Green ATX motherboard with silver LGA 1150 socket and four black DDR3 slots

GIGABYTE

GIGABYTE GA-Z87P-D3 rev.1.x Intel motherboard

SKU CH-GFM2-6V3AE

Supports LGA 1150 Intel CPUs with Z87 chipset, four DDR3 slots for up to 32 GB, one PCI Express x16 slot, six SATA III ports, Realtek ALC887 7.1 audio.

  • CPU Socket TypeLGA 1150
  • CPU Type1. Support LGA1150 slot processor: Intel Core ™ i7 processor
  • ChipsetIntel Z87
  • Maximum Memory Supported32GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID6XSATA III interface
  • LGA 1150 socket fits Intel Core i7, i5, i3, Pentium and Celeron CPUs
  • Intel Z87 chipset provides up to six SATA III ports for fast storage
  • Four DDR3 DIMM slots support up to 32 GB of system memory
  • Realtek ALC887 audio chipset delivers 7.1 channel high-definition sound
  • Built-in Realtek Gigabit LAN handles 10/100/1000 Mbit network speeds

Socket & Chipset

The GIGABYTE GA-Z87P-D3 rev.1.x is an ATX motherboard built on the Intel Z87 chipset for LGA 1150 processors. It accepts Core i7, i5, i3, Pentium and Celeron CPUs, making it suitable for replacement builds or budget upgrades on this platform.

Memory Limit

Four DDR3 DIMM slots support a maximum of 32GB of system memory. This ceiling is the single figure that determines whether the board fits a planned configuration; workloads needing more capacity will require a different platform.

Installation Notes

The board measures 30.5 by 22.5cm and fits standard ATX cases with the usual standoff pattern. Only one SATA cable and the rear I/O panel are included, so builders must supply additional cables, CPU cooler mounting hardware and any required USB 3.0 header adapters.

Highlights

  • LGA 1150 socket fits Intel Core i7, i5, i3, Pentium and Celeron CPUs
  • Intel Z87 chipset provides up to six SATA III ports for fast storage
  • Four DDR3 DIMM slots support up to 32 GB of system memory
  • Realtek ALC887 audio chipset delivers 7.1 channel high-definition sound
  • Built-in Realtek Gigabit LAN handles 10/100/1000 Mbit network speeds

Specifications

BrandGIGABYTE
SeriesGIGABYTE GA-Z87P-D3(rev.1.x)
ModelGIGABYTE GA-Z87P-D3(rev.1.x)
CPU Socket TypeLGA 1150
CPU Type1. Support LGA1150 slot processor: Intel Core ™ i7 processor/Intel Core ™ i5 processor/Intel Core ™ i3 processor /Intel Pentium processor/Intel Celeron processor
2. L3 cache depends on CPU
ChipsetIntel Z87
Maximum Memory Supported32GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications (PCIEX16)
To maximize the performance of the graphics card, it is necessary to install it in the PCIEX16 slot when installing a graphics card.
(PCIEX16 slot supports PCI Express 3.0)
1 PCI Express x16 slot, supporting x4 operating specifications (PCIEX4)
(PCIEX4 slot supports PCI Express 2.0)
3.4 PCI slots
SATA RAID6XSATA III interface
Audio Chipset1. Built-in Realtek ALC887 chip ®
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
To activate the 7.1 channel audio output, you must use the front panel audio output of the HD (High Definition, High Fax) audio module and select the multi-channel audio function through the audio software.
4. Support S/PDIF output
5. Support S/PDIF input
LAN ChipsetBuilt-in Realtek GbE network chip (10/100/1000 Mbit)
Onboard USBBuilt-in chipset:
1. Support up to 6 USB 3.0/2 ports (4 on the rear panel, 2 need to be connected from the USB socket in the main board via the cable)
2. Up to 8 USB 2.0/1 ports (2 on the rear panel, 6 need to be connected from the USB socket in the main board via the cable)

Questions about this item

What does the 32 GB DDR3 limit mean for a typical build?

The board has four DDR3 DIMM slots and supports up to 32 GB total, so you can populate all four slots with 8 GB modules to reach the maximum capacity.

How does the PCI Express x16 slot operate with a graphics card?

The single PCI Express x16 slot runs at x16 electrical speed, giving a discrete graphics card full bandwidth from the Z87 chipset.

Will this ATX board fit in a standard mid-tower case?

The board measures 30.5 cm by 22.5 cm, matching the standard ATX form factor used by most mid-tower and larger cases.
