Green Mini-ITX motherboard with silver CPU socket, two black DDR4 slots, rear I/O shield, single PCIe x16 slot

GIGABYTE

GIGABYTE H370N WIFI Intel motherboard LGA 1151

SKU CH-D368-DW97V

Mini-ITX board for LGA 1151 CPUs with Intel H370 chipset, dual DDR4 slots up to 32 GB, dual Intel GbE LAN and 7.1 audio

  • CPU Socket TypeLGA 1151
  • CPU Type1. Support LGA1151 slot - 9th and 8th generation processors:
  • ChipsetIntel H370
  • Maximum Memory Supported32GB
  • PCI Slots1 PCI Express x16 slot for x16 operation (PCIEX16 slot suppo
  • SATA RAID2XM.2 interface, 4xSATA III interface
  • Supports 9th and 8th Gen Intel Core processors with LGA 1151 socket
  • Compact Mini-ITX board measures 17 x 17 cm for small-form-factor builds
  • Dual-channel DDR4 memory up to 32 GB across two DIMM slots
  • Intel H370 chipset provides one PCIe 3.0 x16 slot and four SATA III ports
  • Realtek ALC1220-VB audio codec delivers 7.1-channel high-definition sound

Mini-ITX LGA 1151 board

This Mini-ITX motherboard fits Intel LGA 1151 processors from the 8th and 9th generations including Core i7, i5, i3, Pentium and Celeron models. It is built for compact systems that need a full desktop socket in a 17x17cm footprint.

PCIe 3.0 and SATA limits

The single PCI Express x16 slot runs at PCIe 3.0 speeds, so modern graphics cards will operate at that bandwidth ceiling. Storage connects through four SATA III ports and two M.2 interfaces that share the chipset's SATA pathways.

32 GB DDR4 ceiling

Two DDR4 DIMM slots support up to 32 GB of system memory, which covers most mainstream workloads and light content creation. Beyond that capacity the board cannot expand, so memory-heavy tasks will hit a hard limit.

Highlights

  • Supports 9th and 8th Gen Intel Core processors with LGA 1151 socket
  • Compact Mini-ITX board measures 17 x 17 cm for small-form-factor builds
  • Dual-channel DDR4 memory up to 32 GB across two DIMM slots
  • Intel H370 chipset provides one PCIe 3.0 x16 slot and four SATA III ports
  • Realtek ALC1220-VB audio codec delivers 7.1-channel high-definition sound

Specifications

BrandGIGABYTE
SeriesGIGABYTE H370N WIFI
ModelGIGABYTE H370N WIFI
CPU Socket TypeLGA 1151
CPU Type1. Support LGA1151 slot - 9th and 8th generation processors: Intel Core ™ i7 processor/Intel Core ™ i5 processor/Intel Core ™ i3 processor/Intel Pentium processor/Intel Celeron processor
2. L3 cache depends on CPU
ChipsetIntel H370
Maximum Memory Supported32GB
PCI Slots1 PCI Express x16 slot for x16 operation
(PCIEX16 slot supports PCI Express 3.0)
SATA RAID2XM.2 interface, 4xSATA III interface
Audio Chipset1. Built-in Realtek ALC1220-VB chip ®
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
To activate the 7.1 channel audio output, you must use the front panel audio output of the HD (High Definition, High Fax) audio module and select the multi-channel audio function through the audio software.
4. Support S/PDIF output
LAN ChipsetBuilt-in 2 Intel GbE network chips (10/100/1000 Mbit)
Onboard USBBuilt-in chipset:
1 USB Type-C ™ interface on the rear panel, supporting USB 3.1 Gen 1
2.6 USB 3.1 Gen 1 ports (4 on the rear panel, 2 to be connected from the USB socket in the main board via cable)
2 USB 2.0/1 ports, which need to be connected from the USB socket in the main board via a cable

Questions about this item

Should I pick the 32 GB DDR4 option or a lower capacity for this H370N WIFI board?

The board tops out at 32 GB across its two DDR4 slots, so choose that figure only if you plan to fill both DIMMs; otherwise a 16 GB kit leaves room to expand later.

What does the dual Intel GbE LAN actually deliver inside a built PC?

Each port handles up to 1000 Mbit wired throughput, giving two independent gigabit links for separate networks or link aggregation without adding a card.

How fast can the rear USB Type-C and the six USB 3.1 Gen 1 ports move data in practice?

All seven ports share the 5 Gbit/s USB 3.1 Gen 1 ceiling, so real-world transfers peak around that rate per port when the bus is not saturated elsewhere.
