Green Micro ATX motherboard with black slots and silver heatsinks

GIGABYTE

GIGABYTE H310M DS2 2.0 LGA 1151 Intel H310 DDR4 Micro ATX Motherboard

SKU CH-YHH4-JHK7M

Micro ATX board with Intel H310 chipset, LGA 1151 socket, two DDR4 slots up to 32 GB, four SATA ports and 7.1-channel audio

  • CPU Socket TypeLGA 1151
  • CPU TypeCore i9 / i7 / i5 / i3 (11th / 10th Gen, LGA1200)
  • ChipsetIntel H310
  • Form FactorMicro ATX
  • Supports up to 32 GB DDR4 memory with two DIMM slots
  • Intel H310 chipset on Micro ATX form factor for compact builds
  • 1-channel audio output for immersive sound
  • Four SATA III connectors for HDD and SSD storage
  • LGA 1151 socket compatible with Intel Celeron, Pentium, Core i3, i5, i7 processors

Socket LGA 1151 Micro ATX Board

This Micro ATX motherboard uses the Intel H310 chipset and an LGA 1151 socket for Intel Celeron, Pentium and Core i3, i5, i7 processors. It suits budget office or home builds that need a compact board with basic connectivity.

Installation Notes

The board fits standard Micro ATX standoffs and uses a single CPU fan header, one chassis fan header and a front panel connector. Only two DDR4 DIMM slots are present, so memory upgrades are limited to two modules and the maximum capacity is 32 GB.

Capacity And Headroom

Four SATA III ports support HDD and SSD storage, while one USB 3.1 Gen 1 header and one USB 2.0 header provide front panel I/O. Dual channel DDR4 runs at 2133, 2400 or 2666 MHz and the 32 GB ceiling meets typical mainstream workloads.

Highlights

  • Supports up to 32 GB DDR4 memory with two DIMM slots
  • Intel H310 chipset on Micro ATX form factor for compact builds
  • 1-channel audio output for immersive sound
  • Four SATA III connectors for HDD and SSD storage
  • LGA 1151 socket compatible with Intel Celeron, Pentium, Core i3, i5, i7 processors

Specifications

CPU Socket TypeLGA 1151
CPU TypeCore i9 / i7 / i5 / i3 (11th / 10th Gen, LGA1200)
ChipsetIntel H310
Form FactorMicro ATX

Questions about this item

How can I confirm the H310M DS2 2.0 is running correctly after installing a processor and memory?

Power on the system and verify the POST screen shows the installed CPU model and the total DDR4 memory detected up to 32 GB across the two DIMM slots.

What does the H310M DS2 2.0 box include and which essential parts must I source separately?

The motherboard ships with the board itself, an I/O shield, SATA cables and documentation; you must supply a compatible LGA 1151 processor, DDR4 DIMMs, storage drives, a chassis, power supply and CPU cooler.

Which memory speed should I choose for the H310M DS2 2.0 given its supported DDR4 frequencies?

Select DDR4 modules rated at 2133, 2400 or 2666 MHz; the board will run them in dual-channel mode up to the maximum 32 GB capacity.
