1155
CPU Type1. Support LGA1155 Slot Processor: Intel Core ™ i7 Processor/Intel Core ™ i5 Processor/Intel Core ™ i3 Processor/Intel Pentium Processor/Intel Celeron Processor
2. L3 cache depends on CPU
ChipsetIntel Z77
Maximum Memory Supported32GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications (PCIEX16)
(PCIEX16 slot supports PCI Express 3.0)
To maximize the performance of the graphics card, it is necessary to install it in the PCIEX16 slot when installing a graphics card.
If a 32nm (Sandy Bridge) CPU is installed, the PCI Express x16 slot supports up to PCI Express 2.0.
1 PCI Express x16 slot, supporting x4 operating specifications (PCIEX4)
3. 2 PCI Express x1 slots
PCIEX4 and PCI Express x1 slots both support PCI Express 2.0.
4. 2 PCI slots
SATA RAID3XSATA II interface; 2xSATA III interface
Audio Chipset1. Built-in Realtek ALC887 sound chip
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
To activate the 7.1 channel audio output, you must use the front panel audio output of the HD (High Definition, High Fax) audio module and select the multi-channel audio function through the audio software.
4. Support S/PDIF output
LAN ChipsetBuilt-in Atheros GbE network chip (10/100/1000 Mbit)
Onboard USBBuilt-in chipset:
1. Support up to 4 USB 3.0/2 ports (2 on the rear panel, 2 need to be connected from the USB socket in the main board via the cable)
In the Windows XP operating system, Intel USB 3.0 only supports USB 2.0 transfer rates.
2. Support up to 8 USB 2.0/1 ports (4 on the rear panel, 4 need to be connected from the USB socket in the main board via the cable)

Questions about this item

Which processor do I need to install in the LGA 1155 socket for this Z77 board to function?

The socket accepts Intel Core i7, i5, i3, Pentium or Celeron CPUs built for LGA 1155; choose one of those to power the system.

Will my existing PCI Express 2.0 graphics card run in the PCIEX16 slot that supports PCI Express 3.0?

Yes, the slot is backward compatible, so a PCIe 2.0 card will operate at PCIe 2.0 speeds without any extra configuration.

How can I verify the Realtek ALC887 audio chip is delivering 7.1-channel output after I connect the front-panel header?

Open the Realtek control panel in Windows, select 7.1 speaker configuration and run the speaker test; all eight channels should play a tone.
