Rectangular ATX motherboard, matte black finish, silver LGA 1151 socket, four DDR4 slots, PCIe x16 slot, USB Type-C port on rear I/O

GIGABYTE

GIGABYTE H170-Designare rev.1.0 LGA 1151 Intel motherboard

SKU CH-90PV-1ZD0H

ATX board with Intel H170 chipset, LGA 1151 socket and 64 GB DDR4 maximum memory

  • CPU Socket TypeLGA 1151
  • CPU TypeSupports LGA1151 slot 7th/6th generation processors: Intel C
  • ChipsetIntel H170
  • Maximum Memory Supported64GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID2XM.2 interface, 2xSATA Express interface, 3xSATA III interf
  • Supports 64GB DDR4 memory for demanding workloads
  • LGA 1151 socket fits 6th and 7th generation Intel Core processors
  • Intel H170 chipset provides stable platform features
  • Realtek ALC887 audio delivers 7.1 channel high-definition sound
  • Intel Gigabit LAN ensures reliable wired network connectivity

H170 Designare LGA 1151 Platform

This ATX motherboard pairs the Intel H170 chipset with an LGA 1151 socket for 6th and 7th generation Core i7, i5, i3, Pentium and Celeron processors. Four DDR4 DIMM slots accept up to 64GB of system memory for multitasking workloads.

Build Connectors And Expansion

A full length PCI Express x16 slot runs at x16 electrical for discrete graphics cards. Storage options include two M.2 interfaces, two SATA Express ports and three SATA III ports. Rear I/O provides one USB 3.1 Type-C port, one USB 3.1 Type-A port and six additional USB 3.0/2.0 ports alongside Intel Gigabit LAN and Realtek ALC887 audio with 7.1 channel support.

Compatibility Checks Before Ordering

The board measures 30.5 by 24.4 cm so confirm your case accepts ATX dimensions. Verify that your power supply delivers the required ATX 24 pin and CPU auxiliary connectors. Ensure your chosen processor is a supported LGA 1151 6th or 7th generation model and that DDR4 modules match the 64GB maximum capacity.

Highlights

  • Supports 64GB DDR4 memory for demanding workloads
  • LGA 1151 socket fits 6th and 7th generation Intel Core processors
  • Intel H170 chipset provides stable platform features
  • Realtek ALC887 audio delivers 7.1 channel high-definition sound
  • Intel Gigabit LAN ensures reliable wired network connectivity

Specifications

BrandGIGABYTE
SeriesGIGABYTE H170 Design (rev.1.0)
ModelGIGABYTE H170-Designare (rev.1.0)
CPU Socket TypeLGA 1151
CPU TypeSupports LGA1151 slot 7th/6th generation processors: Intel Core ™ i7 processor/Intel Core ™ i5 processor/Intel Core ™ i3 processor/Intel Pentium processor/Intel Celeron processor
* Support 7th generation Intel Core ™ processor Please update the latest version of BIOS. ®
2. L3 cache depends on CPU
ChipsetIntel H170
Maximum Memory Supported64GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications (PCIEX16)
To maximize the performance of the graphics card, it is necessary to install it in the PCIEX16 slot when installing a graphics card.
1 PCI Express x16 slot, supporting x4 operating specifications (PCIEX4)
Due to the shared bandwidth between the PCIEX4 slot and the SATA3 0/1 socket and the PCI Express x1 slot, the SATA3 0/1 socket and the PCI Express x1 slot cannot be used when a PCIe x4 expansion card is installed in the PCIEX4 slot.
3. 4 PCI Express x1 slots
All PCI Express slots support PCI Express 3.0.
SATA RAID2XM.2 interface, 2xSATA Express interface, 3xSATA III interface
Audio Chipset1. Built-in Realtek ALC887 chip ®
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
4. Support S/PDIF output
LAN ChipsetBuilt-in Intel GbE network chip (10/100/1000 Mbit)
Onboard USBBuilt-in chipset + Intel USB 3.1 controller: ®
1.1 USB Type-C ™ interface on the rear panel, supporting USB 3.1
2.1 USB 3.1 Type-A interface (red) on the rear panel
Built-in chipset:
3.8 USB 3.0/2 ports (6 on the rear panel, 2 to be connected from the USB socket in the main board via cable)
4 USB 2.0/1 ports need to be connected from the USB socket in the main board via the cable
